Deploying a Waku Relay Node with Store for Offline Message Delivery

Desired outcome

Run a Waku Relay node that persists messages via the Store plugin and verify that a subscriber which was offline during publication receives the missed messages when it reconnects.

Prerequisites

• Docker Engine installed and the user able to run docker commands (either root or a user in the docker group).
• Basic familiarity with terminal/shell usage.
• Network access to pull images from Docker Hub (no firewall blocking docker pull).

Focused procedure

1. Pull the official Waku Go image

   # Run in any terminal with docker access
   # No special flags needed; the image is public
   docker pull wakuorg/waku-go:latest


   This step fetches the Relay binary bundled with the Store plugin.

2. Create a persistent volume for Store data

   # Creates a named volume that survives container restarts
   docker volume create waku-store-data


   The volume will be mounted inside the container to hold the message database.

3. Start the Relay node with Store enabled

   # Run the container, exposing the JSON‑RPC port (default 8545)
   # Adjust --store-path if you prefer a different mount point
   docker run -d \
     --name waku-relay \
     -p 8545:8545 \
     -v waku-store-data:/root/.waku/store \
     wakuorg/waku-go:latest \
     --listen-address 0.0.0.0:8545 \
     --store \
     --store.path /root/.waku/store


   The node begins gossiping via libp2p GossipSub and starts storing incoming messages.

4. Verify the Relay is healthy

   # Check that the container is running
   docker ps --filter name=waku-relay

   # Query the admin peer count endpoint (should show >0 after a few seconds)
   curl -s http://localhost:8545/admin/peers | jq '.peers | length'


   If the peer count is zero, ensure the host can reach the public bootstrap nodes or provide custom ones via --bootstrap.

5. Publish a test message

   # Install waku-cli if not present (npm i -g @wakuorg/waku-cli or use the binary)
   waku-cli publish \
     --topic /my-app/1.0/pubsub \
     --payload '{"event":"hello","seq":1}' \
     --rpc http://localhost:8545


   The command returns a transaction‑like hash; the Relay logs should show a GossipSub propagation line.

6. Subscribe and confirm real‑time receipt

   # In a second terminal
   waku-cli subscribe \
     --topic /my-app/1.0/pubsub \
     --rpc http://localhost:8545


   You should see the published JSON appear within a few seconds.

7. Simulate an offline subscriber
   1. Stop the subscriber with Ctrl+C.
   2. Publish a second message while the subscriber is down:

      waku-cli publish \
        --topic /my-app/1.0/pubsub \
        --payload '{"event":"world","seq":2}' \
        --rpc http://localhost:8545


   3. Restart the subscriber (same command as step 7).
8. Verify offline delivery from Store

   Upon reconnection, the subscriber should first receive the missed message (seq 2) before any new messages. The waku‑cli output will show both payloads in order.

9. Optional: Check stored message count

   # Use the admin store endpoint (if enabled)
   curl -s http://localhost:8545/admin/store/stats | jq '.totalMessages'


   This returns the number of messages persisted in the volume.

Expected checks

• Container runs without exit codes; docker logs waku-relay shows no fatal errors.
• Peer count > 0 after node startup indicates successful GossipSub mesh formation.
• Publish command returns a hash and the Relay log contains a line like "GossipSub message published".
• Subscriber receives messages in real time and, after reconnection, receives any messages published while it was offline.
• Store stats (if queried) increase with each published message, confirming persistence.

Recovery options

If the Relay node stops unexpectedly:

1. Restart the container with the same name and volume: docker start waku-relay (or docker run … again).
2. Verify that the Store volume still contains prior messages by checking the admin store stats.
3. If the volume appears corrupted, delete it (docker volume rm waku-store-data) and start fresh; note that all persisted history will be lost.

Limitations and practical considerations

• Store increases disk usage proportionally to message volume; implement a retention policy (e.g., delete messages older than N days) by pruning the volume or configuring the Store plugin’s --store.max-age flag if available.
• Reliability depends on network density; in very sparse partitions messages may still be lost if the Store plugin is not running.
• Version alignment matters: ensure the waku‑cli version matches the Relay’s API version to avoid RPC mismatches.
• By default, payloads are not encrypted; apply application‑level encryption (e.g., libsodium) if confidentiality is required.
