Designing Minimal RTTI Usage in Delphi Applications

Requirements

When a Delphi application needs to inspect class members at runtime—for serialization, ORM mapping, or IDE designers—the Run‑Time Type Information (RTTI) subsystem must be present for the relevant types. The goal is to enable just enough RTTI to satisfy those consumers while keeping the binary size low and avoiding unintended exposure of private data.

Smallest Suitable Design

The minimal RTTI footprint is achieved by:

1. Declaring the class in a unit where $RTTI is explicitly controlled.
2. Marking only the members that reflection‑based code needs as published (or using an explicit $RTTI directive to include specific visibility).
3. Keeping all other fields, methods, and properties at private or protected so they are omitted from the RTTI block by default.

Example unit:

unit MyDto;

interface

uses
  System.Rtti;

 type
  TPerson = class
  private
    FID: Integer;          // not exposed by default
    FSecret: string;       // stays hidden
  published
    // Only these members appear in RTTI
    property Name: string read FName write FName;
    property Age:  Integer read FAge  write FAge;
  end;

implementation

{$RTTI EXPLICIT METHODS([]) PROPERTIES([vcPublished]) FIELDS([])}
// The above line tells the compiler to emit RTTI only for published properties.
// Methods and fields are omitted even if they were published.

end.

With the $RTTI EXPLICIT directive the compiler emits metadata for the exact set of members listed, producing the smallest possible RTTI block for TPerson.

Trust/Data Boundaries

By default Delphi RTTI includes only published members. Private and protected data remain invisible to TRttiContext unless the $RTTI directive is expanded to include those visibilities. This creates a clear trust boundary: reflection‑based code can only see what the developer has explicitly marked as published (or added via an explicit RTTI rule). Expanding RTTI to ALL or PRIVATE would breach that boundary and could leak sensitive fields such as FSecret in the example.

Operational Checks

To verify that the intended RTTI is present:

• Runtime check – Use TRttiContext to query the type:

var
  Ctx: TRttiContext;
  Typ: TRttiType;
  Prop: TRttiProperty;
begin
  Ctx := TRttiContext.Create;
  try
    Typ := Ctx.GetType(TPerson);
    if Typ = nil then
      raise Exception.Create('RTTI not emitted for TPerson');
    // Expect only Name and Age properties
    for Prop in Typ.GetProperties do
      Writeln(Prop.Name);  // Should print Name and Age
  finally
    Ctx.Free;
  end;
end;

If Typ is nil, RTTI for the class was not generated.

• Binary inspection – On Windows, run dumpbin /HEADERS MyApp.exe or objdump -h MyApp on Linux/macOS and look for a section named .rtti. Its presence confirms that the linker included RTTI data.
• Size check – Compare the file size of two builds: one with $RTTI ON (or default) and one with $RTTI OFF for the unit. A noticeable reduction (often several kilobytes per class) indicates that the RTTI block was omitted.

Failure Modes

• Missing RTTI – If reflection‑based code expects a property that lacks RTTI, TRttiContext.GetType returns nil or GetProperties returns an empty array, leading to Access Violations when the code dereferences the nil pointer, or silent failures if the result is not checked.
• Excessive RTTI – Enabling $RTTI ALL inflates the binary, increases startup time (the loader must map a larger .rtti section), and may expose private fields, raising security concerns.
• Version mismatch – Delphi 7 and earlier emit only basic RTTI (no attributes). Code that relies on newer features such as custom attributes requires Delphi 2009+; otherwise the attributes will not be visible at runtime.

Conditions That Would Change the Design

Reevaluate the minimal RTTI approach when:

1. A new framework requires access to previously hidden members (e.g., an ORM that needs to map private fields). In that case, either promote those members to published or add an explicit $RTTI rule for the needed visibility.
2. Security audits reveal that published members inadvertently expose sensitive data; then move those members to private and adjust the consuming code to use alternative mechanisms (e.g., explicit setter/getter methods).
3. Target platforms change to a Delphi version with different RTTI defaults (e.g., moving to a mobile compiler that strips RTTI by default). You may need to force RTTI emission with $RTTI EXPLICIT or adjust linking options.

By continuously matching the RTTI surface to the actual needs of reflection‑based consumers, you keep the binary lean, preserve encapsulation, and avoid the failure modes associated with missing or excessive metadata.
