Customizing Content Workflows with Sanity Studio v3 Structure Builder

Solving the "Flat List" Problem

By default, Sanity Studio displays every schema type as a top-level list in the sidebar. For small projects, this is sufficient. However, as a project grows, a flat list of twenty different content types becomes a bottleneck for editors. The goal is to transform the Studio from a database explorer into a curated content management interface.

The Structure Builder (available in Sanity Studio v3) allows you to define a custom hierarchy. Instead of just listing types, you can create folders, filtered views (e.g., "Drafts" vs "Published"), and singletons (documents that only ever have one instance, like Site Settings).

Implementing a Custom Desk Structure

To customize the sidebar, you must define a structure function and pass it to the structure property of your Studio configuration. This function uses the S (Structure) object to build a tree of lists and items.

Worked Example: Content-Driven Hierarchy

The following configuration organizes a Studio into a "Content" section for collections and a "Settings" section for a singleton document. This should be placed in a separate file (e.g., structure.ts) and imported into sanity.config.ts.

import { StructureResolver } from 'sanity/structure'

export const myStructure = (S) =>
  S.list()
    .title('Content Management')
    .items([
      // 1. A standard list of all 'post' documents
      S.documentTypeListItem('post').title('All Blog Posts'),

      // 2. A filtered list showing only scheduled posts
      S.listItem()
        .title('Scheduled for Publish')
        .child(
          S.documentList()
            .title('Scheduled Posts')
            .filter('_type == "post" && status == "scheduled"')
            .order('publishAt asc')
        ),

      S.divider(),

      // 3. A Singleton: Direct link to a specific document ID
      S.listItem()
        .title('Site Settings')
        .child(
          S.document()
            .schemaType('siteSettings')
            .documentId('siteSettings')
        ),
    ])

Configuration Details

• S.documentTypeListItem: The quickest way to add a schema type to the sidebar.
• S.documentList().filter(): Uses GROQ (Graph-Relational Object Query) to create a dynamic view. This is evaluated server-side, meaning the list updates automatically as documents are edited.
• S.document().documentId(): Forces the Studio to open one specific document rather than a list, effectively creating a singleton.

Refining the Editor Experience with Conditional Visibility

Structure controls how you find content; conditional visibility controls what you see while editing. You can hide fields based on the value of other fields using the hidden property in your schema definition.

Example: Hiding a date picker unless the status is 'scheduled'

export default {
  name: 'post',
  type: 'document',
  fields: [
    {
      name: 'status',
      type: 'string',
      options: { list: ['draft', 'published', 'scheduled'] }
    },
    {
      name: 'publishAt',
      type: 'datetime',
      // The 'parent' argument provides the current document values
      hidden: ({ parent }) => parent?.status !== 'scheduled'
    }
  ]
}

Limitations and Common Pitfalls

Performance and Synchronicity

The hidden callback runs on every keystroke in the Studio. It must be a pure synchronous function. Never attempt to perform an async fetch or a heavy computation inside a hidden callback, as this will cause significant input lag for the editor.

The Root Node Requirement

A common error is returning an array of items directly from the structure function. The Structure Builder expects a single root node—typically an S.list(). If you return an array, the Studio sidebar will fail to render.

Singleton Management

While S.document().documentId('id') handles the UI side of a singleton, it does not prevent editors from creating duplicate "Site Settings" documents via the API or other views. To fully enforce a singleton, use the __experimental_singleton: true property in the schema (v3.30+) to hide the type from the global search and other lists.

Verification and Deployment

To verify your structure is working as intended:

1. Run sanity dev. Structure changes hot-reload instantly.
2. Open the Browser DevTools Network tab. When clicking a filtered list (like "Scheduled Posts"), look for a request to /data/query. This confirms the GROQ filter is executing on the server.
3. Test the hidden logic by toggling the status field; the publishAt field should appear and disappear without a page refresh.

Once verified, run sanity deploy to push the updated Studio bundle to the Sanity CDN for your production team.
