Configuring SAML 2.0 SSO for Custom Applications with Okta

The Challenge: Establishing Trust Between Okta and a Custom App

When integrating a custom application with Okta for Single Sign-On (SSO), the primary hurdle is establishing a secure trust relationship via the Security Assertion Markup Language (SAML 2.0). Without a precise exchange of metadata and attribute mappings, the application will reject the identity assertions sent by Okta, leading to authentication failures or "Invalid Issuer" errors.

The goal is to configure Okta as the Identity Provider (IdP) and your application as the Service Provider (SP) so that users can authenticate once and gain access to your service without re-entering credentials.

Prerequisites

• An active Okta developer or enterprise account with Administrator privileges.
• A deployed custom application capable of processing SAML 2.0 assertions.
• The application's Assertion Consumer Service (ACS) URL (the endpoint where Okta sends the SAML response).
• The application's Entity ID (a unique identifier, often a URI, used to identify the SP).

Step-by-Step Configuration

1. Create the SAML Application in Okta

Navigate to the Okta Admin Console and follow these steps to define the service provider:

1. Go to Applications > Applications and select Create App Integration.
2. Select SAML 2.0 as the Sign-on method.
3. Enter the Single sign-on URL (your application's ACS URL) and the Audience URI (SP Entity ID). Note: These fields are case-sensitive; a mismatch here is the most common cause of handshake failures.
4. Save the integration.

2. Map User Attributes

Your application likely requires specific user data (claims) to create a session. You must map these in the General tab under SAML Settings:

• Username: Map to user.userName or user.email.
• Custom Attributes: Add attributes such as firstName or department if your application logic depends on them.

3. Exchange Metadata with the Application

To complete the trust circle, your application needs Okta's identity details. In the Okta application Sign On tab, locate the Setup section:

• Identity Provider Single Sign-On URL: Provide this to your app as the login destination.
• Identity Provider Issuer: The unique ID for your Okta instance.
• X.509 Certificate: Download the public certificate and upload it to your application's SAML configuration to allow the app to verify the digital signature of the assertions.

Technical Comparison: SP-Initiated vs. IdP-Initiated Flow

Feature	SP-Initiated Flow	IdP-Initiated Flow
Entry Point	User visits the App URL first.	User clicks app icon in Okta Dashboard.
Request	App sends AuthnRequest to Okta.	Okta sends SAMLResponse directly.
Security	Higher; protects against unsolicited responses.	Lower; susceptible to certain CSRF patterns.

Verification and Diagnostics

To verify the configuration, use a SAML tracer browser extension to inspect the HTTP POST request sent to your ACS URL. Check for the following:

• SAMLResponse XML: Ensure the matches your application's Entity ID exactly.
• Attribute Statements: Confirm that the tags contain the expected user values (e.g., the correct email address).
• Timestamp: Check the NotBefore and NotOnOrAfter values. If the application rejects the token despite correct credentials, ensure your server is synchronized via NTP to prevent clock skew errors.

Recovery and Maintenance

Certificate Rotation: SAML certificates expire. When rotating a certificate in Okta, you must download the new X.509 certificate and update your application's trust store immediately. Failure to do so will result in Invalid Signature errors for all users.

Rollback: If a configuration change breaks authentication, revert the Entity ID or ACS URL in the Okta Admin Console to the previously known working values. If a certificate update fails, re-upload the previous public key to the application to restore access.
