Configure your App Service or Azure Functions app to use Microsoft Entra sign-in

Select another authentication provider to jump to it.

• Microsoft Entra
• Facebook
• Google
• GitHub
• X
• OpenID Connect provider
• Sign in with Apple (preview)

This article shows you how to configure authentication for Azure App Service or Azure Functions so that your app signs in users with the Microsoft identity platform (Microsoft Entra) as the authentication provider.

Choose a tenant for your application and its users

Before your application can sign in users, you need to register it in a workforce tenant or an external tenant. If you're making your app available to employee or business guests, register your app in a workforce tenant. If your app is for consumers and business customers, register it in an external tenant.

1. Sign in to the Azure portal and go to your App Service app or Functions app.

2. On your app's left menu, select Settings > Authentication, and then select Add identity provider.

3. On the Add an identity provider page, select Microsoft as the Identity provider value to sign in Microsoft and Microsoft Entra identities.

4. Under Choose a tenant for your application and its users, select either:

   • Workforce configuration (current tenant) for employees and business guests
   • External configuration for consumers and business customers

Choose the app registration

The App Service authentication feature can automatically create an app registration for you, or you can use a registration that you or a directory admin creates separately.

Create a new app registration automatically, unless you need to create an app registration separately. You can customize the app registration in the Microsoft Entra admin center later if you want.

The following situations are the most common cases for using an existing app registration:

• Your account doesn't have permissions to create app registrations in your Microsoft Entra tenant.
• You want to use an app registration from a different Microsoft Entra tenant than the one that contains your app. This is always the case if you selected External configuration when you chose a tenant.
• The option to create a new registration isn't available for government clouds.

• Workforce configuration
• External configuration

Option 1: Create and use a new app registration

1. Select Create new app registration.

2. For Name, enter the name of the new app registration.

3. Select the Supported account type value:

   • Current tenant - Single tenant: Accounts in this organizational directory only. All user and guest accounts in your directory can use your application or API. Use this option if your target audience is internal to your organization.
   • Any Microsoft Entra directory - Multitenant: Accounts in any organizational directory. All users with a work or school account from Microsoft can use your application or API. These accounts include schools and businesses that use Office 365. Use this option if your target audience is business or educational customers and to enable multitenancy.
   • Any Microsoft Entra directory & personal Microsoft accounts: Accounts in any organizational directory and personal Microsoft accounts (for example, Skype or Xbox). All users with a work or school account, or a personal Microsoft account, can use your application or API. It includes schools and businesses that use Office 365, along with personal accounts that are used to sign in to services like Xbox and Skype. Use this option to target the widest set of Microsoft identities and to enable multitenancy.
   • Personal Microsoft accounts only: Personal accounts that are used to sign in to services like Xbox and Skype. Use this option to target the widest set of Microsoft identities.

You can change the name of the registration or the supported account types later if you want.

A client secret is created as a slot-sticky application setting named MICROSOFT_PROVIDER_AUTHENTICATION_SECRET. If you want to manage the secret in Azure Key Vault, you can update that setting later to use Key Vault references. Alternatively, you can change this to use an identity instead of a client secret.

Option 2: Use an existing registration created separately

To use an existing registration, select either:

• Pick an existing app registration in this directory: Then select an app registration from the dropdown list.

• Provide the details of an existing app registration: Then provide:

  • Application (client) ID.

  • Client secret (recommended): A secret value that the application uses to prove its identity when it requests a token. This value is saved in your app's configuration as a slot-sticky application setting named MICROSOFT_PROVIDER_AUTHENTICATION_SECRET. If the client secret isn't set, sign-in operations from the service use the OAuth 2.0 implicit grant flow, which we don't recommend.

    You can also configure the application to use an identity instead of a client secret.

  • Issuer URL. This URL takes the form <authentication-endpoint>/<tenant-id>/v2.0. Replace <authentication-endpoint> with the authentication endpoint value that's specific to the cloud environment. For example, a workforce tenant in global Azure would use https://login.microsoftonline.com as its authentication endpoint.

