Define a Custom Database-Backed Content Element in Contao with DCA

Why DCA Is the Core of Extension Development

In Contao every back-end editable table is described by a Data Container Array (DCA). The DCA does three things in one place:

• Declares the table schema (via the sql key)
• Defines the edit mask (via palettes and fields)
• Configures the list view (via list)

Because the install tool and the contao:migrate command read the sql definitions, you ship database changes as code, not as hand-written SQL. That is the engineering decision that keeps extensions maintainable and version-control friendly.

Step 1 – Create the DCA File

Place a file in contao/dca/tl_my_element.php. The file must return an array; Contao will merge it into $GLOBALS['TL_DCA'] automatically.

 [
        'dataContainer' => 'Table',
        'enableVersioning' => true,
        'sql' => [
            'keys' => [
                'id' => 'primary',
                'alias' => 'unique'
            ]
        ]
    ],
    'list' => [
        'sorting' => [
            'mode' => 4,
            'fields' => ['sorting'],
            'flag' => 1,
            'panelLayout' => 'filter;sort,search,limit'
        ],
        'label' => [
            'fields' => ['title', 'alias'],
            'showColumns' => true
        ],
        'operations' => [
            'edit' => ['href' => 'act=edit', 'icon' => 'edit.svg'],
            'delete' => ['href' => 'act=delete', 'icon' => 'delete.svg'],
            'toggle' => ['href' => 'act=toggle', 'icon' => 'visible.svg']
        ]
    ],
    'palettes' => [
        'default' => '{title_legend},title,alias,description;{publish_legend},published,start,stop'
    ],
    'fields' => [
        'id' => [
            'sql' => "int(10) unsigned NOT NULL auto_increment"
        ],
        'tstamp' => [
            'sql' => "int(10) unsigned NOT NULL default '0'"
        ],
        'title' => [
            'label' => 'Title',
            'inputType' => 'text',
            'eval' => ['mandatory' => true, 'maxlength' => 255],
            'sql' => "varchar(255) NOT NULL default ''"
        ],
        'alias' => [
            'label' => 'Alias',
            'inputType' => 'text',
            'eval' => ['rgxp' => 'alias', 'unique' => true, 'maxlength' => 128],
            'sql' => "varchar(128) NOT NULL default ''"
        ],
        'description' => [
            'label' => 'Description',
            'inputType' => 'textarea',
            'eval' => ['rte' => 'tinyMCE'],
            'sql' => "text NULL"
        ],
        'published' => [
            'label' => 'Published',
            'inputType' => 'checkbox',
            'eval' => ['doNotCopy' => true],
            'sql' => "char(1) NOT NULL default '0'"
        ],
        'start' => [
            'label' => 'Start',
            'inputType' => 'checkbox',
            'eval' => ['tl_class' => 'w50 wizard', 'doNotCopy' => true, 'datepicker' => true],
            'sql' => "int(10) unsigned NOT NULL default '0'"
        ],
        'stop' => [
            'label' => 'Stop',
            'inputType' => 'checkbox',
            'eval' => ['tl_class' => 'w50 wizard', 'doNotCopy' => true, 'datepicker' => true],
            'sql' => "int(10) unsigned NOT NULL default '0'"
        ]
    ]
];

Key points:

• The sql strings are parsed by Contao's migration tool. Keep them simple; int, varchar, text are fine.
• Never rename the reserved columns id, tstamp, sorting, pid unless you also update the DCA config accordingly.
• The list section controls the back-end overview. Mode 4 creates a tree view that is useful for parent-child relations (e.g. pages).

Step 2 – Register the Content Element

In Contao 5 the modern way is to create a controller class and annotate it with #[AsContentElement]. Older 4.x code can still use the $GLOBALS['TL_CTE'] array, but mixing both will silently fail.

data contains the row from tl_my_element
        return $this->render('ce_my_element.html.twig', [
            'data' => $this->data
        ]);
    }
}

Place the template in templates/ce_my_element.html.twig and reference the fields you need:

<h2>{{ data.title }}</h2>
<p>{{ data.description|raw }}</p>

After adding the class, run the cache clear command to load the new content element type:

# From the Contao root
php bin/console contao:cache:clear

Step 3 – Ship the Schema with the Install Tool

When your extension is installed, Contao will compare the sql definitions with the live database. If the table tl_my_element does not exist, it will be created automatically. If a column is missing or has the wrong type, the tool will alter it.

# In development or on a new server
php bin/console contao:migrate

Verify the migration by checking the database or by inspecting the back-end list view. The list configuration should now show your rows sorted by sorting and provide edit/delete operations.

Common Pitfalls and How to Avoid Them

• Cache not cleared: After editing a DCA, the back-end will still show the old form until contao:cache:clear is run.
• Using unsupported SQL types: The migration tool only understands int, varchar, text, char, datetime. For custom types you must write a manual migration.
• Renaming reserved columns: Changing id or tstamp without updating the DCA config breaks Contao's versioning and sorting.
• Mixing attribute and legacy registration: In Contao 5, use only the PHP attribute. In Contao 4, register via $GLOBALS['TL_CTE']. Mixing them results in the element not appearing in the back-end.
• Missing sql key: Without it, the install tool cannot create or alter the table. Always include the sql definition for every field.

Limitations of the DCA-Based Approach

• Complex migrations (e.g. splitting a column into two) still require hand-written SQL and a custom migration class.
• The automatic migration only supports simple alterations; adding a new column with a default that depends on other columns may fail.
• If you need to expose the data to API consumers, you must write a DataProvider or REST controller yourself; the DCA does not handle that.

Practical Check-List Before Shipping

1. Run php bin/console contao:migrate locally and confirm the table appears.
2. Open an article in the back-end, add a new MyElement, fill in the fields, and save.
3. View the article on the front-end and verify the Twig template renders the data.
4. Clear the cache on the target server and repeat the steps to catch caching issues early.
5. If the element does not appear in the content element picker, double-check the attribute parameters and the namespace of the controller.

By keeping all database, form, and list logic inside the DCA and using the built-in migration tool, you make your extension portable, version-control friendly, and easy to maintain.
