Diagnosing MUI Data Grid Server‑Side Pagination Stale Data Issues

Recognizable condition

When using @mui/x-data-grid in server‑side mode (paginationMode='server'), the grid may continue to show rows from a previous page or keep a loading spinner after a successful API call. The network tab shows a valid response, yet the UI does not update.

Short cause/diagnostic table

Symptom	Likely cause
Stale rows or empty grid despite new data	Missing or incorrect totalCount in server response
Loading spinner never disappears	rowCount returned does not match the actual number of rows
Page size seems ignored	Grid pageSize prop differs from the limit/offset sent to the API
Sorting/filtering resets to defaults	Sort/model or filter/model not forwarded in getRows params

Ordered checks

1. Inspect the network request/response – Open Chrome DevTools → Network, filter XHR, locate the data‑grid request. Verify:
   • Query parameters include limit (or pageSize) and offset (or page).
   • Response JSON contains both rows (array) and totalCount (integer).
   Where to run: Browser dev tools; no special permissions needed. Risk: None – read‑only inspection.
2. Log the getRows return value – Add a temporary console log inside your data source:

   const getRows = async (params) => {
     const { rows, totalCount } = await fetchData(params);
     console.log('getRows returning:', { rowsLength: rows.length, totalCount });
     return { rows, rowCount: totalCount };
   };


   Check that rowsLength matches the rowCount you logged. Where to run: In your React component file; requires dev build. Risk: Only adds logging; remove before production.
3. Temporarily switch to client‑side pagination – Set paginationMode='client' and pass a static array (e.g., the first page of data) to the rows prop. If the UI updates correctly, the issue lies in server‑side handling. Where to run: Same component; no extra permissions. Risk: Changes UI behavior; revert after test.
4. Disable sorting/filtering – Remove sortModel and filterModel props or set them to empty arrays. Observe whether pagination works. If it does, the problem is likely missing propagation of those models to the server. Where to run: In the grid props; no special permissions.

Fixes tied to findings

• Missing totalCount – Adjust the backend to include a field named exactly totalCount (or map it in getRows). Example adjustment:

// Express.js example
app.get('/api/rows', (req, res) => {
  const limit = parseInt(req.query.limit) || 100;
  const offset = parseInt(req.query.offset) || 0;
  db.query('SELECT COUNT(*) AS total FROM items', (err, countRes) => {
    if (err) return res.status(500).send(err);
    const total = countRes[0].total;
    db.query('SELECT * FROM items LIMIT ? OFFSET ?', [limit, offset], (err, rows) => {
      if (err) return res.status(500).send(err);
      res.json({ rows, totalCount: total }); // <-- must match Grid expectation
    });
  });
});

• Incorrect rowCount – Ensure the value you return equals the total number of records, not the length of the current page.
• Page‑size mismatch – Align the Grid prop with the API limit:

  <DataGrid
    paginationMode="server"
    pageSize={100}   // must equal the limit sent in the request
    getRows={myGetRows}
  />


  If you use a different name for the limit (e.g., pageSize on the server), map it inside getRows.
• Sort/filter models not forwarded – Read the params object and pass its sortModel and filterModel to the API:

  const getRows = async (params) => {
    const { sortModel, filterModel, pagination } = params;
    const query = { limit: pagination.pageSize, offset: pagination.page * pagination.pageSize };
    if (sortModel.length) query.sort = sortModel.map(s => `${s.field} ${s.sort}`);
    if (filterModel.length) query.filter = filterModel.map(f => ({ [f.field]: f.value }));
    const resp = await fetch('/api/rows', { method: 'POST', body: JSON.stringify(query) });
    return resp.json();
  };


After applying a fix, force a refresh if needed:

// Using the grid's API reference
const gridRef = useRef(null);
// … after data change
gridRef.current?.apiRef.current.forceUpdate();

Escalation criteria

If you have verified:

• The API returns correct rows and totalCount.
• The getRows function returns an object shaped as { rows: RowModel[], rowCount: number }.
• Grid props paginationMode='server' and pageSize match the request limit.
• Sorting/filtering models are properly forwarded.

and the UI still shows stale data, consider:

1. Upgrading to the latest @mui/x-data-grid (v6+ at time of writing) – known pagination bugs were fixed in recent releases.
2. Reviewing the MUI X GitHub issue tracker for similar reports.
3. Creating a minimal reproducible example using the official template and filing a bug with the MUI issue template.

Practical verification

After a fix, open React DevTools, select the DataGrid component, and watch its rows and rowCount props change as you navigate pages. Then:

1. Go to page 2, then back to page 1.
2. Confirm the displayed rows match the freshly fetched data for page 1 (no leftover rows from page 2).
3. Ensure the loading spinner disappears once the API resolves.

If the props update but the UI does not, check for accidental mutation of the rows array elsewhere in your code; treat data as immutable to let the grid’s change detection work.
