Diagnosing ARM64 Pointer Authentication Faults: SIGSEGV on Signed Pointers

Recognizable condition

A process suddenly crashes with SIGSEGV or an illegal‑instruction exception when it executes code that uses signed pointers (e.g., after loading a shared library, JIT‑compiled code, or returning from a signal handler). The fault often occurs on instructions such as AUTIASP, AUTIAZ, AUTDASP or AUTDAZ.

Cause / diagnostic table

Observed symptom	Likely cause
Fault address points to an AUT* instruction; ESR_EL1 shows ISS[24:0] = 0x0 (Pointer Authentication failure)	PAC key mismatch or corrupted pointer
Same fault after a context switch or thread migration	PAC keys not restored correctly (APIAKey/APIBKey)
Fault occurs even though the code never uses PAC instructions	PAC disabled in SCTLR_EL1 leading to silent corruption that later triggers a fault
Pointer value is not 16‑byte aligned when used with AUT*	Mis‑aligned pointer causes authentication failure

Ordered checks

1. Verify that Pointer Authentication is enabled for the current exception level.

   # Run at EL1 (kernel) or EL0 (userspace) with sufficient privilege to read system registers
   # Example for EL1 (requires root or CAP_SYS_RAWIO)
   mrs x0, SCTLR_EL1
   # Check bits: EnIA (bit 2), EnIB (bit 3), EnDA (bit 10), EnDB (bit 11)
   # If any of these bits are 0, PAC is disabled for that instruction type.


   Permissions: Root or a process with CAP_SYS_RAWIO (EL1) or running under a debugger with access to system registers (EL0). Risk: Reading registers is safe; no state change.

2. Read the PAC key registers to see whether they hold the expected values.

   # APIAKeyLo/Hi and APIBKeyLo/Hi (EL1)
   mrs x0, APIAKeyLo_EL1   # x0 = low 64 bits of APIAKey
   mrs x1, APIAKeyHi_EL1   # x1 = high 64 bits of APIAKey
   mrs x2, APIBKeyLo_EL1
   mrs x3, APIBKeyHi_EL1
   # Compare x0/x1/x2/x3 with the values known from the OS key‑management routine.


   Permissions: Same as step 1. Risk: None.

3. Examine the fault information captured in ESR_EL1 (or the userspace signal context).

   # From a signal handler or kernel oops dump:
   mrs x0, ESR_EL1
   # Extract ISS[24:0] (bits 0‑24) – if non‑zero indicates a PAC failure.
   # Also read FAR_EL1 to see the faulting address.
   mrs x1, FAR_EL1


   Permissions: Access to the fault context (kernel log, dmesg, or userspace sigaction with SA_SIGINFO). Risk: None.

4. Run a software PAC verification routine on a known‑good signed pointer.

   /* Compile with -mbranch-protection=pac-ret+leaf (or equivalent) */
   #include
   #include
   #include

   uint64_t sign_ptr(uint64_t ptr, uint64_t key_lo, uint64_t key_hi) {
       uint64_t signed_ptr;
       __asm__ volatile ("autiasp %0, %1, %2" : "=r" (signed_ptr) : "r" (ptr), "r" (key_lo), "r" (key_hi));
       return signed_ptr;
   }

   int main(void) {
       uint64_t key_lo = 0x;   /* replace with value from step 2 */
       uint64_t key_hi = 0x;
       uint64_t ptr = (uint64_t)main;          /* any code pointer */
       uint64_t signed_ptr = sign_ptr(ptr, key_lo, key_hi);
       /* Now authenticate – should not fault if keys match */
       __asm__ volatile ("autiasp %0, %0, %1" : : "r" (signed_ptr), "r" (key_lo) : "cc");
       printf("PAC verification succeeded\n");
       return 0;
   }


   Where to run: Userspace, compiled for AArch64. Permissions: None beyond normal execution. Risk: If keys are wrong the program will fault with SIGSEGV; this is expected and helps confirm the mismatch.

Fixes tied to findings

• If any of the EnIA/EnIB/EnDA/EnDB bits in SCTLR_EL1 are cleared, set them:

  mrs x0, SCTLR_EL1
  orr x0, x0, #(1 << 2)   /* EnIA */
  orr x0, x0, #(1 << 3)   /* EnIB */
  orr x0, x0, #(1 << 10)  /* EnDA */
  orr x0, x0, #(1 << 11)  /* EnDB */
  msr SCTLR_EL1, x0
  isb                     /* synchronize */


  Permissions: EL2/EL3 or a kernel module with write access to system registers. Risk: Enabling PAC may expose bugs in code that incorrectly signs pointers; test on a non‑production core first.

• If the PAC keys read in step 2 do not match the OS‑maintained values, restore them after a context switch:

  # Assuming the correct keys are stored in variables correct_lo/hi
  msr APIAKeyLo_EL1, correct_lo
  msr APIAKeyHi_EL1, correct_hi
  msr APIBKeyLo_EL1, correct_lo   /* many OSes use same key for A & B */
  msr APIBKeyHi_EL1, correct_hi
  isb


  Permissions: Privileged (EL2/EL3). Risk: Incorrect key values will cause immediate PAC faults on any signed pointer use.

• Recompile or regenerate the offending code with proper signing:

  • For userspace: gcc -mbranch-protection=pac-ret+leaf -o prog prog.c
  • For JIT: ensure the code‑emitter calls the platform’s PAC signing routine before emitting AUT* instructions.

  Permissions: Normal build environment. Risk: None beyond normal compilation.

• Replace corrupted pointers (e.g., reload the library, refresh function pointers).

  Permissions: Same as the application. Risk: None.

• If the fault persists on a specific core after the above steps, isolate that core and run the ARM PAC self‑test (if available) to check for hardware defect.

  # Example using a kernel self‑test module (requires CONFIG_ARM64_PAC_SELFTEST)
  echo 1 > /sys/devices/system/cpu/cpuX/pac_self_test
  # Check dmesg for pass/fail.


  Permissions: Root. Risk: Test may temporarily disable PAC on the core while running.

Escalation criteria

• Pointer Authentication faults continue on multiple cores after verifying SCTLR_EL1 bits and restoring keys.
• The software verification routine (step 4) fails even when using keys known to be correct from the OS key‑management source.
• Kernel logs show recurrent PAC fault ESR codes with varying fault addresses, suggesting systematic key corruption.
• Hardware self‑test reports failure on a core.

When any of the above occurs, escalate to the platform vendor or silicon provider with the collected ESR_EL1, FAR_EL1, SCTLR_EL1, and PAC key register values.
