Create Multiple Argo CD Applications from a Helm Values Directory Using ApplicationSet List Generator

Desired outcome

Automatically create an Argo CD Application for each subdirectory under values/ in a Git repository, so that every environment (e.g., dev, staging, prod) gets its own Helm release using the same chart but its own values file.

Prerequisites

• Argo CD version 2.8 or newer installed and accessible via argocd CLI or UI.
• Cluster access with sufficient permissions to create Applications and install Helm releases.
• A Git repository that Argo CD already tracks (the ApplicationSet will be committed to this repo). The repo must contain:
  • A charts/ directory with the Helm chart you want to deploy.
  • A values/ directory with subdirectories named after target environments, each containing a values.yaml file (e.g., values/dev/values.yaml).
• Read access to the repository for the Argo CD instance (so it can list the values/ directory during reconciliation).

Procedure

1. Define an ApplicationSet manifest. Save it as applicationset-values.yaml in the root of the Git repo that Argo CD manages.

apiVersion: argoproj.io/v1alpha1
kind: ApplicationSet
metadata:
  name: helm-values-appset
  namespace: argocd   # adjust if your Argo CD instance uses a different namespace
spec:
  generators:
  - git:
      repo: https://github.com/example/helm-values-repo.git
      revision: HEAD
      directories:
        - path: values/*

  template:
    metadata:
      name: '{{path.basename}}'   # yields dev, staging, prod
    spec:
      project: default
      source:
        repoURL: https://github.com/example/helm-chart-repo.git
        targetRevision: HEAD
        path: charts/my-chart
        helm:
          valueFiles:
            - {{path}}/values.yaml   # points to values/dev/values.yaml etc.
      destination:
        server: https://kubernetes.default.svc
        namespace: '{{path.basename}}'   # optional: separate namespace per env

Commit the manifest to the Argo CD managed Git repo and push.

1. Commit and push the manifest:

git add applicationset-values.yaml
git commit -m "Add ApplicationSet to generate apps from values/"
git push origin main   # adjust branch as needed

1. Argo CD reconciles the ApplicationSet and creates individual Applications.

Expected checks

• List generated Applications:

argocd app list --selector argocd.argoproj.io/application-set=helm-values-appset

Each entry should match a subdirectory name under values/ (e.g., dev, staging, prod).

• Verify sync and health:

argocd app get dev --sync

Look for Synced and Healthy in the STATUS and HEALTH columns.

• Confirm Helm release:

helm -n dev list | grep my-chart

or

kubectl get helmrelease -n dev

The release should show the chart version and the values from the corresponding values.yaml.

Recovery options

• If a generated Application fails (e.g., due to a malformed values file), you can delete it and let the ApplicationSet recreate it after fixing the file:

argocd app rm dev   # remove the problematic Application

After correcting values/dev/values.yaml, push the change; Argo CD will resync the ApplicationSet and create a new Application.

• To temporarily stop syncing a specific Application without deleting it:

argocd app sync dev --prune   # prune removes resources managed by the app if you want a clean stop

Or suspend sync:

argocd app suspend dev

• If the entire ApplicationSet is causing issues, you can delete the ApplicationSet manifest from the repo and push; Argo CD will garbage‑collect the generated Applications (unless you have set spec.syncPolicy.automated.prune to false).

Limitations and practical verification

• The List (or Git) generator requires the repository to be reachable during each ApplicationSet reconciliation. Network interruptions can cause the generator to see an incomplete file list, resulting in missing or stale Applications. Ensure the Argo CD instance has reliable access to the Git server.
• Avoid overly broad glob patterns (e.g., values/**) that could match non‑YAML files like README.md. Such entries will be treated as Applications and will likely fail validation because they lack a proper values.yaml. Keep the pattern specific to directories that contain a values.yaml file.
• To confirm that the generator is seeing the expected directories, you can temporarily add a debug ApplicationSet that logs the generated names:

apiVersion: argoproj.io/v1alpha1
kind: ApplicationSet
metadata:
  name: debug-values-appset
  namespace: argocd
spec:
  generators:
  - git:
      repo: https://github.com/example/helm-values-repo.git
      revision: HEAD
      directories:
        - path: values/*
  template:
    metadata:
      name: 'debug-{{path.basename}}'
    spec:
      source:
        repoURL: https://github.com/example/empty-repo.git
        path: .
      destination:
        server: https://kubernetes.default.svc
        namespace: default

After sync, list the debug Applications; their names will reveal what the generator saw. Remove the debug set once you confirm the list is correct.

Summary

By using an ApplicationSet with a Git (or List) generator that iterates over subdirectories in a values/ folder, you can automate the creation of Argo CD Applications for each environment, each pointing to the same Helm chart but using its own values file. Verify the generated Applications via the Argo CD CLI or UI, check the Helm releases in the target namespaces, and use the provided recovery steps to handle failures or to clean up.
