Diagnosing LDAP Authentication Failures in Forgejo: A Step‑by‑Step Guide

Recognizable condition

When a user tries to log in with LDAP credentials, Forgejo shows an "Invalid credentials" message and the Forgejo log contains LDAP‑related errors such as:

• LDAP bind failed: Invalid credentials
• LDAP search error: No such object
• TLS handshake failure
• Group lookup failed

The exact log location is set by the [log] section in app.ini (default log/forgejo.log). If you have overridden ROOT_PATH or LOG_ROOT_PATH, adjust the path accordingly.

Short cause/diagnostic table

Possible cause	Typical symptom in logs
Network unreachable / wrong host/port	Connection timed out or refused
Incorrect bind DN or password	LDAP bind failed: Invalid credentials
Search base DN does not contain user entries	LDAP search error: No such object
Attribute mapping mismatch (e.g., uid vs sAMAccountName)	User entry found but username/email empty
TLS/SSL trust issues (self‑signed cert, hostname mismatch)	TLS handshake failure or certificate verify failed
Malformed group filter or missing memberOf/uniqueMember support	Group lookup failed or empty group list

Ordered checks

1. Verify network reachability

   From the Forgejo host, test TCP connectivity to the LDAP server.

   # Replace placeholders with actual values
   nc -zv <ldap-host> <ldap-port>

   Required permission: ability to run network utilities (usually any user). Expected check: "Connection to <ldap-host> <ldap-port> port [tcp/*] succeeded!". Risk: none.

2. Test LDAP bind with correct credentials

   Use ldapsearch to confirm the bind DN and password work.

   ldapsearch -x -H ldap://<ldap-host>:<ldap-port> \
     -D '<bind-dn>' -w '<bind-password>' -b '<search-base>' \
     '(objectClass=*)' dn

   Required permission: read access to the LDAP directory (as defined by bind DN). Expected check: returns at least one entry without error. Risk: exposing the password in shell history; mitigate by using a temporary file or environment variable.

3. Confirm user entry exists under the search base

   Search for a specific user using the attribute Forgejo expects for login (e.g., uid or sAMAccountName).

   ldapsearch -x -H ldap://<ldap-host>:<ldap-port> \
     -D '<bind-dn>' -w '<bind-password>' -b '<search-base>' \
     '(<login-attribute>=<username>)' dn

   Replace <login-attribute> with the attribute configured in Forgejo (uid, sAMAccountName, etc.). Expected check: returns the user’s DN. Risk: none.

4. Validate attribute mapping

   Ensure the Forgejo LDAP configuration maps the correct LDAP attributes to username, email, and full name.

   Check app.ini (or environment variables/Docker secrets) for sections like:

   [auth.ldap]
   ENABLED = true
   HOST = <ldap-host>
   PORT = <ldap-port>
   USE_SSL = false
   START_TLS = false
   BIND_DN = <bind-dn>
   BIND_PASSWORD = ${LDAP_BIND_PASSWORD}
   BASE_DN = <search-base>
   FILTER = (<login-attribute>=%s)
   USERNAME_ATTRIBUTE = <login-attribute>
   EMAIL_ATTRIBUTE = mail
   FIRST_NAME_ATTRIBUTE = givenName
   LAST_NAME_ATTRIBUTE = sn


   Verify that the values match the directory schema. Expected check: after a test login, Forgejo logs show the retrieved attributes. Risk: mis‑mapping can create duplicate accounts.

5. Test TLS/SSL trust (if using LDAPS or STARTTLS)

   Check that the Forgejo host trusts the LDAP server’s certificate. Add SNI handling if the LDAPS server expects it.

   openssl s_client -connect <ldap-host>:<ldap-port> -showcerts -servername <ldap-host>

   Look for "Verify return code: 0 (ok)". If the certificate is self‑signed, add the CA to the system trust store or set SSL_CERT_FILE in the Forgejo environment. Required permission: ability to run openssl and read certificate files. Risk: none.

6. Verify group filter / memberOf configuration

   If groups are used for authorization, test the group lookup. Directories without the memberOf overlay can use a uniqueMember filter instead.

   ldapsearch -x -H ldap://<ldap-host>:<ldap-port> \
     -D '<bind-dn>' -w '<bind-password>' -b '<group-base>' \
     '(<group-filter>)' dn

   Replace <group-base> and <group-filter> with the values from Forgejo’s LDAP group settings. Expected check: returns the groups the user belongs to. Risk: none.

Fixes tied to findings

• Network issue: Correct host/IP, port, or firewall rules; ensure the Forgejo host can reach the LDAP server. Also verify outbound SELinux/AppArmor policies (e.g., setsebool -P httpd_can_network_connect 1 on SELinux systems).
• Bad bind credentials: Update BIND_DN and BIND_PASSWORD (prefer environment variable or Docker secret). Restart Forgejo for the change to take effect.
• Wrong search base: Adjust BASE_DN to an OU that contains the user entries.
• Attribute mapping mismatch: Change USERNAME_ATTRIBUTE, EMAIL_ATTRIBUTE, etc., to match the directory schema.
• TLS trust failure: Install the LDAP server’s CA certificate on the Forgejo host, or disable TLS only for testing (not recommended for production). Ensure SNI is supplied if required.
• Group filter error: Correct the FILTER or GROUP_FILTER syntax; if the directory lacks memberOf, use a filter that checks uniqueMember on the group object.

Escalation criteria

If after performing all checks the login still fails:

1. Enable debug logging for LDAP in Forgejo ([log] LEVEL = Debug) and reproduce the failure; examine the detailed trace in the log file (default log/forgejo.log or the path you configured).
2. Consult the LDAP server logs (requires directory admin access) to see whether the request reached the server and why it was rejected.
3. Use a simple bind test tool (e.g., ldapwhoami -x -D '<bind-dn>' -w '<bind-password>' -H ldap://<ldap-host>:<ldap-port>) to isolate whether the problem is client‑side or server‑side.
4. If the issue persists, contact your directory service administrator with the exact bind DN, search base, and filter being used.
