Diagnosing Lag on Source Engine Servers: Reading net_graph Choke, Loss, sv, and var

The recognizable condition

Players on your srcds server (CS:S, TF2-class Source titles) report rubber-banding, delayed hit registration, or shots that "should have hit." Ping looks normal. The instinct is to blame the host, but the useful first step is reading net_graph on an affected client and the server console stats output at the same moment. Four values do most of the diagnostic work:

• choke — updates the server wanted to send but couldn't, usually because a rate limit capped the bandwidth. Choke points at configuration, not hardware.
• loss — packets that never arrived. Loss points at the network path or an overloaded server dropping traffic.
• sv — the server's frame time (how long the last simulation tick took, in ms).
• var — variance in that frame time. High var means the server tick is unstable even if average sv looks fine.

Note that net_graph layout and field names differ between Source branches and games. Confirm the fields on your specific title before trusting a label; the underlying concepts (choke, loss, server frame time) are consistent.

Cause table

Ordered checks

1. Confirm the server's real tickrate and stability. In the server console (or via RCON), run stats and watch CPU and FPS over a minute of live play. Tickrate is fixed per game build (commonly 64, or 128 where the title supports it) and cannot be changed at runtime — verify what you actually have rather than trusting the listing.
2. Capture sv/var on an affected client. Have the player enable net_graph during symptoms and note whether var spikes coincide with the rubber-banding. Screenshotting both net_graph and the server stats output at the same moment lets you correlate the two views.
3. Compare client rates against server clamps. Client cvars are clamped by sv_minrate/sv_maxrate and sv_maxupdaterate, so a client raising rate may have zero effect. Check the server values first, then align clients to them. A mismatched cl_updaterate silently caps effective update frequency no matter how much bandwidth is available.
4. Remove the network path. Connect a client from the same LAN or host. If choke and loss vanish locally while sv/var stay flat, the server is healthy and the problem is between host and players.
5. Profile the path. During symptoms, run a continuous ping and traceroute/mtr from an affected player's connection to the server IP. Loss appearing at the first hop is the player's ISP; loss appearing only at the final hops points at the hosting provider.

Fixes tied to findings

Universal choke: raise sv_maxrate (and check sv_maxupdaterate) in server.cfg, then restart the map and confirm with sv_maxrate in the console that the value took effect. If only some players choke, fix their client rates to sit inside the server's min/max window instead.

var spikes: reproduce on a clean server — default config, no SourceMod plugins, one local client. Third-party plugins are a frequent cause of tick variance, so reintroduce plugins one at a time until var returns. If var spikes persist on a clean server with confirmed CPU headroom, suspect the hardware or virtualization layer (shared CPU steal on a cheap VPS is a common culprit).

loss with healthy server metrics: this is not fixable in config. Take your traceroute evidence to the host and ask about routing/peering changes, or test a server in a different location.

Escalation criteria

Escalate to the hosting provider when either is true: (1) var spikes persist after plugin removal and you've confirmed CPU headroom, indicating a hardware or hypervisor problem; or (2) loss is reproducible from multiple players on different ISPs, indicating a provider-side network fault. In both cases, attach the captured stats output and traceroute logs — "it feels laggy" tickets get deprioritized, correlated evidence does not.

Limitations and verification

These readings are per-moment snapshots; a single capture can mislead. Always correlate client net_graph with server stats at the same instant, and prefer the A/B approach (clean server, one variable reintroduced at a time) over changing three cvars at once. Behavior described here reflects established Source engine networking; field names and default rate limits vary by game and branch, so verify against your title's console before documenting values for your community.
