Diagnosing Jasmine done() Timeout Failures in Asynchronous Specs

Recognizable condition

When a Jasmine spec that contains asynchronous code (e.g., setTimeout, Promise, XHR/fetch) finishes with a timeout error like Error: Timeout - Async callback was not invoked within timeout specified by jasmine.DEFAULT_TIMEOUT_INTERVAL or appears to hang indefinitely, the most common cause is that the done callback was not invoked exactly once.

Cause / diagnostic table

Observed symptom	Likely cause
Spec times out after default interval	done() never called (missing in success or error path)
Spec fails with "done() called more than once"	done() invoked in both success and error handlers, or inside a finally block without guarding
Spec passes but assertions run too early	done() called before the asynchronous operation resolves
Spec hangs when using async/await together with done()	Mixed styles cause Jasmine to wait for both a promise and done()

Ordered checks

1. Verify the spec function signature – Open the spec file and confirm the it (or describe) callback declares a parameter, typically named done:

   it('should fetch data', function(done) {
     // async work
   });


   If the parameter is missing, Jasmine treats the spec as synchronous and will timeout on any async work.
2. Trace every asynchronous path – For each async API used (e.g., setTimeout, Promise.then, xhr.onreadystatechange), ensure there is exactly one call to done() in the success handler and, if error handling is needed, one call in the error handler. Look for stray calls in finally blocks or outside the async callbacks.
3. Confirm placement after resolution – The done() call must appear after the async operation has settled. For a Promise, place it inside .then and .catch (or finally with a guard). For timer‑based code, call done() after the timeout elapses.
4. Check for duplicate invocations – Search the spec for more than one occurrence of done() that could be reached on the same execution path. A common duplicate is calling done() both in .then and in a finally block that runs regardless of outcome.

Fixes tied to findings

Missing done()

Add the callback in every path that finishes the async work:

it('resolves a promise', function(done) {
  fetch('/api/data')
    .then(response => response.json())
    .then(data => {
      expect(data.value).toBe(42);
      done();
    })
    .catch(err => {
      fail(err); // optional: mark spec as failed
      done();
    });
});

Done() called multiple times

Wrap the call in a guard or use a flag to ensure it runs once:

it('handles success and error', function(done) {
  let called = false;
  const finish = () => {
    if (called) return;
    called = true;
    done();
  };
  someAsyncOp()
    .then(result => {
      expect(result).toBeTruthy();
      finish();
    })
    .catch(err => {
      fail(err);
      finish();
    });
});

Done() before async completes

Move the call inside the resolution handler, not before the async invocation:

// WRONG
it('wrong placement', function(done) {
  done(); // too early
  setTimeout(() => { /* ... */ }, 100);
});

// CORRECT
it('correct placement', function(done) {
  setTimeout(() => {
    expect(true).toBeTrue();
    done();
  }, 100);
});

Prefer returning a promise (Jasmine 2.0+)

If you are on Jasmine ≥2.0, you can avoid done() entirely by returning a promise:

it('returns a promise', function() {
  return fetch('/api/data')
    .then(r => r.json())
    .then(data => {
      expect(data.id).toBeDefined();
    });
});

This style eliminates the risk of missing or duplicate done() calls.

Using Jasmine clock for timer‑based code

For specs that rely on setTimeout or setInterval, install the mock clock:

beforeEach(function() {
  jasmine.clock().install();
});

afterEach(function() {
  jasmine.clock().uninstall();
});

it('advances timer', function(done) {
  setTimeout(() => {
    expect(true).toBeTrue();
    done();
  }, 200);
  jasmine.clock().tick(201); // moves time forward
});

Escalation criteria

• If after applying the above fixes the spec still times out, verify that any external mocks (e.g., fetch-mock, axios-mock-adapter) are correctly resolving or rejecting.
• Check the version of Jasmine in use (jasmine --version). Versions prior to 2.0 have limited promise support; upgrading to a recent release (≥3.6) improves async handling.
• When the spec involves complex asynchronous coordination (multiple promises, race conditions), consider refactoring the test to use async/await with a returned promise, or split the spec into smaller, focused units.
• If the problem persists despite correct done() usage and upgraded Jasmine, flag the test for review by the lead engineer or the team’s testing champion.

Practical verification

Run the spec with Jasmine’s verbose flag to see the execution flow:

# Run from the project root
jasmine spec/myAsyncSpec.js --verbose

Look for output lines like:

Spec ... passed – indicates the spec completed without timeout.
Spec ... failed: Error: Timeout - Async callback was not invoked – points to a missing done().
Spec ... failed: Error: done() called more than once – indicates duplicate invocation.

As a quick sanity check, temporarily replace the async call with a synchronous stub:
it('stubbed version', function(done) {
  // replace setTimeout / fetch with immediate value
  expect(true).toBeTrue();
  done();
});

If the stubbed spec passes instantly, the original timeout is due to the async handling, not the assertions.

Limitations
This guide assumes the spec uses Jasmine’s built‑in done mechanism. If you are using third‑party async matchers (e.g., jasmine‑promise) or a custom test runner, the exact steps may differ. Always consult the documentation of the specific matcher or runner for equivalent verification methods.
