Designing a Minimal Three‑Node Proxmox VE HA Cluster

Requirements

Before building a HA cluster, verify the following prerequisites:

• At least three physical nodes running the same Proxmox VE version (8.x recommended) to achieve quorum.
• Shared storage that all nodes can access concurrently (e.g., a ZFS pool on iSCSI, Ceph RBD, or NFS).
• A dedicated, isolated network for corosync communication (private VLAN or separate NIC) to keep the trust boundary of the HA ring.

Smallest suitable design

Node software

Each node runs Proxmox VE 8.x with the standard pve-cluster, corosync, and pacemaker packages. The HA resources are managed by the ha-manager service.

Fence agent

A simple fence agent such as fence_ipmilan (IPMI) or fence_manual for testing is configured on every node. The agent must be able to power‑off a peer node when corosync detects a loss of quorum.

# Example fence_ipmilan entry in /etc/pve/ha/resources.cfg (run as root on any node)
# Replace , ,  with actual values
ipmi:  login= passwd= lanplus=1

Place this file under /etc/pve/ha/resources.cfg and reload the HA manager: systemctl reload ha-manager.

Trust and data boundaries

• The corosync ring is trusted only on the isolated HA network; storage traffic may flow over a separate trusted storage network.
• VM/CT disks reside on the shared storage, so they never traverse the HA ring.
• The Proxmox web GUI and API are protected by TLS and role‑based access control (RBAC), independent of the HA subnet.

Operational checks

1. Check cluster health: pvecm status on each node. Look for Quorum: yes and all nodes in the member list.
2. Verify fence agent logs: journalctl -u pve-fenced or /var/log/daemon.log for successful fence commands.
3. Test resource migration: ha-manager set --state started on a node, then power off that node and confirm the VM starts on another node via ha-manager status.
4. Validate shared storage accessibility after a node failure: for ZFS, run zpool status -v on the surviving nodes; for Ceph, run ceph status and ensure HEALTH_OK.

Failure modes and design‑change triggers

Split‑brain due to corosync ring loss

If the HA network partition prevents a majority of nodes from communicating, the cluster loses quorum. Recovery requires manual fencing of the isolated partition or deploying a quorum device (e.g., a separate net‑device or a third‑party quorum server).

Storage loss

When the shared storage becomes unavailable, VMs/CTs encounter I/O errors. The HA manager cannot migrate running workloads because the disks are inaccessible. In this case, consider adding a replicated storage layer (Ceph with erasure coding or ZFS send/receive to a secondary site) or switching to a different storage backend.

Fence agent insufficiency

If IPMI or the chosen fence method fails (e.g., loss of BMC connectivity), the cluster cannot power‑off a stuck node. Adding a watchdog that triggers a hard reset, or configuring a redundant fence method (dual IPMI channels or a smart PDU), changes the design to improve reliability.

Regularly update Proxmox VE and the corosync/pacemaker packages; older versions may lack fixes for known quorum or fencing bugs that could precipitate split‑brain scenarios.
