Diagnosing Grafana Alert Rules That Fail to Fire

Recognizable condition

You have configured an alert rule in Grafana, but the rule never enters the firing state even though the underlying metric clearly satisfies the condition (e.g., CPU usage > 80 %). No notifications are sent, and the rule appears inactive in the alert list.

Common causes and quick diagnostic table

Symptom	Likely cause	Where to look
Rule does not appear in the Alerting > Rules list	Rule failed to load (YAML syntax error, missing query/condition)	Grafana UI > Alerting > Rules; check for error banners
Rule shows “No data” or “Error” state	Underlying query returns no results or times out	Alert rule > Evaluation tab; inspect query output
Rule stays in “Pending” state longer than expected	Evaluation interval too long or ‘for’ duration exceeds interval	Alert rule > Condition tab; review interval and ‘for’ fields
Rule evaluates correctly but no notification arrives	Notification channel misconfigured, disabled, or silenced	Alerting > Notification channels; test channel; Alerting > Silences
Rule fires but history is missing after restart	Alert state storage backend lacks retention policy	Grafana configuration > alerting.storage; check backend (e.g., InfluxDB) retention

Ordered checks

1. Verify rule loading
   • Where: Grafana UI > Alerting > Rules
   • Permissions: Any user with Alerting Read access; admin needed to edit
   • Check: Look for a red error banner or “Failed to load” message.
   • Risk: None – read‑only operation.
2. Inspect rule definition
   • Where: Open the rule > click “Edit”
   • Permissions: Alerting Edit
   • Check: Ensure the query field references a valid data source and returns a numeric series; verify the condition operator (above, below, missing) matches intent.
   • Risk: None if you only view; editing incorrectly could break the rule.
3. Preview query results
   • Where: Alert rule > Evaluation tab
   • Permissions: Alerting Edit
   • Check: Select a recent time range (e.g., last 15 minutes) and press “Run”. Confirm that the query returns values and that the condition evaluates to true for at least one sample.
   • Risk: None – read‑only.
4. Check evaluation interval and ‘for’ duration
   • Where: Alert rule > Condition tab
   • Permissions: Alerting Edit
   • Check: Ensure the evaluation interval is ≤ the scraping interval of the data source (e.g., if Prometheus scrapes every 30 s, interval should be 30 s or multiples). Verify that the for duration is ≥ evaluation interval; a for shorter than the interval is ignored and may cause unexpected behavior.
   • Risk: Changing interval may increase load on the data source; test in a staging environment first.
5. Test notification channel
   • Where: Alerting > Notification channels > select channel > “Test”
   • Permissions: Alerting Admin (to edit channels) or Alerting Read (to run test if already configured)
   • Check: You should receive a test message (Slack, email, etc.). If the test fails, note the error (e.g., invalid webhook URL, authentication failure).
   • Risk: None – test only sends a message.
6. Look for active silencers
   • Where: Alerting > Silences
   • Permissions: Alerting Read
   • Check: Any silence that matches the rule’s labels will suppress notifications. Note the silence expiry.
   • Risk: None.
7. Verify alert state storage (if using external backend)
   • Where: Grafana configuration file (grafana.ini) > [alerting] section or via UI > Settings > Alerting > Storage
   • Permissions: Grafana Admin
   • Check: Confirm that enabled = true and a valid backend (e.g., InfluxDB, OpenTSDB) is configured. Then query the backend for recent alert state entries (e.g., SELECT * FROM alert_state WHERE time > now() - 1h).
   • Risk: Querying the backend may affect performance; use a limited time range.

Fixes tied to findings

• Rule failed to load – Correct YAML syntax: ensure required keys title, condition, query are present and properly indented. Reload the rule after saving.
• Query returns no data – Validate the data source query independently (Explore view). Adjust the query time range or add missing labels.
• Evaluation interval mis‑set – Set interval to a multiple of the data source scrape interval (e.g., 30s, 1m). Avoid intervals shorter than the scrape interval.
• ‘for’ duration too short/long – Set for to at least one evaluation interval; adjust based on desired alerting latency (e.g., 5 minutes for a 1 minute interval).
• Notification channel broken – Fix the channel configuration (correct webhook URL, credentials, enable the channel). Re‑run the test.
• Active silencer – Either delete the silence or wait for it to expire; ensure silences are applied only when intentional maintenance occurs.
• Missing alert state retention – Configure a retention policy on the backend (e.g., InfluxDB RETENTION POLICY \"alerts\" ON \"grafana\" DURATION 30d REPLICATION 1) and restart Grafana.

Escalation criteria

• After completing all checks, the rule still shows “No data” or “Error” despite a valid query in Explore.
• Notification channel tests succeed but alerts never transition to firing, even after reducing for to zero.
• Alert state storage backend shows no entries being written, indicating a deeper storage or plugin issue.

In these cases, enable Grafana debug logging ([log] level = debug) and reproduce the condition. Capture the logs around the alert evaluation timestamp and share them with Grafana support or the community, including Grafana version, data source type, and the exact alert rule YAML.

Example: CPU usage alert rule

# alert-rule.yaml
apiVersion: 1
groups:
  - name: system-metrics
    interval: 1m
    rules:
      - alert: HighCPUUsage
        expr: |
          avg by (instance) (rate(node_cpu_seconds_total{mode=\"system\"}[5m])) > 0.8
        for: 5m
        labels:
          severity: critical
        annotations:
          summary: \"CPU usage above 80% on {{ $labels.instance }}\"
          description: \"CPU has been above 80% for more than 5 minutes.\"

To verify this rule:

1. Import the YAML via Alerting > Rule management > Import.
2. Open the rule, go to the Evaluation tab, select the last 10 minutes, and run the query. You should see a time series with values > 0.8 when CPU is high.
3. Check that the interval is 1 m (matches Prometheus scrape) and the for is 5 m (≥ interval).
4. Test the notification channel (e.g., Slack) and confirm you receive a test message.
5. After waiting at least 5 minutes of sustained high CPU, the rule should move to firing state and trigger the notification.

Limitations and practical checks

• The evaluation interval cannot be shorter than the underlying data source’s scrape interval; otherwise the query will return stale or no data.
• The for field is ignored if it is less than the evaluation interval; Grafana treats it as zero, which may cause immediate firing.
• If using the default built‑in alerting storage (SQLite or MySQL), alert state is persisted locally; ensure the data directory is backed up and has sufficient disk space.
• Practical check: after any change, use the Evaluation tab to confirm the rule’s condition evaluates to true, then wait for at least one evaluation interval plus the for duration before expecting a notification.
