Diagnosing Blazor Server UI Freeze After Network Interruption

Recognizable condition

Users report that after a short network hiccup (e.g., Wi‑Fi toggle, VPN reconnect, or cellular drop) the Blazor Server UI stops responding or displays outdated values. In the browser console you may see repeated SignalR reconnection attempts, while server logs contain entries such as CircuitFailed or CircuitClientDisconnected. The page does not reload; instead the existing circuit is considered lost and a new circuit is created, causing any scoped services to lose their state.

Cause / diagnostic table

Observed symptom	Likely cause	What to check
UI freezes or shows stale data after network drop	SignalR circuit not reconnected within DisconnectedCircuitMaxRetry attempts; server disposes the circuit and creates a new one	Enable Blazor server‑side logging at Debug level; look for CircuitFailed or CircuitClientDisconnected messages and note the time between disconnect and reconnect attempts
Repeated reconnect attempts in browser console but UI never recovers	Client‑side SignalR retry delay too short or server‑side retry limits exhausted	Inspect browser console for signalr: Connection disconnected with error and subsequent Attempting to reconnect logs; compare timestamps with server logs
Scoped service values reset (e.g., a counter returns to zero)	New circuit creates fresh DI scope; previous scoped instances are lost	Verify that a scoped service (e.g., ICounterService) holds a value before the drop and is reset after reconnection

Ordered checks

1. Enable detailed logging

   In appsettings.Development.json (or production equivalent) set:

   {
     "Logging": {
       "LogLevel": {
         "Default": "Information",
         "Microsoft.AspNetCore.Components.Server": "Debug"
       }
     }
   }

   Restart the application and reproduce the network drop.

2. Capture server‑side circuit events

   Implement a temporary CircuitHandler to log lifecycle events:

   public class DebugCircuitHandler : CircuitHandler
   {
       private readonly ILogger _logger;
       public DebugCircuitHandler(ILogger logger) => _logger = logger;
       public override Task OnConnectionUpAsync(Circuit circuit, CancellationToken cancellationToken)
       {
           _logger.LogInformation("Circuit {CircuitId} connected", circuit.Id);
           return base.OnConnectionUpAsync(circuit, cancellationToken);
       }
       public override Task OnConnectionDownAsync(Circuit circuit, CancellationToken cancellationToken)
       {
           _logger.LogWarning("Circuit {CircuitId} disconnected", circuit.Id);
           return base.OnConnectionDownAsync(circuit, cancellationToken);
       }
   }

   Register it in Startup.ConfigureServices:

   services.AddServerSideBlazor()
       .AddCircuitOptions(options => { /* defaults */ })
       .AddHubOptions<CircuitHub>(opts => {
           opts.AddFilter<DebugCircuitHandler>();
       });

   Review logs for the sequence: disconnect → reconnect attempts → circuit disposal.

3. Measure reconnection timing

   From the logs, note:

   • Time of CircuitClientDisconnected
   • Time of first reconnect attempt (client side)
   • Time when server logs show a new circuit ID (indicating disposal)

   If the interval exceeds the product of DisconnectedCircuitMaxRetry × DisconnectedCircuitRetryDelay, the server has given up.

4. Verify client‑side SignalR state

   Open browser dev tools → Network → filter by signalr. Look for:

   • A disconnect event followed by multiple POST negotiate or GET /blazor/hub requests.
   • If the requests stop after a few seconds, the client has exhausted its retries.

Fixes tied to findings

1. Adjust circuit retry options

If logs show the server disposed the circuit after a predictable number of retries, increase the allowed attempts or the delay between them.

services.AddServerSideBlazor()
    .AddCircuitOptions(options =>
    {
        // Default: MaxRetry = 10, RetryDelay = 2s
        options.DisconnectedCircuitMaxRetry = 20;   // try twice as long
        options.DisconnectedCircuitRetryDelay = TimeSpan.FromSeconds(5);
    });

This gives the client more time to recover from a transient drop before the server abandons the circuit.

2. Preserve scoped state across circuits

When increasing retries is insufficient (e.g., users experience longer outages), store scoped state in an external cache and rehydrate it on a new circuit.

