Diagnosing ARM64 Memory Tagging Extension Faults on Linux and Android

Recognizable Condition

A process crashes with SIGSEGV (si_code=SEGV_MTEAERR) or SIGBUS (si_code=BUS_MTEAERR) on ARMv8.5-A or newer hardware (Neoverse N2/V1, Cortex-A710/X2/X3, Google Tensor G2+). Kernel logs show arm64_mte: asynchronous tag check fault or a synchronous fault at the program counter with ESR_ELx.ISS bits [5:0]=0b010101 (0x15), indicating a tag-check failure. These faults appear non-deterministically for asynchronous cases, often at an instruction unrelated to the actual memory error.

Cause and Diagnostic Reference

Symptom Pattern	Likely Cause	Fault Type	Typical Location
Crash at unrelated PC, tag mismatch in 16-byte granule	Heap buffer overflow or underflow	Asynchronous	Later load/store after corruption
Fault when freed memory reallocated with new tag	Use-after-free	Asynchronous	Access to dangling pointer
Synchronous fault on function prologue/epilogue	Stack tag mismatch (SP-relative access)	Synchronous	Stack frame setup/teardown
Sync fault on first access after dynamic loader runs	Global/data section tag mismatch	Synchronous	First use of global variable
Faults in legacy pointer arithmetic or integer-to-pointer casts	Top-byte ignore (TBI=0) or missing tag preservation	Either	Pointer manipulation code

Ordered Diagnostic Checks

1. Confirm MTE Is Enabled

Run on the target device (requires shell access, no special permissions):

cat /proc/cpuinfo | grep -i mte
# Expected: "Features" line includes "mte"

dmesg | grep -i mte
# Expected: "MTE enabled" or "arm64_mte: MTE enabled"

If absent, the CPU or kernel lacks MTE support. Minimum kernel: 5.17 for synchronous faults, 6.1+ for full asynchronous handling.

2. Inspect the Fault ESR

Extract the syndrome from kernel logs (requires dmesg access, typically root or CAP_SYSLOG):

dmesg -T | grep -A5 'tag check fault'
# Look for ESR_ELx value, e.g., ESR_EL1=0x96000015
# ISS[5:0] = 0x15 → synchronous tag check fault
# ISS[5:0] = 0x16 → asynchronous tag check fault
# Fault address = (ESR >> 12) & 0xFFFFFFFFF << 12

Decode manually if needed:

echo 'obase=16; ibase=16; 96000015' | bc
# Output: 15 → confirms synchronous tag check fault

3. Check VMA Tag State

Verify the faulting region is MTE-tagged (run as the process owner or root):

pmap -x
# Check permissions column for "mt" flag

cat /proc//smaps | grep -A2 'VmFlags:'
# "mt" in VmFlags indicates MTE-tagged VMA

4. Force Synchronous Faults for Precise Origin

Reproduce with synchronous mode to pinpoint the offending instruction (requires application restart):

LD_PRELOAD=libmtemalloc.so MALLOC_MTE=1 PR_MTE_TCF=1 ./app
# PR_MTE_TCF=1 enables synchronous fault delivery via prctl
# Adds ~5-10% overhead; use only for debugging

5. Enable Hardware-Assisted Sanitizer

Compile with HWASAN for precise origin tracking (requires rebuild):

clang -fsanitize=hwaddress -fno-omit-frame-pointer -O1 -g app.c -o app
# Run normally; faults report exact source line

Fixes Mapped to Findings

Heap Buffer Overflow/Underflow

Add explicit bounds checks before pointer arithmetic. Use malloc_usable_size(ptr) or __builtin_object_size(ptr, 0) to validate accesses. Enable allocator-assisted detection:

export MALLOC_MTE=2  # async detection (default on Android 13+)
export MALLOC_MTE=3  # sync detection for debugging

Use-After-Free

Set pointers to NULL immediately after free(). Use sized deallocation APIs where available: free_sized(ptr, size), free_aligned_sized(ptr, align, size). Enable quarantine to delay reuse:

mallopt(M_QUARANTINE, 64 * 1024);  // 64 KB quarantine buffer

Stack Tag Mismatch

Ensure compiler flags are compatible: -fstack-protector-strong and -mstack-protector-guard=tls work with MTE. Avoid inline assembly that clobbers the stack pointer without preserving its top-byte tag. If hand-written assembly manipulates SP, tag the new value with irg (insert random tag) or copy the tag from the original SP.

Global/Data Section Mismatch

Relink with a tag-aware linker. Use lld with packed dynamic relocations:

clang -fuse-ld=lld -Wl,--pack-dyn-relocs=relr ...

Avoid __attribute__((section(".mysec"))) without a linker script that marks the section MTE-compatible (aligned to 16 bytes, tagged at load time).

TBI/Pointer Cast Issues

Compile with -mno-ignore-top-byte (default on MTE kernels). For integer-to-pointer round-trips, use uintptr_t and preserve tags:

void *p = malloc(16);
uintptr_t i = (uintptr_t)p;
// ... arithmetic on i ...
void *q = __builtin_preserve_tag((void *)i);

Legacy code relying on TBI=0 (prctl(PR_SET_TAGGED_ADDR_CTRL, PR_TAGGED_ADDR_ENABLE)) conflicts with MTE; MTE implies TBI=1. Such code must be updated.

Escalation Criteria

Condition	Likely Root Cause	Action
Fault persists after clean HWASAN build	CPU erratum (e.g., Cortex-A710 r0p0 spurious async faults, fixed in r0p1)	Check CPU revision: cat /proc/cpuinfo | grep -i revision; consult vendor errata; disable MTE for affected cores via kernel cmdline arm64_mte=off as last resort
Kernel panic in do_mte_fault	Kernel < 5.17 (sync) or < 6.1 (async)	Upgrade to 6.1+ LTS; backport MTE patches if stuck on older LTS
Performance regression >15% with sync mode	Overhead on hot paths	Profile: perf stat -e armv8_pmuv3_0/mte_*/ ./app; apply selective tagging: prctl(PR_MTE_TCF, PR_MTE_TCF_SYNC, 0, 0, 0) only on critical threads; use async (PR_MTE_TCF_ASYNC) elsewhere
False positives in JIT/interpreted runtimes (V8, ART)	Runtime emits untagged pointers or mismatched tags	File runtime bug; workaround: restrict MTE to async for JIT regions via mprotect(ptr, size, PROT_MTE | PROT_READ | PROT_WRITE)

Limitations and Verification

MTE granules are 16-byte aligned. Structure padding or alignment changes can shift tag boundaries unexpectedly. Use alignas(16) on critical structures to control tag placement. Low entropy at early boot (before rngd or virtio-rng starts) can cause tag collisions, yielding false negatives. Ensure a hardware RNG is active.

Verify the fix by re-running with synchronous detection and confirming the fault moves to the allocation site:

MALLOC_MTE=3 ./app
# Fault should now occur at the exact overflow/write-after-free line

perf record -e armv8_pmuv3_0/mte_tag_check_fault/ ./app
perf report
# Compare fault counts before and after fix

Cross-validate on x86_64 with HWASAN emulation: the same bug should surface with a similar stack trace, confirming the logic error is architecture-independent.
