Diagnosing Mattermost File Upload Failures: 413 and 500 Errors

Recognizable condition

Users report that file attachments either return HTTP 413 Payload Too Large or a generic HTTP 500 Internal Server Error. Small files (e.g., < 1 MB) upload successfully, while larger files fail consistently.

Cause / diagnostic quick‑reference table

Observed symptom	Likely cause	Primary log indicator
413 on any file > X MB	Server‑wide MaxFileSize or per‑channel/team limit exceeded	"level":"error","msg":"file size exceeds limit"
500 on large files only	Disk full, Postgres connection pool exhaustion, or TLS timeout during multipart streaming	"level":"error","msg":"failed to write file" or "pq: sorry, too many clients already"
403 on specific extensions	File‑type policy blocks the MIME type	"level":"warn","msg":"file type not allowed"
400 on any upload	Malformed multipart request or parser mis‑configuration	"level":"error","msg":"multipart parse error"

Ordered diagnostic checks

1. Confirm the exact HTTP status – capture the response with browser dev‑tools or curl -v -F "files=@test.pdf" https://mattermost.example.com/api/v4/files. Note the status code and any JSON error body.
2. Inspect server logs – on the Mattermost host (requires root or the service account):

   grep -i -e 'upload' -e 'file size' -e 'multipart' /var/log/mattermost/mattermost.log | tail -30

   Look for the log lines shown in the table above.
3. Verify the configured upload ceiling – in config.json (or System Console → Environment → File Storage):

   "FileSettings": {
     "MaxFileSize": 52428800,
     "EnableFileAttachments": true,
     "DriverName": "local"
   }

   MaxFileSize is in bytes (50 MB in the example). Also check per‑channel overrides via ChannelSettings.MaxFileSize if set.
4. Test the threshold – create a file just under the limit and one just over it:

   dd if=/dev/zero of=under.bin bs=1M count=49   # 49 MB
    dd if=/dev/zero of=over.bin  bs=1M count=51   # 51 MB
    curl -v -F "files=@under.bin" https://mattermost.example.com/api/v4/files
    curl -v -F "files=@over.bin"  https://mattermost.example.com/api/v4/files

   The under‑limit file should return 201; the over‑limit file should return 413 with a matching log entry.
5. Check storage health – run df -h /var/opt/mattermost/data (or the mount point used by the file driver). Ensure at least 10 % free space and no inode exhaustion (df -i).
6. Validate Postgres connectivity – from the Mattermost host:

   psql "postgres://mmuser:password@dbhost:5432/mattermost?sslmode=disable" -c "SELECT 1;"

   Watch for too many clients or timeout errors that appear only under load.
7. Review TLS / proxy timeouts – if a reverse proxy (nginx, HAProxy, AWS ALB) sits in front, verify client_max_body_size (nginx) or equivalent is ≥ MaxFileSize and that proxy read/write timeouts exceed the expected upload duration (e.g., 300 s).

Fixes tied to findings

• 413 – limit too low: increase FileSettings.MaxFileSize in config.json (or via System Console) and restart Mattermost (systemctl restart mattermost). Ensure the reverse proxy allows the same size.
• 500 – disk full: free space on the storage volume, then restart Mattermost. If using S3 driver, verify bucket quota and IAM permissions.
• 500 – Postgres pool exhaustion: raise SqlSettings.MaxOpenConns and MaxIdleConns in config.json (typical values 30/10 for medium instances) and restart.
• 500 – TLS / proxy timeout: adjust proxy timeouts (nginx: proxy_read_timeout 300s; proxy_send_timeout 300s;) and reload the proxy.
• 403 – file‑type block: add the missing MIME type to FileSettings.AllowedFileTypes (comma‑separated list) or set "AllowAnyFileType": true temporarily for testing.
• 400 – multipart parse error: ensure the client sends proper multipart/form-data with a files field; if using a custom client, match the field name exactly.

Escalation criteria

Escalate to the platform team or Mattermost support when:

• All configuration limits are correct, storage and DB are healthy, yet 500 persists on files < 10 MB.
• Log entries show panic or stack traces from the Go runtime.
• Multiple unrelated services (e.g., websocket, search) degrade simultaneously, indicating a host‑level issue.

Limitations & verification

This guide covers server‑side configuration and infrastructure causes. Client‑side network throttling, antivirus interference, or browser‑specific multipart bugs are out of scope. After applying a fix, verify by uploading a file at 90 % of the new limit and confirming a 201 Created response and a log line "msg":"file uploaded".
