Deterministic Cleanup in Delphi Without Heap Allocation: Custom Managed Records

The Problem: Resource Leaks in Value Types

Delphi developers have long relied on try/finally blocks to release OS handles, GPU resources, or database connections wrapped in records. While effective, this pattern clutters the business logic, and a single forgotten finally block leads to a resource leak.

Interfaces provide deterministic finalization via reference counting, but they require heap allocation and virtual dispatch. For high-performance code or simple handle wrappers, this overhead is often unacceptable. Since Delphi 10.4 Sydney, Custom Managed Records allow records to have a deterministic lifecycle without leaving the stack. By implementing three special operators—Initialize, Finalize, and Assign—you can implement RAII (Resource Acquisition Is Initialization) patterns for value types.

The Lifecycle Operators

The compiler automatically injects calls to these operators at specific points in the program execution:

• Initialize: Executed when a record variable enters scope or is passed as a value parameter. Use this to set handles to a known null or sentinel state.
• Finalize: Executed when the variable leaves scope, whether via normal exit, an Exit statement, or an exception unwinding the stack. This is where resource release logic resides.
• Assign: Triggered during a := assignment between two managed records. The compiler calls Assign on the destination before calling Finalize on the source.

Crucially, for var or out parameters, the compiler only invokes Initialize and Finalize; Assign is skipped. This distinction is critical to avoid double-free errors.

Worked Example: Win32 Handle Wrapper

This example wraps a Windows HANDLE. It ensures CloseHandle is called exactly once, even if an exception occurs. This requires Delphi 10.4 or later.

unit HandleWrapper;

interface

uses
  Winapi.Windows;

type
  TAutoHandle = record
  private
    FHandle: THandle;
    function IsValid: Boolean; inline;
  public
    class operator Initialize(out Dest: TAutoHandle);
    class operator Finalize(var Dest: TAutoHandle);
    class operator Assign(var Dest: TAutoHandle; const [ref] Src: TAutoHandle);
    class function Create(AHandle: THandle): TAutoHandle; static;
    property Handle: THandle read FHandle;
  end;

implementation

class operator TAutoHandle.Initialize(out Dest: TAutoHandle);
begin
  Dest.FHandle := INVALID_HANDLE_VALUE;
end;

class operator TAutoHandle.Finalize(var Dest: TAutoHandle);
begin
  if Dest.IsValid then
    CloseHandle(Dest.FHandle);
  Dest.FHandle := INVALID_HANDLE_VALUE;
end;

class operator TAutoHandle.Assign(var Dest: TAutoHandle; const [ref] Src: TAutoHandle);
begin
  // Release existing resource in destination before taking ownership of source
  if Dest.IsValid then
    CloseHandle(Dest.FHandle);
  Dest.FHandle := Src.FHandle;
  // Note: Src.FHandle cannot be modified here due to const [ref]
end;

class function TAutoHandle.Create(AHandle: THandle): TAutoHandle;
begin
  Result.FHandle := AHandle;
end;

function TAutoHandle.IsValid: Boolean;
begin
  Result := (FHandle <> INVALID_HANDLE_VALUE) and (FHandle <> 0);
end;

end.

Handling Exceptions

Consider a scenario where a file handle is opened, but a failure occurs during processing:

procedure ProcessFile;
var
  H: TAutoHandle;
begin
  H := TAutoHandle.Create(CreateFile('data.bin', GENERIC_READ, 0, nil, OPEN_EXISTING, FILE_ATTRIBUTE_NORMAL, 0));
  if not H.IsValid then
    RaiseLastOSError;

  // If this raises an exception, Finalize is still called by the compiler
  PerformRiskyOperation(H.Handle);
end;

In this case, the developer does not need a try/finally block. The compiler-generated epilogue ensures TAutoHandle.Finalize is called during the stack unwind.

Trade-offs and Limitations

Feature	Managed Record	Interface/Class
Allocation	Stack (Zero Heap)	Heap Required
Dispatch	Direct/Inline Call	Virtual Dispatch
Reference Counting	None	Automatic
RTTI/Published	Not Supported	Supported
Generic Impact	Binary bloat per type	Shared vtable

Circular References: Unlike interfaces, managed records do not have a cycle collector. If two managed records hold references to each other via object fields, they will not be cleaned up automatically in a way that resolves the cycle.

The Assign Trap: Because Assign is called before the source is finalized, you must ensure the destination's current resource is released first. Failure to do so in the Assign operator results in a leak of the destination's previous handle.

Verification and Validation

To verify the behavior of a custom managed record, follow these steps in RAD Studio 11+:

1. Log Execution: Insert OutputDebugString('Finalize Called') inside the Finalize operator. Run the application and monitor the Event Log to confirm it fires on both normal exit and exception paths.
2. Inspect Assembly: Use View → CPU Windows → Disassembly. Confirm that the calls to Initialize and Finalize are direct CALL instructions rather than interface thunks.
3. Memory Leak Check: Run the binary under FastMM4 in FullDebugMode. Verify that no memory leaks are reported, as the record itself should not allocate heap memory.
4. Binary Size: For generic managed records, check the MAP file. Each instantiation of a generic managed record generates its own operator code, which can increase binary size compared to a class-based approach.
