Create a Bar Chart in Kibana Lens from an Elasticsearch Index Pattern

Quick answer

In Kibana Lens you can build a bar chart of HTTP status codes by dragging the http.status field to the Split series bucket and keeping the default Metric as Count.

Step‑by‑step configuration

1. Open Kibana and go to Stack Management → Index Patterns. Confirm that an index pattern such as logstash-* exists and lists the http.status field.
2. Navigate to Visualize → Lens → Add to start a new visualization.
3. In the data panel, locate the http.status field (usually under the chosen index pattern). Drag it to the Buckets → Split series area.
4. Leave the Metric panel set to Count (the default aggregation).
5. Click Apply. Lens builds a terms aggregation on http.status and renders a bar chart where each bar corresponds to a status code.
6. Press Save, give the visualization a name, choose the appropriate Space, and confirm.

How Lens builds the chart

Lens translates the drag‑and‑drop actions into an Elasticsearch aggregation request. The Split series bucket becomes a terms aggregation on the keyword sub‑field of http.status. The Metric bucket stays as a count aggregation. The response returns buckets keyed by status code and their document counts, which Lens renders as vertical bars.

Limits and things to watch

• Lens only supports aggregations that match the visualization type. For a bar chart you can use terms, histogram, date histogram, or range aggregations on the bucket axis; custom Painless scripts are not available in the bucket configuration.
• High‑cardinality fields (e.g., request.url) can cause the terms aggregation to return thousands of buckets, leading to slow queries or timeouts. Limit the split to a low‑cardinality field or add a filter to reduce the dataset.
• Lens visualizations are saved as Kibana saved objects. Moving them between clusters requires exporting the JSON (Management → Saved Objects → Export) and importing on the target cluster; version mismatches may break the visualization.
• If you add new fields to the underlying index after creating the index pattern, you must refresh the pattern (Stack Management → Index Patterns → Refresh field list) before Lens shows them.

Common mistakes

• Saving the visualization to the wrong Space, which hides it from teammates who do not have access to that Space.
• Expecting Lens to display scripted fields defined in Kibana without reindexing; scripted fields are only available if they are mapped in Elasticsearch or defined as runtime fields.
• Leaving the Metric as something other than Count (e.g., Sum) when you actually want a frequency chart, resulting in unexpected values.
• Ignoring the query bar at the top of Lens; a stray filter can unintentionally narrow the data and produce an empty chart.

Verification steps

1. Open Kibana, go to Stack Management → Index Patterns and verify the pattern shows http.status.
2. In Visualize → Lens, add a new visualization, drag http.status to Split series, keep Metric as Count, click Apply and confirm a bar chart appears.
3. Check the browser developer console for no error messages and ensure the network request to Elasticsearch returns HTTP 200 with an aggregation payload.
4. Save the visualization to a Space, create a new dashboard, add the saved visualization, and verify it renders for other users with access to that Space.
