Deploying Phoenix LiveView: From Setup to Production Readiness

Desired Outcome

By the end of this article you will be able to:

• Generate a new Phoenix 1.7+ project with LiveView support.
• Mount a LiveView module, perform authorization and data loading in mount/3.
• Handle client events with handle_event/3 and update UI state via socket.assigns.
• Configure file uploads and component composition.
• Verify the LiveView traffic flow in dev, run tests, and prepare for high‑concurrency production.

Prerequisites

• Elixir 1.14+ and Erlang/OTP 26+ installed.
• Node.js 18+ for asset compilation.
• PostgreSQL (or another supported DB) for persistence.
• Basic knowledge of Phoenix routing, controllers, and templates.

Step‑by‑Step Setup

1. Create a LiveView‑enabled project

   mix phx.new my_app --live
   # cd into the project directory
   cd my_app
   # install dependencies
   mix deps.get
   # compile assets
   npm install --prefix assets
   npm run deploy
   # start the server
   mix phx.server


   The --live flag adds the phoenix_live_view dependency and a basic LiveView route in lib/my_app_web/router.ex.

2. Define a LiveView module

   defmodule MyAppWeb.DashboardLive do
     use Phoenix.LiveView

     def mount(_params, session, socket) do
       # Authorization example
       user_id = session["user_id"]
       if user_id do
         # Load initial data
         {:ok, assign(socket, user: MyApp.Accounts.get_user!(user_id), items: [])}
       else
         {:redirect, to: "/login"}
       end
     end

     def handle_event("add_item", %{"name" => name}, socket) do
       # Persist the item and update assigns
       {:ok, _item} = MyApp.Items.create(name: name)
       {:noreply, update(socket, :items, fn items -> [name | items] end)}
     end
   end


   Mounting via live/2 in the router:

   live "/dashboard", DashboardLive


3. Use HeEx templates for efficient diffing

   def render(assigns) do
     ~H"
     Hello, <%= @user.name %>!


       Add



       <%= for item <- @items do %>

   <%= item %>
       <% end %>

     "
   end


4. Configure file uploads

   def mount(_params, _session, socket) do
     {:ok, assign(socket, :uploads, allow_upload(socket, :image, max_entries: 1, accept: ".png,.jpg"))}
   end

   # In the template
   ~H"


     Upload

   "


   Processing after completion:

   def handle_event("upload", _params, socket) do
     consume_uploaded_entries(socket, :image, fn %{path: path} ->
       # Move to permanent storage
       File.cp!(path, "/uploads/#{Path.basename(path)}")
     end)
     {:noreply, socket}
   end


5. Component composition

   # Function component (stateless)
   # lib/my_app_web/components/button.ex
   defmodule MyAppWeb.Components.Button do
     use Phoenix.Component

     def render(assigns) do
       ~H"

         <%= @label %>

       "
     end
   end

   # Usage in a LiveView template
   ~H"

   "


   Stateful live components can be added with live_component/1 when you need isolated state.

6. Run automated tests

   defmodule MyAppWeb.DashboardLiveTest do
     use MyAppWeb.ConnCase, async: true
     import Phoenix.LiveViewTest

     test "renders dashboard", %{conn: conn} do
       {:ok, view, _html} = live(conn, "/dashboard")
       assert render(view) =~ "Hello"
     end
   end


   Execute with mix test.

7. Verify WebSocket flow in dev
   1. Open http://localhost:4000/dashboard in a browser.
   2. Open DevTools → Network → filter by WS.
   3. Observe the initial GET, the upgrade to a WebSocket, and binary frames containing patch diffs (phx-update).
8. Prepare for production
   • Set check_origin in config/prod.exs to match your domain.
   • Configure a reverse proxy (NGINX, HAProxy) to pass Upgrade and Connection headers.
   • Adjust BEAM options: +P 1000000 +Q 1000000 for high concurrency.
   • Use Phoenix.PubSub for cross‑process messaging instead of long‑running DB transactions.

Expected Checks

• LiveView mounts successfully and redirects unauthorized users.
• Client events trigger handle_event/3 and update the DOM without full re‑renders.
• File uploads complete with progress events and server‑side storage.
• Component rendering matches expected HTML fragments.
• Automated tests pass in CI without a browser.
• WS traffic shows only patch frames after the initial upgrade.

Recovery Options

• Socket disconnects – the client automatically retries with exponential backoff. Ensure mount/3 is idempotent: re‑load data and re‑authenticate on reconnection.
• Memory pressure – monitor process counts with elixir --sname my_app --remsh and :observer.start(). Scale out with more BEAM nodes if +P limits are reached.
• High‑latency networks – use phx-debounce in the template or implement optimistic updates via phx-update="ignore" for critical interactions.
• Large session payloads – keep session data minimal; store user context in a server‑side store keyed by user_id and fetch on mount/3.
• JavaScript hook failures – wrap hook logic in try/catch and log errors to console.error; fallback to pure LiveView behavior if hooks crash.

Practical Tips

• Use phx-update="ignore" on elements that should not be patched, reducing diff size.
• When a LiveView needs to broadcast updates, call Phoenix.PubSub.broadcast/3 and handle handle_info/2 to update assigns.
• For long‑running operations, consider Task.async_stream/3 inside handle_event/3 to keep the socket responsive.
• Leverage LiveViewTest helpers like element/3 to query specific DOM nodes before asserting state.
• In production, enable live_reload: false in config/prod.exs to avoid unnecessary reloads and reduce WebSocket chatter.

Conclusion

Phoenix LiveView turns server‑side rendering into an interactive, low‑latency experience without the overhead of a full client‑side framework. By following the steps above, you can quickly prototype, test, and deploy a production‑ready LiveView application that scales with proper BEAM tuning and thoughtful state management.
