Diagnosing invalid_grant on OAuth Refresh in Public Clients

Your app uses Authorization Code with PKCE. Login works. A day later, API calls return 401 and the token endpoint answers invalid_grant. The useful takeaway: invalid_grant comes from two different grants, and in public clients most occurrences trace to local token state, a lost PKCE verifier, or a configuration mismatch rather than a broken authorization server. Work the checks below in order before opening a ticket.

Separate the two grants that return invalid_grant

RFC 6749 defines invalid_grant at the token endpoint generally. In practice you see it from the authorization_code exchange and from the refresh_token grant, and they have different causes. If the failure happens on the first exchange after the browser redirect, PKCE verifier handling is in scope. If login succeeded and a refresh token is stored, you are in refresh territory, and code_verifier is not the parameter to inspect.

Keep invalid_client separate as well. That error points at client authentication: a client_id mismatch, or a public client sending a client_secret it should not have. The fix is different.

Cause table

Symptom pattern	Likely cause	First check
First refresh fails, then every retry fails	Rotation reuse detection: an old refresh token was replayed	Whether two processes or devices share one stored token
Fails only after app restart or backgrounding	Refresh token not persisted, or stored in ephemeral storage	Where the token is written and when
Fails on the first exchange after redirect	PKCE code_verifier lost when the app was killed	Whether the verifier is persisted before the browser opens
invalid_client instead of invalid_grant	client_id mismatch or unexpected secret	Client registration and request body
Fails after a device time change	Clock skew against server-issued expiry claims	Local time versus the token endpoint's Date header
Affects specific users only	Server-side revocation or expiry for those accounts	Authorization server audit events

Ordered checks

1. Identify the failing grant. Inspect the request body your app sends: grant_type=authorization_code or grant_type=refresh_token. Run this from app logs or a local proxy on a test build, and redact tokens before sharing logs.
2. Confirm you hold the current refresh token. With rotation enabled, the server may invalidate the previous token once a new one is issued. If two processes read the same keychain or keystore entry, one will replay an old value. Check that storage has a single writer and that each new token is written atomically before the old one is discarded.
3. Check the token request parameters. A public-client refresh normally needs grant_type, refresh_token, and client_id. Per RFC 6749 section 6, redirect_uri is required only if it was included in the original authorization request. Do not send code_verifier here; it belongs to the code exchange.
4. Compare clocks. Run date -u on the device and compare it with the Date response header from the token endpoint. A skew of more than a few tens of seconds is a common heuristic threshold, but the exact tolerance and leeway are server-specific.
5. Read the server's reason. Authorization server logs usually distinguish reuse detection, revocation, expiry, and policy change. If you cannot see them, ask the identity provider administrator for the specific error_description or audit event rather than guessing.
6. Check scope. If the refresh request includes scope, it must not contain scopes that were not originally granted; that case typically returns invalid_scope, not invalid_grant. Requesting minimal scopes at authorization time avoids the situation.

A refresh request to compare against

Run this from a development machine against a test account. You need a valid refresh token and the public client's client_id. Risk: shell history and terminal logs capture the token, so use an environment variable and unset it afterwards. This is a template, not a tested transcript.

export REFRESH_TOKEN='<test-account-refresh-token>'
curl -sS -X POST 'https://<issuer>/oauth2/token' \
  -H 'Content-Type: application/x-www-form-urlencoded' \
  -d 'grant_type=refresh_token' \
  -d "refresh_token=${REFRESH_TOKEN}" \
  -d 'client_id=<public-client-id>'
unset REFRESH_TOKEN

Expected check: a success response carries access_token and token_type; whether it also carries a new refresh_token depends on the server's rotation policy. A failure carries error and usually error_description. Compare the actual shape with your provider's documented response instead of assuming it.

Fixes tied to what you found

• Reuse detected: discard the entire local token set and force interactive re-authentication. Retrying the old token will keep failing.
• redirect_uri mismatch: use the exact registered URI, including trailing-slash consistency, wherever the parameter is required.
• Clock skew: sync device time and add a small leeway to local expiry checks so you refresh slightly early rather than after the server considers the token dead.
• Lost code_verifier: persist the verifier keyed by state before opening the browser. If it is gone, restart the authorization; there is no way to reconstruct it.
• Expired or revoked refresh token: implement silent re-authentication. If the token lifetime is shorter than your background interval, this is expected behavior.
• Scope mismatch: request only the scopes you need at authorization time.

Escalation criteria

Escalate to the identity provider when invalid_grant persists after a clean re-authentication with a fresh client, when several unrelated clients lose tokens at the same time, or when audit logs show a server-side policy or rotation change. Escalate internally when token storage is unencrypted, shared across users, or written by more than one process.

Limitations and how to verify

Rotation behavior, reuse-detection windows, and clock tolerance are implementation-specific. This guide assumes RFC 6749 and RFC 7636 behavior without vendor extensions, and PKCE assumptions apply to public clients. Verify by reproducing the failure with a controlled refresh using the same client_id and redirect_uri, comparing local timestamps against the token's iat and exp with the measured clock offset, then clearing stored tokens and completing a fresh authorization to confirm the failure disappears. Clearing tokens changes local state; the rollback is simply re-authenticating. Because provider behavior changes, confirm current details against your authorization server's documentation before changing production configuration.
