Configure Mattermost Interactive Message Buttons via Outgoing Webhooks

Why Use Interactive Buttons?

Interactive Message Buttons let you attach actionable controls to a Mattermost post. When a user clicks a button, Mattermost sends an HTTP POST to a configured webhook URL, allowing you to trigger custom logic without leaving the channel. This is ideal for quick approvals, ticket creation, or any workflow that benefits from a single click.

Set Up the Outgoing Webhook

1. Log in as a system administrator. 2. Navigate to System Console > Integrations > Outgoing Webhooks. 3. Click Add outgoing webhook and fill in the form:

• Name: e.g., Help Button
• Channel: Choose the channel(s) where the button should appear.
• Trigger Words: Set a keyword such as !help.
• Callback URL: The endpoint that will receive the button click payload, e.g., https://example.com/mattermost/webhook.
• Content Type: application/json (required).
• Response Type: For an immediate reply, leave as in_channel or ephemeral depending on visibility.

After saving, note the Webhook Token displayed. It will be used to verify incoming requests.

Craft the Post with a Button

When a user posts the trigger word (!help), Mattermost will send a payload to your webhook URL. Your service must respond with a JSON object that includes an attachments array containing an actions array. Each action defines a button.

{
  "response_type": "ephemeral",
  "text": "Need help?",
  "attachments": [
    {
      "actions": [
        {
          "name": "help_button",
          "integration": {
            "url": "https://example.com/mattermost/webhook",
            "context": {
              "action": "request_help"
            }
          },
          "type": "button",
          "value": "request_help"
        }
      ]
    }
  ]
}

Key points:

• response_type controls who sees the reply. ephemeral shows only the user who triggered the button.
• The integration.url must match the webhook URL configured in the console.
• Button text is limited to 30 characters.
• A post can contain up to 5 actions.

Handle the Button Click

When a user clicks the button, Mattermost sends a POST to the webhook URL with a JSON payload that includes the button’s value and the original message context. Below is a minimal Node.js Express handler that validates the signature, logs the payload, and returns an ephemeral confirmation.

const express = require('express');
const crypto = require('crypto');
const bodyParser = require('body-parser');

const app = express();
app.use(bodyParser.json());

const WEBHOOK_TOKEN = process.env.MATTERMOST_WEBHOOK_TOKEN;

function verifySignature(req) {
  const signature = req.headers['mattermost-token'];
  return signature === WEBHOOK_TOKEN;
}

app.post('/mattermost/webhook', (req, res) => {
  if (!verifySignature(req)) {
    return res.status(401).send('Invalid token');
  }
  console.log('Received payload:', JSON.stringify(req.body, null, 2));

  // Example: if the button value is 'request_help', respond accordingly
  if (req.body.actions && req.body.actions[0].value === 'request_help') {
    return res.json({
      response_type: 'ephemeral',
      text: 'Your help request has been logged. We will assist you shortly.'
    });
  }

  res.json({
    response_type: 'ephemeral',
    text: 'Unknown action.'
  });
});

app.listen(3000, () => console.log('Webhook listening on port 3000'));

Run this service behind HTTPS and expose the public URL to Mattermost. The webhook will now respond to button clicks.

Limitations & Common Pitfalls

Aspect	Limit
Maximum actions per post	5
Button text length	30 characters
Webhook timeout	10 seconds (default)

Typical mistakes:

• Using application/x-www-form-urlencoded instead of application/json – Mattermost expects JSON.
• Not URL‑encoding the payload – button values containing spaces or special characters can break the request.
• Ignoring the response_type field – without it, the reply may appear publicly.
• Performing heavy processing in the handler – exceeding the timeout will return a generic error to the user.

Verification Checklist

1. Deploy the webhook service and confirm it accepts HTTPS POST requests.
2. Post the trigger word (!help) in the configured channel.
3. Verify the button appears and click it.
4. Check the service logs for the received payload.
5. Ensure the user sees the expected ephemeral confirmation.
6. Test a non‑existent button value to see the fallback response.

When to Use This Pattern

Use interactive buttons when you want a quick, in‑channel trigger that initiates server‑side logic. Examples include:

• Ticket escalation or assignment.
• Pull request review requests.
• Automated reminders or polls.

For more complex interactions (e.g., multi‑step forms), consider using Mattermost’s Modal Dialogs or Slash Commands instead.
