Configure LDAP Authentication and Team-Based RBAC in Portainer

Desired Outcome

Configure Portainer to authenticate users against an LDAP directory and automatically assign Portainer roles based on LDAP group membership. This enables team-based access control without manually creating users in Portainer.

Prerequisites

• Portainer server version 2.0 or newer running and reachable via its web UI.
• Administrator account in Portainer.
• Access to an LDAP server (e.g., Active Directory or OpenLDAP) with network connectivity from the Portainer host.
• LDAP bind account that has read-only permission to search users and groups.
• (Optional) LDAPS or STARTTLS configured if the LDAP server requires encrypted connections.

Procedure

1. Log in to Portainer as an administrator and open the Settings menu (gear icon) → Authentication.
2. Select the LDAP tab.
3. Fill in the fields as shown below (replace placeholders with your actual values):

Server URL: ldap://ldap.example.com:389
Bind DN: cn=readonly,ou=serviceAccounts,dc=example,dc=com
Bind Password: ********
User Search Base: ou=Users,dc=example,dc=com
User Search Filter: (uid=%s)
Group Search Base: ou=Groups,dc=example,dc=com
Group Search Filter: (memberUid=%s)
Enable TLS: false   # set to true if using LDAPS or STARTTLS

Expected Checks

1. Log out of Portainer, then log in using the username and password of an LDAP user that belongs to a mapped group (e.g., jdoo@example.com).
2. After login, the user’s full name should appear in the top‑right corner and the team name(s) should be listed under the user’s profile (accessible via the user icon → My Profile).
3. Attempt an action that is permitted by the assigned role. For a Regular user, try creating a new stack; the operation should succeed. For a Read-only user, the same attempt should be denied with a permission error.
4. Review the audit log: Settings → Logs → Authentication. Look for entries showing a successful LDAP bind and a login event for the test user.

Recovery Options

If LDAP authentication causes login issues, you can revert to local Portainer authentication:

1. Log in to Portainer using a local admin account (if you still have one) or use the recovery admin account created during initial setup.
2. Go to Settings → Authentication → LDAP and disable the LDAP toggle or clear the Server URL field.
3. Save the changes. Portainer will fall back to its internal user database.
4. Optionally, re-enable LDAP after correcting the configuration (e.g., fixing the bind DN or ensuring TLS certificates are trusted).

Note: Disabling LDAP does not delete any existing local users; it only changes the source of authentication.