    You can find this value in the Microsoft Entra admin center. Go to App registrations, select your app, and then select Endpoints. Copy the OpenID Connect metadata document endpoint for your tenant, and then remove /.well-known/openid-configuration from the end of the URL. For example, if the metadata endpoint is https://login.microsoftonline.com/<tenant-id>/v2.0/.well-known/openid-configuration, use https://login.microsoftonline.com/<tenant-id>/v2.0 as the issuer URL.

    Note

    If you created your identity provider using the express setup (Option 1), the issuer URL is automatically set to use the legacy https://sts.windows.net endpoint. To align with current Microsoft Entra ID best practices, edit your identity provider and update the issuer URL to use https://login.microsoftonline.com/<tenant-id>/v2.0 instead.

If you need to manually create an app registration in a workforce tenant, see Register an application with the Microsoft identity platform. As you go through the registration process, be sure to note the application (client) ID and client secret values.

During the registration process, in the Redirect URIs section, select Web for platform, and enter a redirect URI. For example, enter https://contoso.azurewebsites.net/.auth/login/aad/callback.

Now, modify the app registration:

1. On the left pane, select Expose an API > Add > Save. This value uniquely identifies the application when it's used as a resource, which allows tokens that grant access to be requested. The value is a prefix for scopes that you create.

   For a single-tenant app, you can use the default value, which is in the form api://<application-client-id>. You can also specify a more readable URI like https://contoso.com/api, based on one of the verified domains for your tenant. For a multitenant app, you must provide a custom URI. For more information about accepted formats for app ID URIs, see Security best practices for application properties in Microsoft Entra ID.

2. Select Add a scope, and then:

   1. In Scope name, enter user_impersonation.
   2. In Who can consent, select Admins and users if you want to allow users to consent to this scope.
   3. Enter the consent scope name. Enter a description that you want users to see on the consent page. For example, enter Access application-name.
   4. Select Add scope.

3. (Recommended) Create a client assertion for the app. To create a client secret:

   1. On the left pane, select Certificates & secrets > Client secrets > New client secret.
   2. Enter a description and expiration, and then select Add.
   3. In the Value field, copy the client secret value. After you move away from this page, it doesn't appear again.

   You can also configure the application to use an identity instead of a client secret.

4. (Optional) To add multiple reply URLs, select Authentication.

Option 1: Create and use a new app registration

1. Select Create new app registration.

2. For Select a tenant, take one of the following actions:

   • Select an existing tenant to use.

   • Select Create new, and then:

     1. On the Create a tenant page, add the Tenant Name and Domain Name values.

     2. Select a Location value, and then select Review and create > Create. The tenant creation process takes a few minutes.

     For more information about creating a tenant, see Use your Azure subscription to create an external tenant.

Set up sign-in

1. Select Configure to configure external authentication for the new tenant.

2. The browser opens Configure customer authentication.

3. Select or create a user flow. The user flow defines the sign-in methods that your external users can use. Each app can only have one user flow, but you can reuse the same user flow for multiple apps.

   Take one of the following actions:

   • Select a user flow from the dropdown list.

   • Select Create new, and then:

     1. For Name, enter a name for the user flow.

     2. Select the sign-in method for your external users.

        Email and password and Email and one-time passcode are already configured in the new tenant. You can also add Google or Facebook as identity providers.

     3. Select Create.

Customize branding

1. Select Next to customize branding.

2. Add your logo, select a background color, and select a sign-in layout.

3. Select Next, and then select Yes, update the changes to accept the branding changes.

4. On the Review tab, select Configure to confirm the external tenant update.

   The browser opens to the Add an identity provider page.

Option 2: Use an existing registration created separately

To use an existing registration, select Provide the details of an existing app registration. Then provide values for:

• Application (client) ID
• Client secret
• Issuer URL. In the Microsoft Entra admin center, go to App registrations, select your app, and then select Endpoints. Copy the OpenID Connect metadata document endpoint for your tenant, and then remove /.well-known/openid-configuration from the end of the URL. For example, if the metadata endpoint is https://login.microsoftonline.com/<tenant-id>/v2.0/.well-known/openid-configuration, use https://login.microsoftonline.com/<tenant-id>/v2.0 as the issuer URL.

If you need to manually create an app registration in an external tenant, see Register an app in your external tenant.

During the registration process, in the Redirect URIs section, select Web for platform, and enter a redirect URI. For example, enter https://contoso.azurewebsites.net/.auth/login/aad/callback.

