Configure encryption with customer-managed keys stored in Azure Key Vault Managed HSM

Azure Storage encrypts all data in a storage account at rest. By default, Azure Storage encrypts data by using Microsoft-managed keys. For more control over encryption keys, manage your own keys. You must store customer-managed keys in Azure Key Vault or Azure Key Vault Managed HSM (Hardware Security Module). An Azure Key Vault Managed HSM is a FIPS 140-2 Level 3 validated HSM.

This article shows how to configure encryption with customer-managed keys stored in a managed HSM by using Azure CLI. To learn how to configure encryption with customer-managed keys stored in a key vault, see Configure encryption with customer-managed keys stored in Azure Key Vault.

Note

Azure Key Vault and Azure Key Vault Managed HSM support the same APIs and management interfaces for configuration.

Assign an identity to the storage account

First, assign a system-assigned managed identity to the storage account. You'll use this managed identity to grant the storage account permissions to access the managed HSM. For more information about system-assigned managed identities, see What are managed identities for Azure resources?

To assign a managed identity using Azure CLI, call az storage account update. Remember to replace the placeholder values in brackets with your own values:

az storage account update \
    --name <storage-account> \
    --resource-group <resource_group> \
    --assign-identity

Assign a role to the storage account for access to the managed HSM

Assign the Managed HSM Crypto Service Encryption User role to the storage account's managed identity so that the storage account has permissions to the managed HSM. Scope the role assignment to the level of the individual key to grant the fewest possible privileges to the managed identity.

To create the role assignment for storage account, call az key vault role assignment create. Remember to replace the placeholder values in brackets with your own values.

storage_account_principal = $(az storage account show \
    --name <storage-account> \
    --resource-group <resource-group> \
    --query identity.principalId \
    --output tsv)

az keyvault role assignment create \
    --hsm-name <hsm-name> \
    --role "Managed HSM Crypto Service Encryption User" \
    --assignee $storage_account_principal \
    --scope /keys/<key-name>

Configure encryption with a key in the managed HSM

Configure Azure Storage encryption with customer-managed keys to use a key stored in the managed HSM. Supported key types include RSA-HSM keys of sizes 2048, 3072, and 4096. To learn how to create a key in a managed HSM, see Create an HSM key.

Install Azure CLI 2.12.0 or later to configure encryption to use a customer-managed key in a managed HSM. For more information, see Install the Azure CLI.

To automatically update the key version for a customer-managed key, omit the key version when you configure encryption with customer-managed keys for the storage account. For more information about configuring encryption for automatic key rotation, see Update the key version.

Next, call az storage account update to update the storage account's encryption settings, as shown in the following example. Include the --encryption-key-source parameter and set it to Microsoft.Keyvault to enable customer-managed keys for the account. Remember to replace the placeholder values in brackets with your own values.

hsmurl = $(az keyvault show \
    --hsm-name <hsm-name> \
    --query properties.hsmUri \
    --output tsv)

az storage account update \
    --name <storage-account> \
    --resource-group <resource_group> \
    --encryption-key-name <key> \
    --encryption-key-source Microsoft.Keyvault \
    --encryption-key-vault $hsmurl

To manually update the version for a customer-managed key, include the key version when you configure encryption for the storage account:

az storage account update
    --name <storage-account> \
    --resource-group <resource_group> \
    --encryption-key-name <key> \
    --encryption-key-version $key_version \
    --encryption-key-source Microsoft.Keyvault \
    --encryption-key-vault $hsmurl

When you manually update the key version, you'll need to update the storage account's encryption settings to use the new version. First, query for the key vault URI by calling az keyvault show, and for the key version by calling az keyvault key list-versions. Then call az storage account update to update the storage account's encryption settings to use the new version of the key, as shown in the previous example.
