Diagnosing AngularJS $injector:unpr Unknown Provider Errors

Recognizable Condition

AngularJS logs Error: [$injector:unpr] Unknown provider: <name>Provider <- <name> immediately after bootstrap or controller instantiation. The dependency injection (DI) system halts, leaving the component or service uninitialized. You will see this in the browser console, often paired with a stack trace pointing to the failing injector call.

Cause and Diagnostic Reference

Symptom	Likely Cause	Quick Verification
Error names a service you wrote	Missing module dependency in angular.module('app', ['missingModule'])	Check the module declaration array
Error appears only after minification	Constructor parameters lost their names; no inline array or $inject annotation	Compare minified vs. unminified source
Error references a third-party service	Typo in service name or provider script loads after consumer	Inspect script order in Network tab
Error during service-to-service injection	Circular dependency between two services	Search for mutual factory/service references
Error names a provider that returns undefined	Factory function missing return statement	Review factory body for explicit return

Ordered Diagnostic Checks

1. Confirm module identity. The string passed to ng-app (or angular.bootstrap) must exactly match the first argument of angular.module('name', []). A mismatch creates a new empty module instead of extending yours.

   <!-- index.html -->
   <html ng-app="myApp">

   // app.js
   angular.module('myApp', ['ngRoute']); // must be 'myApp'


   Run in console: angular.module('myApp')._invokeQueue.length — zero means the module is empty.
2. Verify script load order. Open the Network tab, filter by JS, and ensure every provider script appears before the consumer script and before ng-app bootstrap. Deferred or async scripts that load after bootstrap will not register in time.
3. Inspect minification annotations. Controllers, services, and factories must use inline array annotation or $inject property when minified. AngularJS 1.2+ supports both.

   // Before minification — safe
   app.controller('UserCtrl', ['$scope', '$http', function($scope, $http) {
     // ...
   }]);

   // Equivalent $inject form
   function UserCtrl($scope, $http) { /* ... */ }
   UserCtrl.$inject = ['$scope', '$http'];
   app.controller('UserCtrl', UserCtrl);


   If you see function(a,b) in the minified bundle without a preceding string array, annotation is missing.
4. Check spelling against registration. The provider name in the error (before Provider) must match the exact string used in .factory('exactName', ...) or .service('exactName', ...). Case sensitivity matters.
5. Trace circular references. Search for two services injecting each other directly. Example:

   app.service('Auth', ['User', function(User) { /* uses User */ }]);
   app.service('User', ['Auth', function(Auth) { /* uses Auth */ }]);


   Break the cycle by injecting $injector lazily in one service or extracting shared logic into a third service.

Fixes Mapped to Findings

Finding	Fix	Code Example
Missing module in dependency array	Add the module name to the main module's requires array	angular.module('app', ['ngRoute', 'ui.bootstrap', 'myFeature'])
Unannotated parameters after minification	Rewrite using inline array annotation (preferred) or $inject	See step 3 example above
Typo in service name	Correct the spelling in the injection array to match registration	Change 'userServcie' to 'userService'
Provider script loads too late	Move the provider's <script> tag above the consumer and bootstrap	Order: angular.js → providers → consumers → app bootstrap
Circular dependency	Inject $injector and call get() at runtime, or refactor to a shared service	app.service('Auth', ['$injector', function($inj) { var User = $inj.get('User'); }])
Factory returns undefined	Add explicit return statement in factory function	.factory('api', function() { return { get: fn }; })

Escalation Criteria

Stop debugging and escalate when:

• All five checks pass but the error persists — suspect a third-party module built for a different AngularJS version.
• The offending provider comes from a library incompatible with AngularJS 1.8.x (the final LTS release).
• Workarounds such as lazy $injector injection proliferate, indicating architectural decay.

At this point, evaluate whether to pin the third-party dependency to a compatible version, fork and patch it, or plan migration to Angular (v2+). Patching DI internals is not sustainable.

Version-Sensitive Behavior

• Inline array annotation (['$scope', fn]) is supported from AngularJS 1.2 onward.
• component() introduced in 1.5 follows identical DI rules; its controller function still requires annotation for minification safety.
• Minification handling has not changed across 1.x LTS releases.

Practical Verification Steps

1. Reproduce with the unminified angular.js (not angular.min.js) to get readable stack traces.
2. In the browser console, run:

   angular.injector(['ng', 'myApp']).get('myService')

   If this throws, the service is not registered in the injector at all.
3. Confirm every module script appears in the Network tab before the ng-app bootstrap timestamp.

Limitations and Risks

• Do not edit minified production bundles directly; rebuild from source with ng-annotate (deprecated but functional) or explicit inline annotations.
• Assuming provider availability before angular.bootstrap completes is unsafe; script load order is deterministic only when scripts are synchronous and ordered.
• Lazy $injector injection masks circular-dependency design problems; prefer refactoring shared logic into a dedicated service.
• This guide assumes AngularJS 1.2+ and access to browser developer tools (Console, Network, Sources).

Quick Result Check

After applying a fix, reload the page with the unminified AngularJS file. The console should show no [$injector:unpr] errors, and the component that previously failed should initialize. If the error shifts to a different provider, repeat the diagnostic from step 1 for the new name.