Now, modify the app registration:

1. On the left pane, select Expose an API > Add > Save. This value uniquely identifies the application when it's used as a resource, which allows tokens that grant access to be requested. The value is a prefix for scopes that you create.

   For a single-tenant app, you can use the default value, which is in the form api://<application-client-id>. You can also specify a more readable URI like https://contoso.com/api, based on one of the verified domains for your tenant. For a multitenant app, you must provide a custom URI. For more information about accepted formats for app ID URIs, see Security best practices for application properties in Microsoft Entra ID.

2. Select Add a scope, and then:

   1. In Scope name, enter user_impersonation.
   2. In Who can consent, select Admins and users if you want to allow users to consent to this scope.
   3. Enter the consent scope name. Then enter a description that you want users to see on the consent page. For example, enter Access application-name.
   4. Select Add scope.

3. (Optional) Create a client secret:

   1. On the left pane, select Certificates & secrets > Client secrets > New client secret.
   2. Enter a description and expiration, and then select Add.
   3. In the Value field, copy the client secret value. After you move away from this page, it doesn't appear again.

4. (Optional) To add multiple reply URLs, select Authentication.

Configure additional checks

Additional checks determine which requests are allowed to access your application. You can customize this behavior now, or you can adjust these settings later from the main Authentication page by selecting Edit next to Authentication settings.

For Client application requirement, choose whether to:

• Allow requests only from this application itself.
• Allow requests from specific client applications.
• Allow requests from any application (not recommended).

For Identity requirement, choose whether to:

• Allow requests from any identity.
• Allow requests from specific identities.

For Tenant requirement, choose whether to:

• Allow requests only from the same tenant as the app registration.
• Allow requests from specific tenants.
• Use default restrictions based on the app registration's tenant.

For Allowed token audiences, add any audience values that your app should accept in the aud claim of incoming access tokens. You commonly need this setting when clients request tokens by using the app registration's Application ID URI, such as api://<application-client-id> or a custom URI like https://contoso.com/api. The app registration's client ID is already accepted by default, so you typically add values here only if your app accepts another audience format.

Your app might still need to make other authorization decisions in code. For more information, see Use a built-in authorization policy later in this article.

Configure authentication settings

Authentication settings determine how your application responds to unauthenticated requests. The default selections redirect all requests to sign in with this new provider. You can customize this behavior now, or you can adjust these settings later from the main Authentication page by selecting Edit next to Authentication settings. For more information, see Authentication flow.

For Restrict access, decide whether to:

• Require authentication.
• Allow unauthenticated access.

For Unauthenticated requests, choose error options:

• HTTP 302 Found redirect: recommended for websites
• HTTP 401 Unauthorized: recommended for APIs
• HTTP 403 Forbidden
• HTTP 404 Not found

Select Token store (recommended). The token store collects, stores, and refreshes tokens for your application. You can disable this behavior later if your app doesn't need tokens or if you need to optimize performance.

Allowed token audiences

The Allowed token audiences setting lets you restrict which access tokens are accepted by your App Service or Azure Functions app based on the token audience (aud claim).

By default, App Service authentication accepts tokens that are issued for the app registration associated with this application. If your app exposes multiple APIs, uses multiple application IDs, or is accessed through custom application ID URIs, you may need to explicitly configure additional allowed audiences.

When configured, only access tokens whose aud claim matches one of the allowed audiences are accepted.

Typical values include:

• The Application (client) ID of the app registration
• The Application ID URI (for example, api://<application-client-id> or a custom URI such as https://contoso.com/api)

You can configure this setting from the Authentication page in the Azure portal:

1. Go to your App Service or Azure Functions app.
2. Select Settings > Authentication.
3. Select Edit for the Microsoft identity provider.
4. Under Allowed token audiences, add one or more allowed audience values.

This setting is useful when:

• Your app is called by multiple client applications using different resource identifiers.
• You use a custom Application ID URI for your API.
• You want to explicitly limit which tokens are accepted by the app.

If this list is configured, any token whose audience does not match one of the configured values is rejected.

Add the identity provider

If you selected workforce configuration, you can select Next: Permissions and add any Microsoft Graph permissions that the application needs. These permissions are added to the app registration, but you can also change them later. If you selected external configuration, you can add Microsoft Graph permissions later.

