Controlled‑Rate Load Testing with Gatling Feeders and constantUsersPerSec

Desired outcome

Run a Gatling simulation that injects a fixed number of virtual users per second, feeds each user with a unique record from an external CSV file, and validates that each request returns HTTP 200. The test provides a steady arrival rate so you can measure throughput or latency under controlled load.

Prerequisites

1. Gatling 3.x installed (bundle or via Maven/Gradle).
2. A CSV file (e.g., users.csv) placed in src/test/resources/data/ with a header row and at least as many rows as the expected number of requests.
3. A local mock HTTP endpoint that returns 200 for GET requests (e.g., a simple WireMock stub or a lightweight Node/Express server).
4. Basic familiarity with Scala syntax and the Gatling DSL.
5. Sufficient heap space for the feeder; for files larger than a few hundred KB consider a JDBC feeder or batching.

Procedure

1. Prepare the feeder

Define a queue‑based feeder that will serve each record once, in order.

val csvFeeder = csv("data/users.csv").queue

2. Build the scenario

Each virtual user takes a record from the feeder, performs an HTTP GET, and checks the response status.

val httpProtocol = http
  .baseUrl("http://localhost:8080")   // adjust to your mock endpoint
  .acceptHeader("text/html,application/json")

val scn = scenario("ControlledRateGet")
  .feed(csvFeeder)
  .exec(
    http("GetResource")
      .get("/resource/${id}")   // assumes CSV column named 'id'
      .check(status.is(200))
  )

3. Configure the injection profile

Use constantUsersPerSec to inject a steady flow of users for a defined duration.

setUp(
  scn.inject(constantUsersPerSec(5).during(10.seconds))
).protocols(httpProtocol)

This configuration attempts to start 5 new users every second, for a total of 10 seconds → up to 50 users (subject to feeder availability).

4. Run the simulation

From the project root, execute:

./gatling.sh -s com.example.ControlledRateGetSimulation

If you use Maven:
mvn gatling:test -Dgatling.simulationClass=com.example.ControlledRateGetSimulation
Run the command with a user that has read access to the CSV and permission to bind to the mock endpoint’s port.
5. Expected checks

Console output should show lines like:


Feeder: csv data/users.csv (queue) - 50 records
constantUsersPerSec: 5.0 users/sec during 10.0s
Requests: 50 OK, 0 KO


The generated report under target/gatling/results//index.html should display a “Requests” table with the total count matching the number of feeder records consumed (or fewer if the feeder runs out early). All status checks should be reported as passed.

6. Practical verification

Open the report and confirm that the “Summary” section shows # requests = 50 (or the actual number fed).
Check the “Errors” tab – it should be empty.
Optionally, add a custom check to verify a field from the CSV appears in the response (e.g., .check(jsonPath("$.id").is(${id}))) and re‑run to see it reflected in the report.

Limitations

Feeder memory: Queue feeders materialize the entire CSV in memory. Very large files may cause heap pressure; consider switching to a JDBC feeder or reading the file in chunks.
Think‑time interference: constantUsersPerSec does not pause for think‑time. Any pause or thinkTime inside the scenario reduces the offered load below the configured rate. If you need think‑time, add it separately or adjust the injection rate upward.
Check overhead: Complex jsonPath or regex checks add CPU cost. Profile them with a short dry‑run before scaling to higher rates.

Recovery options
Running the simulation does not modify persistent state (assuming the mock endpoint is stateless). If the test inadvertently targets a production service, stop the test immediately with Ctrl+C in the terminal, verify the service’s health, and, if needed, restore any altered data from backups or re‑run idempotent setup scripts.
