Diagnosing NHibernate Second‑Level Cache Issues: A Practical Guide

Problem Statement

When your application’s queries keep hitting the database instead of the cache, performance drops and you lose the benefits of NHibernate’s second‑level cache. The symptoms can be subtle – missing cache logs, stale data, or silent cache misses – and the root cause is often a mis‑configured or disabled cache component.

Typical Symptoms

Symptom	Description
No Cache Hit entries in logs	Cache not initialized or disabled.
Queries hit the DB on every run	Cache provider failed to store results.
Stale data after updates	Improper locking strategy or missing invalidation.
Runtime exceptions mentioning region names	Region mis‑configuration or missing definition.
Memory spikes after enabling cache	Eviction policy not set or region size too large.

Root Causes & Diagnostic Table

Cause	Diagnostic Check	Fix
Cache not enabled in NHibernate configuration	Search cache.use_second_level_cache in hibernate.cfg.xml or fluent config.	Set cache.use_second_level_cache="true" and rebuild SessionFactory.
Wrong provider assembly or missing connection string	Review cache.provider_class and provider‑specific settings.	Install correct provider NuGet package, update assembly reference, and provide valid connection string.
Entity not marked cacheable	Check mapping files or Fluent API for Cacheable().	Add Cacheable() to the mapping or Cacheable() in Fluent.
Region name mismatch or missing region definition	Verify region names in mappings match those in provider config.	Align region names or add missing region definitions.
Incorrect locking strategy	Look for cache.use_minimal_puts or locking strategy in logs.	Choose appropriate strategy: read-only for immutable data, read-write for mutable.
SessionFactory not rebuilt after changes	Confirm that SessionFactory is recreated after config changes.	Rebuild SessionFactory programmatically or restart the application.

Ordered Diagnostic Checklist

1. Verify Cache Flag

   var cfg = new Configuration();
   cfg.Configure();
   Console.WriteLine(cfg.GetProperty("cache.use_second_level_cache"));


   Expected output: true. If false, enable it.

2. Confirm Provider Initialization

   Enable NHibernate logging at DEBUG level. Search for Cache provider initialized messages. If missing, check cache.provider_class and assembly load errors.

3. Check Entity Cacheability

   // Mapping XML example
   <class name="Order" table="Orders" cache="read-write" />


   or Fluent API:

   public class OrderMap : ClassMap<Order>
   {
       public OrderMap()
       {
           Cache.ReadWrite();
       }
   }


4. Run a Test Query and Inspect Logs

   using (var session = sessionFactory.OpenSession())
   {
       var order = session.Get<Order>(1);
   }


   Check logs for Cache Miss followed by Cache Hit on subsequent runs. If only misses appear, the cache region isn’t storing results.

5. Inspect Provider’s Cache Region

   For Infinispan, use http://localhost:9990/rest/cache/Orders. For MemoryCache, use MemoryCache.Default.Get("Orders:1") in a debug session.

6. Monitor Memory Usage

   Use Process.GetCurrentProcess().PrivateMemorySize64 or a profiler to detect rapid growth after enabling cache.

7. Validate Eviction Policy

   Check provider config for max-entries or eviction-policy. Adjust to avoid memory overflow.

8. Confirm Locking Strategy

   If using read-write, ensure updates trigger cache invalidation. Test by updating an entity and re-querying.

Fixes Tied to Findings

• Enable Cache Flag – Add cache.use_second_level_cache="true" to hibernate.cfg.xml or fluent config.
• Correct Provider – Add NuGet package NHibernate.SQLCache or provider‑specific package, update cache.provider_class.
• Mark Entities – Add Cacheable() in mappings.
• Align Region Names – Ensure mapping cache="read-write" matches provider region.
• Set Locking Strategy – Use cache.use_minimal_puts="true" for read‑only data or read-write for mutable.
• Rebuild SessionFactory – Call sessionFactory.Close() and recreate after config changes.
• Configure Eviction – Set max-entries or eviction-policy="LRU" in provider config.

Escalation Criteria

1. If after all checks the cache still behaves incorrectly, verify that the provider version supports the features you need (e.g., Infinispan 12.x requires specific JARs).
2. Consult the provider’s documentation for any known bugs or required JVM options.
3. Engage the application’s DevOps or infrastructure team if memory usage remains high despite eviction settings.
4. Open a support ticket with the provider vendor if you encounter provider‑specific exceptions or performance regressions.

Practical Verification Checklist

• Logs show Cache Hit after first query.
• Provider’s cache region contains the entity key.
• Memory usage stabilizes after cache population.
• Updates to entities correctly invalidate cache entries.

Conclusion

By following the ordered diagnostic steps and matching findings to targeted fixes, you can quickly pinpoint why NHibernate’s second‑level cache isn’t delivering. Keep an eye on logs, provider metrics, and memory usage to confirm that the cache is both functional and efficient.