• Select Add.

You're now ready to use the Microsoft identity platform for authentication in your app. The provider is listed on the Authentication page. From there, you can edit or delete this provider configuration.

For an example of configuring Microsoft Entra sign-in for a web app that accesses Azure Storage and Microsoft Graph, see Add app authentication to your web app.

Authorize requests

By default, App Service authentication handles only authentication. It determines whether the caller is who they say they are. Authorization, determining whether that caller should have access to some resource, is a step beyond authentication. For more information, see Authorization basics.

Your app can make authorization decisions in code. App Service authentication provides some built-in checks, which can help, but they alone might not be sufficient to cover the authorization needs of your app. The following sections cover these capabilities.

Tip

Multitenant applications should validate the issuer and tenant ID of the request as part of this process to make sure the values are allowed. When App Service authentication is configured for a multitenant scenario, it doesn't validate which tenant the request comes from. An app might need to be limited to specific tenants, based on whether the organization has signed up for the service (for example). See Update your code to handle multiple issuer values.

Perform validations from application code

When you perform authorization checks in your app code, you can use the claims information that App Service authentication makes available. For more information, see Access user claims in app code.

The injected x-ms-client-principal header contains a Base64-encoded JSON object with the claims asserted about the caller. By default, these claims go through a claims mapping, so the claim names might not always match what you would see in the token. For example, the tid claim is mapped to http://schemas.microsoft.com/identity/claims/tenantid instead.

You can also work directly with the underlying access token from the injected x-ms-token-aad-access-token header.

Use a built-in authorization policy

The created app registration authenticates incoming requests for your Microsoft Entra tenant. By default, it also lets anyone within the tenant access the application. This approach is fine for many applications. Some applications need to restrict access further by making authorization decisions.

Your application code is often the best place to handle custom authorization logic. However, for common scenarios, the Microsoft identity platform provides built-in checks that you can use to limit access.

This section shows how to enable built-in checks by using the App Service authentication V2 API. Currently, the only way to configure these built-in checks is by using Azure Resource Manager templates or the REST API.

Within the API object, the Microsoft Entra identity provider configuration has a validation section that can include a defaultAuthorizationPolicy object, as shown in the following structure:

{
    "validation": {
        "defaultAuthorizationPolicy": {
            "allowedApplications": [],
            "allowedPrincipals": {
                "identities": []
            }
        }
    }
}

Property	Description
defaultAuthorizationPolicy	A group of requirements that must be met for access to the app. Access is granted based on a logical AND over each of its configured properties. When allowedApplications and allowedPrincipals are both configured, the incoming request must satisfy both requirements to be accepted.
allowedApplications	An allowlist of string application client IDs that represent the client resource that calls into the app. When this property is configured as a nonempty array, only tokens obtained by an application specified in the list are accepted. This policy evaluates the appid or azp claim of the incoming token, which must be an access token. See Payload claims.
allowedPrincipals	A group of checks that determine if the principal that the incoming request represents can access the app. Satisfaction of allowedPrincipals is based on a logical OR over its configured properties.
identities (under allowedPrincipals)	An allowlist of string object IDs that represent users or applications that have access. When this property is configured as a nonempty array, the allowedPrincipals requirement can be satisfied if the user or application that the request represents is specified in the list. There's a limit of 500 characters (total) across the list of identities. This policy evaluates the oid claim of the incoming token. See Payload claims.

Also, you can configure some checks through an application setting, regardless of the API version that you're using. You can configure the WEBSITE_AUTH_AAD_ALLOWED_TENANTS application setting with a comma-separated list of up to 10 tenant IDs; for example, aaaabbbb-0000-cccc-1111-dddd2222eeee. This setting can require that the incoming token is from one of the specified tenants, as specified by the tid claim.

You can configure the WEBSITE_AUTH_AAD_REQUIRE_CLIENT_SERVICE_PRINCIPAL application setting to true or 1, to require the incoming token to include an oid claim. If you configured allowedPrincipals.identities, this setting is ignored and treated as true because the oid claim is checked against this provided list of identities.

Requests that fail these built-in checks get an HTTP 403 Forbidden response.

