Diagnosing k3OS Automatic OS Upgrade Failures on Bare‑Metal Clusters

Recognizable Condition

After a scheduled k3OS upgrade, nodes fail to reboot into the new OS version, remain on the old release, or show a kernel panic during boot.

Cause/Diagnostic Table

Symptom	Likely Cause
k3os-upgrade service inactive or failed	Service did not start; upgrade process never began
Download timeouts in logs	Network connectivity to upgrades.rancher.com blocked
"No space left on device" messages	Insufficient free space on /var/lib/k3os for image extraction
YAML syntax error in cloud‑config	Malformed user‑data causing upgrade script abort
Kernel panic after reboot	Incompatible drivers or missing firmware for hardware

Ordered Checks

1. Verify the upgrade service state

   Run systemctl status k3os-upgrade as root. Look for active (exited) or failed. If the unit is inactive or shows a failure, note the error message.

2. Inspect the upgrade log

   Examine /var/log/k3os-upgrade.log for tracebacks, HTTP errors, or space‑related messages. Use journalctl -u k3os-upgrade --no-pager as an alternative.

3. Test outbound HTTPS to the upgrade server

   From the node, run curl -v https://upgrades.rancher.com/v1. A successful response returns HTTP 200 and a JSON payload. Note any connection timeout, TLS handshake failure, or HTTP error codes.

4. Check free space on the upgrade partition

   Execute df -h /var/lib/k3os. Ensure at least 2 GB of free space is reported. If the usage is >80 % or free space <2 GB, the upgrade cannot extract the new image.

5. Validate the cloud‑config user‑data

   If the node uses a custom cloud‑config, retrieve the current user‑data (often stored in /var/lib/rancher/k3s/server/manifests or provided via DHCP). Run a YAML linter such as yamllint or an online validator. Look for indentation errors, forbidden keys, or missing required fields.

6. Review hardware compatibility

   If logs indicate a kernel panic, compare the kernel version in the new release with the hardware’s driver/firmware requirements. Check dmesg output after a failed boot for messages like Unable to handle kernel paging request or request_firmware failed.

Fixes Tied to Findings

• Service not starting – Enable and start the unit: systemctl enable --now k3os-upgrade. If the unit file is missing, reinstall the k3os package (apk add --upgrade k3os) on the node.
• Network blockage – Ensure outbound TCP 443 to upgrades.rancher.com is allowed. Adjust firewall rules or proxy settings. Verify DNS resolution with nslookup upgrades.rancher.com.
• Insufficient disk space – Clean the upgrade partition: remove old cached images (rm -rf /var/lib/k3os/*) or expand the partition if using LVM. After freeing space, restart the upgrade service.
• Cloud‑config syntax error – Correct the YAML, then reapply the configuration (e.g., via ros config set or by updating the user‑data source and triggering a reconfigure). After correction, trigger the upgrade again with systemctl restart k3os-upgrade.
• Kernel panic / driver mismatch – Boot into the previous working kernel (often available via the GRUB entry), then either:
  • Upgrade firmware/drivers on the hardware, or
  • Pin the k3OS version to a known‑good release by setting K3OS_UPGRADE_ENABLED=false in /etc/rancher/k3os/config.yaml until compatibility is verified.

Escalation Criteria

Proceed to escalation when:

• The upgrade service repeatedly fails after applying the above fixes and logs show persistent "internal server error" or "502 Bad Gateway" from the upgrade endpoint.
• Disk space cannot be freed because the partition is at its maximum size and resizing is not possible without reinstall.
• Kernel panic persists after firmware updates and the hardware is not listed in the k3OS hardware compatibility matrix for the target version.
• Multiple nodes in the cluster exhibit the same failure pattern, suggesting a systemic issue with the upgrade server or network path.

In these cases, collect the following data before contacting Rancher support or the community:

• Output of systemctl status k3os-upgrade and journalctl -u k3os-upgrade
• Contents of /var/log/k3os-upgrade.log
• Result of curl -v https://upgrades.rancher.com/v1
• Output of df -h /var/lib/k3os and lsblk
• Current cloud‑config/user‑data YAML
• Hardware model, BIOS/firmware versions, and output of dmesg from a failed boot.
