Configuring DMA for Zero‑CPU Overhead UART Reception on STM32 Using HAL

Desired Outcome

Transfer data from a UART peripheral to a memory buffer without the CPU consuming cycles for each byte. The DMA engine should load a predefined buffer size, signal completion via an interrupt, and leave the CPU free for other tasks.

Prerequisites

• STM32CubeIDE or equivalent toolchain with HAL libraries for the target device.
• Basic knowledge of UART, DMA, and interrupt handling in C.
• Hardware: an STM32 board with a UART port (e.g., STM32F103C8) and a serial terminal for testing.
• Ensure the board’s clock tree is configured so that the UART and DMA clocks are enabled.

Focused Procedure

1. Enable Clocks

   __HAL_RCC_USART1_CLK_ENABLE();
   __HAL_RCC_DMA2_CLK_ENABLE();


   These macros enable the peripheral clocks for USART1 and DMA2 (the DMA controller that services USART1 on many STM32F1 devices).

2. Configure UART

   UART_HandleTypeDef huart1;
   huart1.Instance = USART1;
   huart1.Init.BaudRate = 115200;
   huart1.Init.WordLength = UART_WORDLENGTH_8B;
   huart1.Init.StopBits = UART_STOPBITS_1;
   huart1.Init.Parity = UART_PARITY_NONE;
   huart1.Init.Mode = UART_MODE_TX_RX;
   huart1.Init.HwFlowCtl = UART_HWCONTROL_NONE;
   huart1.Init.OverSampling = UART_OVERSAMPLING_16;
   HAL_UART_Init(&huart1);


   Initialize the UART with the desired settings. The HAL function takes care of setting the USART registers.

3. Allocate DMA Channel

   Choose a DMA stream/channel that the UART can request. For example, on STM32F103C8, USART1_RX uses DMA2 Stream 2 Channel 4.

   DMA_HandleTypeDef hdma_usart1_rx;
   hdma_usart1_rx.Instance = DMA2_Stream2;
   hdma_usart1_rx.Init.Channel = DMA_CHANNEL_4;
   hdma_usart1_rx.Init.Direction = DMA_PERIPH_TO_MEMORY;
   hdma_usart1_rx.Init.PeriphInc = DMA_PINC_DISABLE;
   hdma_usart1_rx.Init.MemInc = DMA_MINC_ENABLE;
   hdma_usart1_rx.Init.PeriphDataAlignment = DMA_PDATAALIGN_BYTE;
   hdma_usart1_rx.Init.MemDataAlignment = DMA_MDATAALIGN_BYTE;
   hdma_usart1_rx.Init.Mode = DMA_NORMAL;
   hdma_usart1_rx.Init.Priority = DMA_PRIORITY_LOW;
   HAL_DMA_Init(&hdma_usart1_rx);


   Link the DMA handle to the UART handle so the HAL knows which DMA stream to use for reception.

   __HAL_LINKDMA(&huart1, hdmarx, hdma_usart1_rx);


4. Prepare Buffer and Start DMA

   Allocate a buffer that is aligned to 4‑byte boundaries to avoid bus faults. For a 256‑byte UART receive:

   #define UART_RX_BUF_LEN 256
   uint8_t uart_rx_buf[UART_RX_BUF_LEN] __attribute__((aligned(4)));


   Start the DMA transfer in interrupt mode:

   HAL_UART_Receive_DMA(&huart1, uart_rx_buf, UART_RX_BUF_LEN);


   The HAL function configures the DMA registers, enables the transfer‑complete interrupt, and starts the stream.

5. Enable DMA Transfer‑Complete Interrupt

   The HAL library automatically sets the DMA interrupt priority in the NVIC when you call HAL_UART_Receive_DMA. Verify that the IRQ is enabled:

   HAL_NVIC_SetPriority(DMA2_Stream2_IRQn, 5, 0);
   HAL_NVIC_EnableIRQ(DMA2_Stream2_IRQn);


   Adjust the priority to suit your application’s interrupt hierarchy.

6. Implement the ISR

   The HAL provides a weakly‑linked default handler that calls HAL_DMA_IRQHandler. Override it to set a flag when the transfer completes.

   volatile bool dma_rx_done = false;

   void DMA2_Stream2_IRQHandler(void) {
       HAL_DMA_IRQHandler(&hdma_usart1_rx);
       if (HAL_DMA_GetState(&hdma_usart1_rx) == HAL_DMA_STATE_READY) {
           dma_rx_done = true;
       }
   }


   In the main loop, poll dma_rx_done or use a semaphore if you’re in an RTOS environment.

7. Verify the Transfer
   • After the ISR sets dma_rx_done, compare uart_rx_buf against a known pattern you sent from the terminal.
   • Use a debugger to inspect the DMA registers: CCR, CMAR, CPAR, CNDTR. Verify CMAR points to uart_rx_buf, CPAR points to USART1->DR, and CNDTR equals UART_RX_BUF_LEN during transfer.
   • Measure CPU load with a profiling tool or by toggling an LED in a tight loop; the LED should remain steady while the DMA runs.
8. Recovery Options
   • If dma_rx_done never becomes true, check for DMA errors: HAL_DMA_GetError(&hdma_usart1_rx). If an error is returned, call HAL_DMA_Abort(&hdma_usart1_rx) and re‑start the transfer.
   • For long‑running data streams, switch the DMA mode to DMA_CIRCULAR and use a ring buffer. Then, in the ISR, compute the number of bytes received by reading CNDTR and updating a head pointer.
   • When the UART is re‑initialized (e.g., after a baud‑rate change), always re‑link the DMA handle with __HAL_LINKDMA before starting a new transfer.

Limitations and Practical Checks

• Not all STM32 families expose a DMA stream for every UART. Verify the datasheet or reference manual for the correct stream/ channel.
• DMA buffers must be aligned to at least 4 bytes for Cortex‑M3/M4 devices; misalignment can trigger bus faults.
• On devices with a limited number of DMA streams, allocating all streams to high‑priority tasks can starve other peripherals. Plan channel usage early.
• When using circular mode, ensure that the CPU does not read the buffer while DMA writes to it. Use double buffering or critical sections.

Conclusion

By following the steps above, you can off‑load UART reception to the DMA engine, freeing the CPU for other real‑time tasks. The HAL library abstracts low‑level register manipulation, but careful attention to buffer alignment, interrupt handling, and error recovery is essential for robust operation.
