Creating a Custom Health Bar HUD Element with VGUI2 in Source Engine

Desired Outcome

Add a reusable VGUI2 panel that draws a health bar for the local player, updates each frame, and scales correctly across different resolutions.

Prerequisites

• Source SDK 2013 (or later) installed and a working mod or game project.
• Basic C++ knowledge and ability to rebuild the client DLL (client.dll).
• Access to VGUI2 headers (vgui_controls.h, vgui.h) and the engine interfaces.
• A backup of the original client.dll before making changes.

Procedure

1. Create the panel class

   Add a new header HealthBar.h and source file HealthBar.cpp to the client project.

   // HealthBar.h
   #pragma once
   #include

   class HealthBar : public vgui::Panel
   {
       DECLARE_CLASS_SIMPLE( HealthBar, vgui::Panel );
   public:
       HealthBar( vgui::Panel *parent, const char *name );
       virtual void OnThink() override;
       virtual void Paint() override;
   private:
       int m_iHealth; // cached health value
   };


   // HealthBar.cpp
   #include "HealthBar.h"
   #include "cbase.h"
   #include "vgui/ISurface.h"
   #include "vgui/ISystem.h"
   #include "vgui/ILocalize.h"

   using namespace vgui;

   HealthBar::HealthBar( Panel *parent, const char *name )
       : BaseClass( parent, name ), m_iHealth( 100 )
   {
       SetSize( 200, 20 ); // initial size; will be scaled later
       SetPos( 10, 10 );   // top‑left corner; will be adjusted in OnThink
       SetPaintBackgroundEnabled( true );
       SetBgColor( Color( 0, 0, 0, 120 ) ); // semi‑transparent dark background
   }

   void HealthBar::OnThink()
   {
       BaseClass::OnThink();
       C_BasePlayer *pPlayer = C_BasePlayer::GetLocalPlayer();
       if ( !pPlayer )
           return;
       int newHealth = pPlayer->GetHealth();
       if ( newHealth != m_iHealth )
       {
           m_iHealth = newHealth;
           // Force a repaint when health changes
           Repaint();
       }
       // Keep panel within screen bounds using proportional scaling
       int screenWide, screenTall;
       engine->GetScreenSize( screenWide, screenTall );
       int wide = vgui::scheme()->GetProportionalScaledValue( 200 );
       int tall = vgui::scheme()->GetProportionalScaledValue( 20 );
       SetSize( wide, tall );
       SetPos( 10, screenTall - tall - 10 ); // bottom‑left with margin
   }

   void HealthBar::Paint()
   {
       BaseClass::Paint();
       int wide, tall;
       GetSize( wide, tall );
       // Draw red health bar proportionally
       int healthWide = ( wide * m_iHealth ) / 100;
       surface()->DrawSetColor( Color( 200, 0, 0, 255 ) );
       surface()->DrawFilledRect( 0, 0, healthWide, tall );
       // Optional: draw a white border
       surface()->DrawSetColor( Color( 255, 255, 255, 255 ) );
       surface()->DrawOutlinedRect( 0, 0, wide, tall );
   }


2. Register the panel with VGUI

   In the client DLL’s initialization function (usually ClientDLL_Init or similar), add the panel to the VGUI hierarchy using the GET_PANEL macro.

   // Example snippet inside ClientDLL_Init
   #include "HealthBar.h"

   void ClientDLL_Init( void )
   {
       // ... existing init code ...
       // Create a panel under the game UI root
       vgui::Panel *pGameParent = g_pVGui->GetPanel( PANEL_GAMEUIDLL );
       new HealthBar( pGameParent, "HealthBar" );
       // ... rest of init ...
   }


3. Recompile and launch

   Build the client DLL (ensure you have the correct configuration for Debug or Release). Copy the resulting client.dll into your mod’s bin folder, then launch the game.

Expected Checks

• Visual confirmation: the health bar appears at the bottom‑left of the screen, scales with resolution, and shows a red fill proportional to the player’s health.
• Functional check: inflict damage or use a health kit; the bar should update instantly without noticeable FPS impact.
• Console verification: open the console (~) and run vgui_drawtree 1. The hierarchy should list a panel named HealthBar under PANEL_GAMEUIDLL.
• Error check: watch for any VGUI: warnings when developer 1 is enabled.

Recovery Options

• If the panel does not appear, verify that the GET_PANEL macro was called after VGUI is initialized (typically after g_pVGui->Initialize).
• Revert to a known‑working HUD element (e.g., the default crosshair) by commenting out the new HealthBar line and rebuilding.
• Check the build output for missing includes or linker errors; ensure vgui_controls.lib is linked.
• Run with debug symbols (-debug launch option) to catch assertions that may indicate threading violations (VGUI must be accessed on the main thread).
