Diagnosing Invalid Opcode or Out‑of‑Gas Errors in Hardhat Network Forks

Recognizable Condition

When running tests against a Hardhat Network fork, transactions that interact with a deployed contract revert with either invalid opcode or out of gas. The same call succeeds on the live mainnet.

Cause / Diagnostic Table

Possible Cause	What to Look For
Fork block is older than the contract’s deployment block	Check forking.blockNumber in hardhat.config.js; compare with the transaction block where the contract was created.
Required storage slots were modified after the fork point	Identify storage reads the contract performs (e.g., via sload) and verify whether those slots changed after the fork block.

Ordered Checks

1. Confirm the fork block number
   1. Open hardhat.config.js and locate the forking section.
   2. Note the value of blockNumber (or blockHash if used).
2. Find the contract’s deployment block
   1. Using a block explorer (e.g., Etherscan) or hardhat network provider, retrieve the transaction that created the contract.
   2. Record its block number (deploymentBlock).
3. Compare
   1. If forking.blockNumber < deploymentBlock, the fork is missing the contract’s bytecode and storage.
   2. If equal or greater, proceed to check storage slots.
4. Inspect storage‑dependent logic
   1. Identify any sload operations the contract performs (via source code or hardhat trace).
   2. For each storage slot, query its value at the fork block:

      hardhat.network.provider.send('hardhat_getStorageAt', [contractAddress, slotNumber, 'latest'])

   3. Compare with the value at a later block (e.g., deploymentBlock + 100) to see if it changed after the fork.

Fixes Tied to Findings

• Update the fork block
  1. Set forking.blockNumber to a block that is >= deploymentBlock and includes all relevant state‑changing transactions.
  2. Example configuration:

     module.exports = {
       solidity: '0.8.20',
       networks: {
         hardhat: {
           forking: {
             url: 'https://mainnet.infura.io/v3/',
             blockNumber: 19000000   // replace with a recent block
           }
         }
       }
     };

• Mock missing storage
  1. If moving the fork forward is not feasible (e.g., RPC limits), inject the required storage values:

     await hardhat.network.provider.send('hardhat_setStorageAt', [
       contractAddress,
       '0x0', // slot number as hex
       hardhat.ethers.utils.hexZeroPad('0x0000000000000000000000000000000000000000000000000000000000000001', 32) // example value
     ]);

• Re‑fork at a newer block
  1. Stop the current Hardhat node, update the config as shown above, and restart.

Escalation Criteria

If after adjusting the fork block and/or mocking storage the transactions still revert with invalid opcode or out of gas:

• Isolate the test to a pure Hardhat Network (no forking) using mock contracts or fixtures to confirm the issue is fork‑specific.
• Collect the following data and open an issue in the Hardhat repository:
  • Hardhat version (npx hardhat version)
  • Fork block number and RPC endpoint used
  • Contract address and ABI (or source)
  • Full error trace (hardhat network logs with --show-stack-traces)

Verification

1. Run a simple read‑only test that queries a known storage slot (e.g., totalSupply of an ERC‑20) before and after changing the fork block; the value should match the block explorer’s reading at that block.
2. Confirm the node is on the expected block with:

   hardhat.network.provider.send('hardhat_getBlockByNumber', [forkBlockNumber, false])

3. If you mocked storage, verify the slot reads the mocked value:

   hardhat.network.provider.send('hardhat_getStorageAt', [contractAddress, slot, 'latest'])
