Diagnosing and Fixing Harbor Image Replication Failures

Why Replication Fails in Harbor

Harbor’s replication engine copies images from a source project to a target project or external registry. A failure can surface as a job stuck in pending, marked failed, or with a specific error code. The most common culprits are authentication problems (401/403), network reachability, pod resource constraints, and mis‑configured target endpoints.

Diagnostic Overview

Below is a quick reference table that maps a recognizable condition to its likely cause, the checks you should run, the fix, and when to seek escalation.

Condition	Likely Cause	Checks	Fix	Escalation
Job status = pending or failed with no progress	Authentication failure (401/403)	Verify credentials in Harbor UI, check replication.yaml, run harborctl replication list	Update token/username/password, rotate secrets, re‑create replication rule	After 2 retries, contact registry admin
Job logs show timeout or connection refused	Network connectivity	Run curl -v https://TARGET_REGISTRY/v2/ from the Harbor host, check kubectl logs of replication pods	Fix network routes, open firewall ports (443), add DNS entries	If external registry unreachable, involve network ops
Job stops with OOMKilled or CrashLoopBackOff	Resource limits	Check pod status: kubectl describe pod, inspect resource usage via kubectl top pod	Increase CPU/memory limits in replication.yaml or deployment, or scale replicas	After adjustment, monitor for stability; if persistent, review cluster capacity
Job logs contain 404 or endpoint not found	Target endpoint mis‑configured	Validate target URL in replication rule, test via curl from Harbor node, confirm TLS certificates	Correct URL, update TLS secret, restart replication pods	If external registry requires custom CA, involve security team

Step‑by‑Step Diagnostic Flow

1. Open the Harbor UI
   • Navigate to Projects → Replication and locate the job.
   • Check the Status column; note any error messages displayed.
   • Click the job ID to view detailed logs.
2. Verify Replication Configuration
   • Locate the replication rule in /etc/harbor/replication.yaml (or via the UI).
   • Ensure the source and target URLs are correct, including protocol (https://).
   • Check credential fields: username, password, or token. Avoid hard‑coded secrets in logs.
   • Run harborctl replication list (if harborctl is installed) to confirm the rule is active.
3. Test Network Connectivity from the Harbor Host
   • SSH into the node running Harbor (or use kubectl exec into the harbor-core pod).
   • Execute:

     curl -v https://TARGET_REGISTRY/v2/

   • Expected output: HTTP 200 OK. If you see a timeout or connection error, the registry is unreachable.
   • Check DNS resolution: nslookup TARGET_REGISTRY.
4. Inspect Replication Pod Logs and Status
   • Run:

     kubectl logs -n harbor harbor-replication-pod-name

   • Look for stack traces, 401 / 403 messages, or timeout warnings.
   • Check pod events:

     kubectl describe pod -n harbor harbor-replication-pod-name

     to see if it was OOMKilled or crashed.
5. Validate Resource Allocation
   • Run:

     kubectl top pod -n harbor harbor-replication-pod-name

   • Compare CPU/memory usage against the pod’s limits defined in replication.yaml or the Helm chart.
   • If usage approaches limits, consider raising them or adding replicas.
6. Check TLS and CA Certificates
   • For HTTPS targets, ensure Harbor’s node trusts the registry’s CA. If using a self‑signed cert, add it to /etc/ssl/certs/ca-certificates.crt or mount a custom ca-bundle secret.
   • Test with curl --cacert /path/to/ca.crt https://TARGET_REGISTRY/v2/ to confirm the handshake succeeds.
7. Apply Fixes and Re‑run the Job
   • After making configuration changes, restart the replication pod:

     kubectl rollout restart deployment -n harbor harbor-replication

   • Re‑trigger the replication job from the UI or via harborctl replication trigger.
   • Verify job completes successfully within a reasonable time frame.

Practical Example: Updating Credentials

Suppose a job fails with a 401 error. The replication rule in replication.yaml looks like this:

replication_rules:
  - name: "copy-to-prod"
    source: "https://harbor.example.com/api/v2.0"
    target: "https://prod-registry.internal:5000"
    credentials:
      username: "old_user"
      password: "old_pass"

Replace the credentials by editing the file:

sed -i 's/old_user/new_user/' /etc/harbor/replication.yaml
sed -i 's/old_pass/new_pass/' /etc/harbor/replication.yaml

After editing, back up the file:

cp /etc/harbor/replication.yaml /etc/harbor/replication.yaml.bak

Restart the replication deployment:

kubectl rollout restart deployment -n harbor harbor-replication

Trigger a new job and observe it finish. If it still fails, verify the new credentials are valid by logging into the target registry directly from the Harbor host.

Escalation Criteria

• After two consecutive failed attempts with the same error, involve the registry administrator.
• If network diagnostics reveal firewall or routing issues, contact the network operations team.
• Persistent OOMKilled pods after raising limits should prompt a cluster capacity review.
• Mis‑configured TLS that requires custom CAs should involve the security or compliance teams.

Limitations and Verification

Harbor’s replication logs may not surface all underlying issues; external factors like upstream registry throttling can also cause timeouts. Always confirm changes by re‑triggering the job and checking both Harbor UI and kubectl logs. If the problem recurs, consider enabling debug logging in Harbor’s harbor-core container for deeper insight. Remember to keep a backup of replication.yaml before editing, and avoid exposing credentials in command history or unsecured files.

Conclusion

By following the ordered checks—UI inspection, config validation, network testing, pod log analysis, and resource verification—you can efficiently isolate and resolve most Harbor replication failures. Apply the fixes, re‑run the job, and if the issue persists beyond the defined escalation thresholds, bring the appropriate team into the loop.
