Creating a Reusable Amazon EBS AMI with Packer

Desired outcome

Produce a reproducible Amazon Machine Image (AMI) that contains a specific set of software (e.g., Python 3 and nginx) and can be launched repeatedly in any AWS region.

Prerequisites

• Packer version 1.8 or later installed locally or in a CI runner.
• An AWS account with access key and secret key that allow the IAM principal to perform EC2 actions: RunInstances, CreateImage, DescribeImages, DescribeSnapshots, DeleteSnapshot, and DeregisterImage.
• AWS CLI configured (optional but useful for verification).
• SSH key pair that will be used to connect to the temporary build instance (the private key must be accessible to the Packer process).
• Basic familiarity with HCL2 or JSON syntax for Packer templates.

Focused procedure

1. Define variables

Create a file variables.pkr.hcl (or variables.json) that holds values you do not want to hard‑code:

variable "aws_access_key" {}
variable "aws_secret_key" {}
variable "region" { default = "us-east-1" }
variable "instance_type" { default = "t3.micro" }
variable "ssh_username" { default = "ec2-user" }
variable "source_ami_filter" {
  type = map(string)
  default = {
    owners = "amazon"
    most_recent = true
    name = "amzn2-ami-hvm-*-x86_64-gp2"
  }
}

Provide the secret values via environment variables when running Packer, e.g.:

export AWS_ACCESS_KEY_ID=$(cat .aws_access_key)
export AWS_SECRET_ACCESS_KEY=$(cat .aws_secret_key)
packer build -var-file=variables.pkr.hcl template.pkr.hcl

2. Write the Packer template

Save the following as template.pkr.hcl. It uses the amazon-ebs builder with an AMI filter to pick the latest Amazon Linux 2 AMI in the chosen region, then installs Python 3 and nginx via a shell provisioner.

packer {
  required_plugins {
    amazon = { version = ">= 1.0.0", source = "github.com/hashicorp/amazon" }
  }
}

source "amazon-ebs" "base" {
  access_key      = var.aws_access_key
  secret_key      = var.aws_secret_key
  region          = var.region
  instance_type   = var.instance_type
  ssh_username    = var.ssh_username
  ami_filter {
    owners      = var.source_ami_filter["owners"]
    most_recent = true
    names       = [var.source_ami_filter["name"]]
  }
  ami_name        = "packer-base-{{timestamp}}"
  tags = {
    Purpose = "packer-demo"
    CreatedBy = "packer"
  }
}

build {
  sources = ["source.amazon-ebs.base"]

  provisioner "shell" {
    inline = [
      "sudo yum update -y",
      "sudo amazon-linux-extras install nginx1 -y",
      "sudo yum install -y python3",
      "sudo systemctl enable nginx",
      "sudo systemctl start nginx"
    ]
  }
}

3. Initialize, validate, and build

1. Initialize plugins (downloads the amazon‑ebs plugin if not present):

packer init template.pkr.hcl

1. Check the template syntax:

packer validate template.pkr.hcl

1. Run the build (this creates a temporary EC2 instance, runs provisioners, and registers an AMI):

packer build template.pkr.hcl

During the build, Packer prints lines like:

==> amazon-ebs.base: artifact,0,id=us-east-1:ami-0a1b2c3d4e5f6g7h8

The value after id= is the newly created AMI ID.

Expected checks

1. Verify AMI existence and state

Using the AWS CLI (replace ami-0a1b2c3d4e5f6g7h8 with the ID from the build output):

aws ec2 describe-images --image-ids ami-0a1b2c3d4e5f6g7h8 --query 'Images[0].{State:State,Tags:Tags}' --output table

You should see State = available and the tags you defined (Purpose=packer-demo, CreatedBy=packer).

2. Validate provisioned software

Launch a temporary instance from the AMI and test SSH access:

aws ec2 run-instances \
  --image-id ami-0a1b2c3d4e5f6g7h8 \
  --instance-type t3.micro \
  --key-name MyKeypair \
  --subnet-id subnet-xxxxxxxx \
  --security-group-ids sg-xxxxxxxx \
  --associate-public-ip-address \
  --query 'Instances[0].InstanceId' --output text

Wait for the instance to reach running state, retrieve its public IP, then:

ssh -i ~/.ssh/MyKeypair.pem ec2-user@<public-ip> "which python3 && nginx -v"

Expect a path to python3 and the nginx version string.

Recovery / rollback options

Because the build creates an AMI and an associated snapshot, you can clean up if the image is not needed:

1. Deregister the AMI:

aws ec2 deregister-image --image-id ami-0a1b2c3d4e5f6g7h8

1. Delete the snapshot(s) linked to the AMI (describe the AMI first to get snapshot IDs):

aws ec2 describe-images --image-ids ami-0a1b2c3d4e5f6g7h8 --query 'Images[0].BlockDeviceMappings[*].Ebs.SnapshotId' --output text

For each snapshot ID returned, run:

aws ec2 delete-snapshot --snapshot-id snap-xxxxxxxx

Note: Deregistering the AMI does not automatically delete snapshots; they must be removed separately to avoid storage charges.

Limitations and practical tips

• The amazon-ebs builder creates a temporary instance in the specified region; ensure your VPC and subnet allow outbound internet access for package updates.
• If you need to reuse the same AMI across multiple regions, copy it after build using aws ec2 copy-image.
• Avoid placing AWS secret keys directly in the template; the example uses variables sourced from environment variables or a secrets manager.
• For production pipelines, consider adding a post‑process step that runs packer inspect to confirm the artifact metadata before promoting the AMI.