Use a managed identity instead of a secret

Instead of configuring a client secret for your app registration, you can configure an application to trust a managed identity. Using an identity instead of a secret means you don't have to manage a secret. You don't have secret expiration events to handle, and you don't have the same level of risk associated with possibly disclosing or leaking that secret.

The identity allows you to create a federated identity credential, which can be used instead of a client secret as a client assertion. This approach is available only for workforce configurations.

You can use the steps in this section to configure your App Service or Azure Functions resource to use this pattern. The steps here assume that you already set up an app registration by using one of the supported methods, and that you have a secret defined already.

1. Create a user-assigned managed identity resource according to these instructions.

2. Assign that identity to your App Service or Azure Functions resource.

   Important

   The user-assigned managed identity that you create should only be assigned to the App Service or Azure Functions application through this registration. If you assign the identity to another resource, you're giving that resource unnecessary access to your app registration.

3. Note down the Object ID and Client ID values of the managed identity. You'll need the object ID to create a federated identity credential in the next step. You'll use the managed identity's client ID in a later step.

4. Follow the Microsoft Entra ID instructions to configure a federated identity credential on an existing application. Those instructions also include sections for updating application code, which you can skip.

5. Add a new application setting named OVERRIDE_USE_MI_FIC_ASSERTION_CLIENTID. Set its value to the managed identity's Client ID value that you obtained in a previous step. Don't use the client ID of your app registration. Make sure to mark this application setting as slot-sticky.

6. In the built-in authentication settings for your app resource, set Client secret setting name to OVERRIDE_USE_MI_FIC_ASSERTION_CLIENTID.

   To make this change by using the Azure portal:

   1. Go back to your App Service or Azure Functions resource and select the Authentication tab.
   2. In the Identity provider section, for the Microsoft entry, select the icon in the Edit column.
   3. In the Edit identity provider dialog, open the dropdown list for Client secret setting name and select OVERRIDE_USE_MI_FIC_ASSERTION_CLIENTID.
   4. Select Save.

   To make this change by using the REST API:

   • Set the clientSecretSettingName property to OVERRIDE_USE_MI_FIC_ASSERTION_CLIENTID. You can find this property under properties > identityProviders > azureActiveDirectory > registration.

7. Verify that the application works as you expect. You should be able to successfully perform a new sign-in action.

When you're satisfied with the behavior using a managed identity, remove the existing secret:

1. Make sure that your app code doesn't take a dependency on the application setting. If it does, follow the instructions to update your application code to request an access token.

2. Remove the application setting that previously held your secret. The name of this application setting is the previous Client secret setting name value, before you set it to OVERRIDE_USE_MI_FIC_ASSERTION_CLIENTID.

3. Sign in to the Microsoft Entra admin center by using the tenant that contains your app registration. Go to the app registration again.

4. Under Certificates & secrets, select Client secrets and remove the client secret.

Your app is now configured to use Microsoft Entra ID authentication without secrets.

Configure client apps to access App Service

In prior sections, you registered your App Service or Azure Functions app to authenticate users. The following sections explain how to register native clients or daemon apps in Microsoft Entra. These clients or apps can request access to APIs exposed by App Service on behalf of users or themselves, such as in an N-tier architecture. If you only want to authenticate users, the steps in the following sections aren't required.

Native client application

You can register native clients to request access to your App Service app's APIs on behalf of a signed-in user:

1. On the Azure portal menu, select Microsoft Entra ID.

2. On the left pane, select Manage > App registrations. Then select New registration.

3. On the Register an application pane, for Name, enter a name for your app registration.

4. In Redirect URI, select Public client/native (mobile & desktop) and enter the redirect URL. For example, enter https://contoso.azurewebsites.net/.auth/login/aad/callback.

5. Select Register.

6. After the app registration is created, copy the value of Application (client) ID.

   Note

   For a Microsoft Store application, use the package SID as the URI instead.

7. On the left pane, select Manage > API permissions. Then select Add a permission > My APIs.

8. Select the app registration that you created earlier for your App Service app. If you don't see the app registration, be sure to add the user_impersonation scope in the app registration.

9. Under Delegated permissions, select user_impersonation, and then select Add permissions.

You've now configured a native client application that can request access your App Service app on behalf of a user.

