Configure data boundary

This documentation provides details on how customers can configure Azure Resource Manager for use in a data boundary. The only data boundary configuration currently supported, aside from the default Global configuration, is for the European Union (EU). The EU Data Boundary is a geographically defined boundary within which Microsoft has committed to store and process Customer Data and pseudonymized personal data, and store Professional Services Data for Microsoft enterprise online services, including Azure, Dynamics 365, Power Platform, and Microsoft 365, subject to limited circumstances where personal data continue to be transferred outside the EU Data Boundary. For more information, see Overview of the EU Data Boundary.

Important

To store Professional Services Data in the EU Data Boundary for Azure, customers must configure Azure Resource Manager to the EU Data Boundary. This documentation provides details on how customers can configure Azure Resource Manager for use in the EU Data Boundary.

A data boundary can only be established in new tenants that have no existing subscriptions or deployed resources. Once a tenant is opted into a data boundary, the data boundary configuration cannot be removed or modified. Subscriptions and resources created under a tenant with a data boundary cannot be moved out of that tenant. Existing subscriptions and resources cannot be moved into a tenant with a data boundary. Each tenant is limited to one data boundary, and after the data boundary is configured, Azure Resource Manager will restrict resource deployments to regions within that boundary. A Global data boundary has no restrictions on the regions a resource can deploy to. Customers can opt their tenants into a data boundary by deploying a Microsoft.Resources/dataBoundaries resource at the tenant level.

The DataBoundaryTenantAdministrator built-in role is required to configure data boundary. For more information, see Permissions required.

To opt your tenant into an Azure EU Data Boundary:

Create a new tenant within an EU country or region to configure a Microsoft Entra EU Data Boundary. For more information on how to create a new tenant within an EU country or region, see Create a new tenant in Microsoft Entra ID.
Before creating any new subscriptions or resources, deploy a Microsoft.Resources/dataBoundaries resource with an EU configuration.
Create a subscription and deploy Azure resources.

Permissions required

To configure data boundary, the DataBoundaryTenantAdministrator built-in role is required at the tenant scope. Use the following steps to assign the role:

Elevate access to manage all Azure subscriptions and management groups. For more information, see Elevate access to manage all Azure subscriptions and management groups.

With the User Access Administrator privilege, grant yourself the DataBoundaryTenantAdministrator role at the tenant scope (/) by using Azure CLI or Azure PowerShell or REST API.

Not supported by the Azure portal. Use Azure CLI or Azure PowerShell or REST API instead.

DATA_BOUNDARY_TENANT_ADMINISTRATOR_ROLE_ID="d1a38570-4b05-4d70-b8e4-1100bcf76d12"

az role assignment create --assignee "{assignee}" --role DATA_BOUNDARY_TENANT_ADMINISTRATOR_ROLE_ID --scope "/"

$dataBoundaryTenantAdministratorRoleDefinitionId = "d1a38570-4b05-4d70-b8e4-1100bcf76d12"

New-AzRoleAssignment -ObjectId <objectId> -RoleDefinitionId $dataBoundaryTenantAdministratorRoleDefinitionId -Scope "/"

PUT https://management.azure.com/providers/Microsoft.Authorization/roleAssignments/{roleAssignmentName}?api-version=2020-04-01-preview

Request body:

{
  "properties": {
    "roleDefinitionId": "/providers/Microsoft.Authorization/roleDefinitions/d1a38570-4b05-4d70-b8e4-1100bcf76d12",
    "principalId": "{assignee}"
  }
}

Response body:

{
  "id": "/providers/Microsoft.Authorization/roleAssignments/{roleAssignmentName}",
  "type": "Microsoft.Authorization/roleAssignments",
  "name": "{roleAssignmentName}",
  "properties": {
    "roleDefinitionId": "/providers/Microsoft.Authorization/roleDefinitions/d1a38570-4b05-4d70-b8e4-1100bcf76d12",
    "principalId": "{assignee}",
    "principalType": "User", // Could also be "Group", "ServicePrincipal", etc.
  }
}

For more information, see Assign Azure roles.

Create data boundary

Data boundary geo currently has two options:

Data boundary geo	Description
Global	By default, all tenants have a global data boundary.
EU	Establish an EU data boundary.

To opt in a tenant to data boundary, use the following commands.

Use these steps to create a data boundary:

Open the Azure portal.
In the search box, type azure data boundaries, and then select Azure Data Boundaries.
In Boundary region, select data boundary geo, either Global or EU, and then select Save.

Open diagram: Screenshot of configuring data boundary.

The Boundary region can only be configured for empty tenants.

az data-boundary create --data-boundary <data-boundary-geo> --default default

The --default switch is currently mandatory but will be phased out in the future.

For more information, see Azure CLI Reference.

Set-AzDataBoundary -DataBoundary <data-boundary-geo>

For more information, see Azure PowerShell Reference.

PUT https://management.azure.com/providers/Microsoft.Resources/dataBoundaries/default?api-version=2024-08-01

Request body:

{
  "properties": {
    "dataBoundary": "<data-boundary-geo>"
  }
}


```json
{
  "name": "{tenantId}",
  "id": " /providers/Microsoft.Resources/dataBoundaries/{tenantId}",
  "properties": {
    "dataBoundary": "{dataBoundaryGeo}",
    "provisioningState": "Created"
  }
}

For more information, see Azure REST API Reference.

Read data boundary

To get data boundary at specified scopes. The scopes include:

Scope	Value
Tenant	(empty)
Subscription	subscriptions/{subscriptionId}
Resource group	subscriptions/{subscriptionId}/resourceGroups/{resourceGroupName}

Open the Azure portal.
In the search box, type azure data boundaries, and then select Azure Data Boundaries. The following screenshot shows a Global data boundary.

Open diagram: Screenshot of showing data boundary.

az data-boundary show --scope <scope-path> --default default

Get data boundary of tenant:

az data-boundary show-tenant --default default