Example: using Redis

1. Add the Redis cache package:

<PackageReference Include="Microsoft.Extensions.Caching.StackExchangeRedis" Version="8.0.0" />

2. Configure Redis in Program.cs:

var redisConnection = builder.Configuration.GetConnectionString("Redis");
builder.Services.AddStackExchangeRedisCache(options =>
{
    options.Configuration = redisConnection;
    options.InstanceName = "BlazorServer:";
});

3. Create a scoped service that reads/writes to Redis:

public class CounterService : ICounterService
{
    private readonly IDistributedCache _cache;
    private const string KeyPrefix = "counter:";
    public CounterService(IDistributedCache cache) => _cache = cache;
    public async Task GetValueAsync(string userId)
    {
        var bytes = await _cache.GetAsync(KeyPrefix + userId);
        return bytes != null ? BitConverter.ToInt32(bytes) : 0;
    }
    public async Task IncrementAsync(string userId)
    {
        var current = await GetValueAsync(userId);
        var next = current + 1;
        var bytes = BitConverter.GetBytes(next);
        await _cache.SetAsync(KeyPrefix + userId, bytes, new DistributedCacheEntryOptions
        {
            AbsoluteExpirationRelativeToNow = TimeSpan.FromHours(1)
        });
    }
}

4. Register it as scoped:

builder.Services.AddScoped<ICounterService, CounterService>();

5. In a component, inject ICounterService and call IncrementAsync on user actions. The value survives circuit recreation because it is persisted in Redis.

Limitations: Serialization overhead (only primitive or simple DTOs should be cached), and you must ensure thread‑safe access if multiple users share the same key. Avoid storing large object graphs; instead store IDs and reload heavy data from the primary data store.

3. Implement a custom CircuitHandler for state rehydration

If you prefer to keep the rehydration logic centralized, a custom CircuitHandler can load scoped state from Redis when a circuit comes up and store it when the circuit goes down.

public class StatePreservingCircuitHandler : CircuitHandler
{
    private readonly IDistributedCache _cache;
    private readonly IServiceScopeFactory _scopeFactory;
    private const string StatePrefix = "circuit-state:";
    public StatePreservingCircuitHandler(IDistributedCache cache, IServiceScopeFactory scopeFactory)
    {
        _cache = cache;
        _scopeFactory = scopeFactory;
    }
    public override async Task OnConnectionUpAsync(Circuit circuit, CancellationToken cancellationToken)
    {
        // Attempt to restore any scoped state stored for this circuit ID
        var bytes = await _cache.GetAsync(StatePrefix + circuit.Id, cancellationToken);
        if (bytes != null)
        {
            using var scope = _scopeFactory.CreateScope();
            var stateService = scope.ServiceProvider.GetRequiredService();
            await stateService.RestoreAsync(bytes, cancellationToken);
        }
        await base.OnConnectionUpAsync(circuit, cancellationToken);
    }
    public override async Task OnConnectionDownAsync(Circuit circuit, CancellationToken cancellationToken)
    {
        using var scope = _scopeFactory.CreateScope();
        var stateService = scope.ServiceProvider.GetRequiredService();
        var bytes = await stateService.CaptureAsync(cancellationToken);
        await _cache.SetAsync(StatePrefix + circuit.Id, bytes, new DistributedCacheEntryOptions
        {
            AbsoluteExpirationRelativeToNow = TimeSpan.FromMinutes(30)
        }, cancellationToken);
        await base.OnConnectionDownAsync(circuit, cancellationToken);
    }
}

Register the handler:

builder.Services.AddServerSideBlazor()
    .AddHubOptions<CircuitHub>(opts =>
    {
        opts.AddFilter<StatePreservingCircuitHandler>();
    });

Escalation criteria

• If increasing DisconnectedCircuitMaxRetry and DisconnectedCircuitRetryDelay does not reduce the frequency of CircuitFailed logs after realistic network throttling (e.g., Slow 3G, 50% packet loss), consider the client‑side network environment as the primary factor and advise users on improving connectivity.
• When scoped state must survive outages longer than the adjusted retry window (e.g., >30 seconds), the external‑cache approach is required. If introducing Redis adds unacceptable latency (>100 ms per read/write) or operational complexity, evaluate alternative durable storage (e.g., SQL Server, Cosmos DB) or accept full page reload as a fallback.
• If after implementing a custom CircuitHandler you still observe state loss, verify that the scoped service you are persisting is truly scoped (not singleton) and that the cache key is unique per user or per circuit. Mis‑scoped caching can cause cross‑user data leakage.

Practical verification

1. Reproduce the issue: open Chrome DevTools → Network → set throttling to Slow 3G, toggle the network offline/online, and perform a UI action (e.g., click a button that increments a counter).
2. Observe the browser console for SignalR reconnection attempts and the server logs for CircuitClientDisconnected followed by either a new circuit ID (indicating disposal) or a successful reconnect.
3. After applying a fix, repeat the steps and confirm:
• The counter retains its pre‑drop value without a full page reload.
• Server logs show no CircuitFailed entries and a single CircuitUp after reconnection.
• If using Redis, you can inspect the cache (e.g., REDISCLI GET BlazorServer:counter:<userId>) to see the persisted value.
