Diagnosing Carbon Event Manager Loop Failures in Legacy macOS Apps

A legacy Carbon app that freezes when it receives an Apple event, ignores menu clicks after a modal dialog, or silently drops high-level events almost always has a broken event loop — not broken handlers. The useful takeaway: in Carbon, events are only delivered if three things line up — the event mask you wait on, the handler you installed, and the loop actually yielding. A mismatch in any one produces a silent failure, because Carbon does not raise errors for undelivered events; they simply never arrive.

This guide applies to apps built against the Carbon Event Manager (HIToolbox), typically targeting macOS 10.4 through 10.14. Note upfront: Carbon UI APIs were deprecated in macOS 10.15 and are unsupported for new development. These diagnostics are for maintaining existing 32-bit-era or legacy 64-bit Carbon code, and behavior on current macOS versions should be verified on the oldest OS you still support.

Recognizable conditions

Start by matching what you observe to a symptom class:

• Apple events arrive but nothing happens. The app logs nothing, the handler never runs, and there is no error returned to the sender.
• The UI freezes for seconds at a time, then catches up in a burst — queued clicks and keys replay all at once.
• Some event types work and others never fire, even though handlers are installed for both.
• The app hangs only while a modal dialog or menu is open.

Cause and diagnostic table

Ordered checks

Work through these in order; each is cheap and rules out a layer.

1. Confirm the wait mask covers what you expect. Find the central loop call, e.g. ReceiveNextEvent(0, NULL, kEventDurationForever, true, &event). A zero type list means all event classes — that is usually what you want. If you instead use the classic GetNextEvent/WaitNextEvent, verify the mask includes kHighLevelEventMask; without it Apple events are never pulled from the queue.
2. Confirm receipt dispatches to the handler. In a classic loop, a high-level event must be passed to AEProcessAppleEvent (older code: ProcessHighLevelEvent). In a Carbon Event Manager loop, SendEventToEventTarget must target the dispatcher or an object with the right handler installed.
3. Audit every InstallEventHandler call. Each takes an array of EventTypeSpec — a class/kind pair such as { kEventClassAppleEvent, kEventAppleEvent }. A handler installed for kEventClassCommand will never see an Apple event, and Carbon gives no warning.
4. Check for starvation. Time one loop iteration. If any iteration can exceed roughly 100 ms of synchronous work, pending user and high-level events queue up and the UI appears frozen. Break the work up or move it off the main thread.
5. Check modal paths separately. Menu tracking and modal dialogs run their own nested loops. Handlers installed only on a window target may not be reachable during modality; blocking sleeps in a modal filter stall control redraws.

Fixes tied to findings

Missing mask coverage: widen the mask. For the classic loop:

// Classic loop: must include high-level events or Apple events never arrive
EventRecord event;
WaitNextEvent(everyEvent, &event, 0, NULL);  // not a hand-built partial mask
if (event.what == kHighLevelEvent)
    AEProcessAppleEvent(&event);  // requires Apple Event Manager handlers installed

Run this in the app's main thread; no special permissions are needed. The risk of switching from a narrow mask to everyEvent is that you now receive event types your loop doesn't handle — verify the dispatch chain has a default path that discards unknown events rather than spinning.

Handler never fires: correct the EventTypeSpec. Log the class and kind of undelivered events by installing a catch-all handler on the event dispatcher target and printing GetEventClass/GetEventKind for anything unexpected. Then register the handler for the pair you actually observed.

Starvation: pass a finite timeout (kEventDurationNoWait for polling plus a short sleep, or a small duration) instead of doing work inline, and chunk long tasks across iterations. Verify by logging the timestamp of each delivered Apple event in a test run; gaps over ~100 ms during load indicate remaining starvation.

Verification

Rebuild and send a known Apple event (for example an odoc open-documents event via AppleScript) while logging handler entry. Confirm the handler runs and the main loop continues processing input during delivery. For a broader audit, run nm or otool -L on the binary to list linked Carbon frameworks, and cross-reference the Carbon entry points you call against Apple's deprecation list before assuming behavior on newer macOS.

Escalation criteria

Stop patching the loop and escalate to a re-architecture discussion when: the app must run on macOS 10.15 or later as a primary target (Carbon UI is deprecated and increasingly fragile there); you find Carbon and Cocoa event loops interleaved in the same process, which commonly deadlocks or drops events and resists point fixes; or the event mask must cover custom or future event types you cannot enumerate — a sign the design depends on behavior Carbon never guaranteed. At that point the durable fix is migrating the event handling to AppKit, not another loop tweak.