Daemon client application (service-to-service calls)

In an N-tier architecture, your client application can acquire a token to call an App Service or Azure Functions app on behalf of the client app itself, not on behalf of a user. This scenario is useful for non-interactive daemon applications that perform tasks without a logged-in user. It uses the standard OAuth 2.0 client credentials grant. For more information, see Microsoft identity platform and the OAuth 2.0 client credentials flow.

1. On the Azure portal menu, select Microsoft Entra ID.

2. On the left pane, select Manage > App registrations. Then select New registration.

3. On the Register an application pane, for Name, enter a name for your app registration.

4. For a daemon application, you don't need a redirect URI, so you can keep the Redirect URI box empty.

5. Select Register.

6. After the app registration is created, copy the value of Application (client) ID.

7. On the left pane, select Manage > Certificates & secrets. Then select Client secrets > New client secret.

8. Enter a description and expiration, and then select Add.

9. In the Value field, copy the client secret value. After you move away from this page, it doesn't appear again.

You can now request an access token by using the client ID and client secret. Set the resource parameter to the Application ID URI value of the target app. The resulting access token can then be presented to the target app via the standard OAuth 2.0 Authorization header. App Service authentication validates and uses the token to indicate that the caller is authenticated. In this case, the caller is an application, not a user.

This approach allows any client application in your Microsoft Entra tenant to request an access token and authenticate to the target app. If you also want to enforce authorization to allow only certain client applications, you must perform extra configuration.

1. Define an app role in the manifest of the app registration that represents the App Service or Azure Functions app that you want to protect.

2. On the app registration that represents the client that needs to be authorized, select API permissions > Add a permission > My APIs.

3. Select the app registration that you created earlier. If you don't see the app registration, make sure that you added an app role.

4. Under Application permissions, select the app role that you created earlier. Then select Add permissions.

5. Select Grant admin consent to authorize the client application to request the permission.

   Similar to the previous scenario (before you added any roles), you can now request an access token for the same target resource. The access token includes a roles claim that contains the app roles that were authorized for the client application.

Within the target App Service or Azure Functions app code, you can now validate that the token has the expected roles. App Service authentication doesn't perform this validation. For more information, see Access user claims in app code.

You've now configured a daemon client application that can access your App Service app by using its own identity.

Best practices

Regardless of the configuration that you use to set up authentication, the following best practices keep your tenant and applications more secure:

• Configure each App Service app with its own app registration in Microsoft Entra.
• Give each App Service app its own permissions and consent.
• Avoid permission sharing between environments. Use separate app registrations for separate deployment slots. When you're testing new code, this practice can help prevent problems from affecting the production app.

Migrate to Microsoft Graph

Some older apps might be set up with a dependency on Azure AD Graph, which is deprecated and scheduled for full retirement. For example, your app code might call Azure AD Graph to check group membership as part of an authorization filter in a middleware pipeline. Apps should move to Microsoft Graph. For more information, see Migrate your apps from Azure AD Graph to Microsoft Graph.

During this migration, you might need to make some changes to your configuration of App Service authentication. After you add Microsoft Graph permissions to your app registration, you can:

• Update the Issuer URL value to include the /v2.0 suffix if it doesn't already.

• Remove requests for Azure AD Graph permissions from your sign-in configuration. The properties to change depend on which version of the management API you're using:

  • If you're using the V1 API (/authsettings), this setting is in the additionalLoginParams array.
  • If you're using the V2 API (/authsettingsV2), this setting is in the loginParameters array.

  You need to remove any reference to https://graph.windows.net, for example. This change includes the resource parameter, which the /v2.0 endpoint doesn't support. It also includes any scopes that you specifically request that are from Azure AD Graph.

  You also need to update the configuration to request the new Microsoft Graph permissions that you set up for the application registration. In many cases, you can use the default scope to simplify this setup. To do so, add a new sign-in parameter: scope=openid profile email https://graph.microsoft.com/.default.

With these changes, when App Service authentication tries to sign in, it no longer requests permissions to Azure AD Graph. Instead, it gets a token for Microsoft Graph. Any use of that token from your application code also needs to be updated, as described in Migrate your apps from Azure AD Graph to Microsoft Graph.
