Composing Realistic Load Profiles with k6 Scenarios and Executors

The problem: one script, many traffic patterns

Most load tests start simple: hammer an endpoint with a constant stream of requests. Real systems, however, face a mix of steady API traffic, sudden checkout spikes, and long-running background jobs — often over different protocols. Running separate scripts for each flow fragments your CI pipeline and makes it hard to see how the combined load affects shared resources.

k6 scenarios solve this by letting you define multiple independent load profiles in a single script. Each scenario gets its own executor (the VU scheduling strategy), start offset, and protocol, while sharing the same test lifecycle. The result is a realistic, composable load model that runs locally and in distributed cloud executions without rewrites.

Scenarios: independent load profiles in one script

A scenario is a named block in the exported options.scenarios object. It declares:

• executor — the scheduling algorithm (see below)
• startTime — delay before this scenario begins (e.g., "30s")
• tags — key/value pairs automatically attached to every metric sample from this scenario
• executor-specific knobs like vus, iterations, or rate

Because tags flow into metrics, you can filter Grafana dashboards or write thresholds per scenario (e.g., http_req_duration{scenario:checkout} < 500). The gracefulStop and gracefulRampDown settings also apply per scenario, letting you drain in-flight requests cleanly at phase boundaries.

Choosing the right executor for each flow

k6 ships with five executors, each implementing a different VU scheduling model:

Executor	Model	Best for
shared-iterations	Closed	Fixed total iterations split across VUs; good for "run N requests total"
per-vu-iterations	Closed	Each VU runs a fixed iteration count; predictable per-VU work
constant-vus	Closed	Hold a steady VU count; classic constant concurrency
ramping-vus	Closed	Ramp VUs up/down through stages; simulates traffic waves
arrival-rate	Open	Target a request rate regardless of latency; mimics real-world arrival streams

Pick closed-model executors when you control concurrency (e.g., a fixed pool of virtual users). Use arrival-rate when you want to stress a system at a specific throughput, but set maxVUs conservatively — if the system stalls, k6 will spawn VUs up to that limit to catch up, potentially amplifying the load.

Worked example: mixed HTTP, WebSocket, and gRPC traffic

The script below defines three scenarios that run concurrently:

• browse — steady HTTP API traffic at 100 VUs
• checkout — a 30-second spike at 200 iterations/sec using arrival-rate
• background — a long-running gRPC job with 10 VUs each doing 50 iterations

import http from 'k6/http';
import ws from 'k6/ws';
import grpc from 'k6/net/grpc';
import { check, sleep } from 'k6';

export const options = {
  scenarios: {
    browse: {
      executor: 'constant-vus',
      vus: 100,
      duration: '2m',
      tags: { scenario: 'browse' },
      exec: 'browseFlow',
    },
    checkout: {
      executor: 'arrival-rate',
      rate: 200,
      timeUnit: '1s',
      duration: '30s',
      startTime: '30s',
      preAllocatedVUs: 50,
      maxVUs: 300,
      tags: { scenario: 'checkout' },
      exec: 'checkoutFlow',
    },
    background: {
      executor: 'per-vu-iterations',
      vus: 10,
      iterations: 50,
      startTime: '10s',
      tags: { scenario: 'background' },
      exec: 'backgroundFlow',
    },
  },
  thresholds: {
    'http_req_duration{scenario:checkout}': ['p(95)<500'],
    'grpc_req_duration{scenario:background}': ['p(99)<1000'],
  },
};

export function browseFlow() {
  const res = http.get('https://api.example.com/products');
  check(res, { 'status 200': (r) => r.status === 200 });
  sleep(1);
}

export function checkoutFlow() {
  const payload = JSON.stringify({ items: ['sku-123'], user: 'test' });
  const res = http.post('https://api.example.com/checkout', payload, {
    headers: { 'Content-Type': 'application/json' },
  });
  check(res, { 'order placed': (r) => r.status === 201 });
}

export function backgroundFlow() {
  const client = new grpc.Client();
  client.load([], 'proto/batch.proto');
  client.connect('grpc.example.com:443', { plaintext: false });
  const response = client.invoke('batch.Process', { jobId: `job-${__VU}-${__ITER}` });
  check(response, { 'grpc ok': (r) => r.status === grpc.StatusOK });
  client.close();
  sleep(0.5);
}

Run it locally with:

k6 run --summary-export=summary.json script.js

Then inspect the JSON for per-scenario metrics (look for the scenario tag in each sample). You can also preview the resolved execution plan before running:

k6 inspect --execution-script script.js

Both commands require only read access to the script and a working k6 binary (v0.50+). No elevated permissions are needed.

Trade-offs and limitations

• Arrival-rate overshoot: If the system under test stalls, k6 spawns VUs up to maxVUs to meet the target rate. Set maxVUs to a safe ceiling.
• Shared-iterations distribution: When total iterations < VUs, some VUs exit immediately — not an error, but it reduces concurrency.
• Custom metrics need manual tags: Scenario tags are not auto-applied to custom metrics; add tags: { scenario: 'checkout' } in your trend.add() calls.
• Graceful stop cutoff: The default 30s gracefulStop may abort long requests (e.g., file uploads), inflating error rates. Increase it per scenario if needed.
• Local resource exhaustion: Many high-VU scenarios can hit file-descriptor or port limits. Use --no-usage-report and raise ulimits for heavy local runs.

Actionable next steps

1. Add a scenarios block to your existing script and move each logical flow into its own exec function.
2. Tag each scenario and write at least one scenario-scoped threshold.
3. Run k6 inspect --execution-script to verify the resolved config.
4. Execute locally with --summary-export and confirm per-scenario metrics appear in the JSON.
5. Promote the same script to CI or Grafana Cloud k6 — scenario names and tags will match exactly.

By modeling each traffic pattern as a first-class scenario, you get realistic load, per-flow pass/fail criteria, and a single source of truth for local and cloud runs.
