Cut Network Traffic with Aerospike UDFs: A Hands‑On Guide

Problem: Too Much Client‑Side Work

In many real‑world applications, the client pulls a record, performs a calculation, and writes back a result. For a shopping‑cart service, that might mean retrieving every item, summing prices, and updating the total. Each of those steps costs network round‑trips, increases payload size, and adds latency. When thousands of carts are updated every second, the network becomes a bottleneck and the client code grows complex.

Takeaway: Run the calculation on the Aerospike server with a User‑Defined Function (UDF). The server does the heavy lifting, returns only the final value, and keeps your client thin.

How Aerospike UDFs Work

Aerospike UDFs are Lua scripts that execute inside the Aerospike process. They are registered once and then invoked by key, query, batch, or scan. The server runs them in a sandboxed environment: you can call Aerospike functions like get, put, scan, but you cannot open sockets or read files.

Key concepts:

• Namespace – logical database; UDFs are global to a namespace.
• Set – optional partition of a namespace, like a table.
• Bin – column‑like storage inside a record.
• Sandbox – limits Lua access to Aerospike APIs only.

Registering a UDF:

# register a file named cart.lua
# run as a user that can write to /opt/aerospike/udf
$ aerospike-admin udf register cart.lua
# optional: list registered UDFs
$ aerospike-admin udf list

Once registered, you can call the function by name. For example, cart_total in the script below will be invoked with a key and optional arguments.

Concrete Example: Shopping‑Cart Total

Suppose each cart record has a bin called items that stores a list of item tables, each containing price and quantity. We want to compute the total price and store it in a new bin total.

cart.lua

-- cart.lua
-- Calculate total price for a cart and store it
function cart_total(rec, args)
    local items = rec.bins.items
    if not items then return end
    local sum = 0
    for _, item in ipairs(items) do
        sum = sum + (item.price or 0) * (item.quantity or 1)
    end
    -- write back the result
    aerospike:update(rec, { total = sum })
    return sum
end

Invoke from a query:

# Using the Aerospike SQL interface
SELECT cart_total FROM shopping_carts WHERE key = 'cart123'
# The server returns the computed total and has already written it to the record.

Alternatively, call it from a client driver (Java, Python, etc.):

# Python example
from aerospike import client

config = {'hosts': [('127.0.0.1', 3000)]}
client = client(config).connect()
key = ('myns', 'shopping_carts', 'cart123')
# args can be nil or a table
client.udf.execute('cart_total', key, None)
# Now the record's 'total' bin holds the sum.

Performance comparison:

• Client‑side: Pull items bin, iterate in client, compute sum, send total bin back.
• Server‑side UDF: Only cart_total result is sent back; no full items payload travels over the network.

For a cart with 50 items, the client payload may be ~10 KB, while the UDF approach returns a few bytes. Latency drops by a factor of 5–10 in high‑throughput scenarios.

Trade‑offs & Monitoring

Running Lua on the server is powerful but not free. The UDF executes inside the Aerospike process, consuming CPU and memory:

• CPU impact: Simple arithmetic is negligible, but loops over large data sets or recursive calls can spike CPU usage.
• Memory: Lua creates its own heap. Heavy data structures may increase per‑node memory pressure.
• Sandbox restrictions: Attempts to perform network I/O, file reads, or system calls will fail with a sandbox violation error.

Monitoring strategy:

1. Use aerospike-admin udf list to track active UDFs.
2. Enable Aerospike’s log_level for stat to capture UDF execution times.
3. Set up a Prometheus exporter or use the Aerospike monitoring API to track udf_execution_time and udf_cpu_time metrics.
4. Run a staged benchmark: generate a synthetic load of 10 k cart updates per second and measure query latency with and without the UDF.

If you notice a consistent spike in udf_execution_time or a drop in overall cluster throughput, consider refactoring the script or moving some logic back to the client.

Actionable Steps

1. Identify a candidate: Look for calculations that always run on the same data set and can be expressed in Lua.
2. Create and register the UDF: Write the script, register it with aerospike-admin udf register, and verify with udf list.
3. Test in staging: Run a controlled load, capture latency, and compare against the client‑side baseline.
4. Deploy to production: Roll out with a canary flag, monitor udf_execution_time, and be ready to roll back if CPU usage climbs.
5. Document the UDF: Keep the script versioned, note its purpose, and add usage examples for future developers.

By moving heavy, deterministic logic to the Aerospike server, you reduce network traffic, simplify client code, and can achieve lower latency for high‑volume workloads. Just remember to monitor the server’s resources and keep the UDFs lean.
