Designing a Minimal LLVM New Pass Manager Pass: Requirements, Boundaries, and Checks

Requirements

To use LLVM's New Pass Manager (NPM) you need:

• LLVM IR as the input representation.
• A pass class that inherits from PassInfoMixin and implements a run method returning PreservedAnalyses.
• A pipeline builder (PassBuilder) that registers the pass via a lambda or named pipeline.

Smallest Suitable Design

The minimal NPM pass is a single FunctionPass that does not depend on any external analysis. It registers itself with the PassBuilder using a simple lambda:

#include "llvm/IR/PassManager.h"
#include "llvm/IR/Function.h"
#include "llvm/Support/raw_ostream.h"

using namespace llvm;

struct TestPass : PassInfoMixin {
  PreservedAnalyses run(Function &F, FunctionAnalysisManager &) {
    errs() << "TestPass saw function: " << F.getName() << '\n';
    // This pass does not modify the IR, so it preserves everything.
    return PreservedAnalyses::all();
  }
};

static void registerTestPass(PassBuilder &PB) {
  PB.registerPipelineParsingCallback(
      [](StringRef Name, FunctionPassManager &FPM,
         ArrayRef) {
        if (Name == "test-pass") {
          FPM.addPass(TestPass());
          return true;
        }
        return false;
      });
}

extern "C" LLVM_ATTRIBUTE_WEAK ::llvm::PassPluginLibraryInfo llvmGetPassPluginInfo() {
  return {LLVM_PLUGIN_API_VERSION, "test-pass", LLVM_VERSION_STRING,
          [](PassBuilder &PB) { registerTestPass(PB); }};
}

Compile this as a shared library (-fPIC -shared) and load it with opt -load-pass-plugin=<libtestpass.so> -passes='test-pass'.

Trust and Data Boundaries

The pass receives only the Function reference and a FunctionAnalysisManager. It must:

• Never assume ownership of memory outside the IR; all modifications must go through LLVM IR APIs (e.g., IRBuilder, Value::replaceAllUsesWith).
• Not retain pointers to IR objects after run returns, unless those objects are preserved by the returned PreservedAnalyses.
• Avoid static or global state that could cause cross-invocation interference.

Operational Checks

LLVM runs the IR verifier before and after each pass. If a pass claims to preserve an analysis but actually invalidates it, the verifier will detect inconsistencies and LLVM will call report_fatal_error. The PassManager also checks that the PreservedAnalyses returned by a pass matches what the next pass expects.

Failure Modes and Design Triggers

• Incorrect analysis preservation: Returning PreservedAnalyses::all() while modifying the IR leads to stale analysis results and possible miscompiles.
• Version sensitivity: The NPM API changed between LLVM 11 and LLVM 14. Code that uses the legacy PassManager or old RegisterPass macros may fail to compile unless guarded by #ifdef LLVM_ENABLE_NEWPM.
• Design change triggers: Switching back to the legacy PassManager, adding a new analysis interface, or altering the pass granularity (e.g., moving to a ModulePass) requires updating the pipeline registration and adjusting analysis dependencies.

Practical Example: Building and Testing the Pass

Run the following in a shell where you have write permission to the working directory. LLVM 14 or newer is assumed.

1. Build LLVM (version 14 or later) or install a pre-built package that includes headers and libraries.
2. Compile the pass, assuming the source is in TestPass.cpp:

   clang++ -fPIC -shared TestPass.cpp `llvm-config --cxxflags --ldflags --system-libs --libs core irreader` -o libTestPass.so

   This produces a shared library in the current directory.

3. Create a simple IR file (sample.ll):

   ; ModuleID = 'sample'
   source_filename = "sample"
   define i32 @main() {
     ret i32 0
   }


4. Run the pass:

   opt -load-pass-plugin=./libTestPass.so -passes='test-pass' -S -disable-output sample.ll 2>&1

   Expected output on stderr:

   TestPass saw function: main

   If you see this line, the NPM successfully loaded and invoked the pass.

5. Introduce a deliberate error: change the return statement to return PreservedAnalyses::none(); while still not modifying the IR. Re-run the command; LLVM should abort with a verification failure, confirming the manager's analysis checks are active.
6. Compare NPM vs. legacy PM:

   opt -O2 -S sample.ll -o opt-npm.bc
   opt -O2 -S -enable-new-pm=0 sample.ll -o opt-legacy.bc
   cmp -s opt-npm.bc opt-legacy.bc && echo "IR identical" || echo "IR differs"

   Identical output indicates the new design preserves semantics while providing extensibility.

Limitations

• The NPM adds a small indirection for analysis caching; in ultra-low-latency JIT scenarios a hand-rolled legacy pass may still be preferable.
• Debugging registration errors can be opaque; enabling -debug-pass-manager or using opt -passes=print<module> helps pinpoint mismatches.
• Version-specific API changes mean that tutorials targeting older LLVM may need adaptation (e.g., using PassPluginLibraryInfo vs. legacy RegisterPass).

Practical Verification Checklist

1. Build LLVM 14 or later, or confirm the pre-built version.
2. Compile the pass as a shared library.
3. Run opt -load-pass-plugin=<lib> -passes='test-pass' on a trivial IR file and verify the expected print appears.
4. Introduce an analysis-preservation mistake and confirm LLVM aborts with a verification error.
5. Run -O2 with both NPM and legacy PM and compare the resulting IR binaries.
