Choosing Sema for CI Dependency Graphs: A Decision Guide vs. Go Mod Graph, Golangci‑Lint, and Custom Scripts

Decision Context

When a CI pipeline needs a reliable, machine‑readable representation of a Go project’s dependency graph, the first question is: which tool delivers that data most efficiently while keeping maintenance low? Sema, a lightweight Go‑native CLI, has emerged as a candidate. This guide walks through the decision, compares the main alternatives, and shows a concrete CI implementation and verification steps.

Options Overview

Tool	Primary Use	Output Format	Runtime Overhead	Maintenance	Go Version	Community Support
Sema	Dependency graph extraction	JSON (structured)	Low – single binary, no linting	Low – maintained as part of the Go ecosystem	1.22+	Moderate – issues resolved quickly, but no enterprise backing
go mod graph	Print module dependency tree	Text (human‑readable)	Low – built into Go toolchain	Very low – no external deps	1.16+	High – part of standard library
golangci-lint	Linting & static analysis	JSON, text, or custom reporters	High – runs multiple linters	High – many linters to keep up with	1.17+	High – large community
Custom script (e.g., using go list)	Any custom extraction logic	Flexible (JSON, YAML, etc.)	Variable – depends on implementation	High – maintenance of script	1.16+	Variable – depends on maintainer

Trade‑offs & Constraints

• Structured Output – Sema’s JSON is ready for downstream processing (e.g., generating visual graphs, policy checks). go mod graph emits plain text, requiring custom parsing.
• Transitive Dependencies – Sema automatically resolves transitive modules, whereas go mod graph must be combined with other commands to build a full graph.
• Runtime Footprint – Sema’s single binary incurs negligible overhead. golangci‑lint runs dozens of linters, which can double or triple job time.
• Maintenance Burden – Custom scripts grow in complexity as the repository evolves. Sema and go mod graph are maintained by the Go team; golangci‑lint has a large contributor base.
• Go Version Compatibility – Sema requires Go 1.22+, which may be a blocker in environments locked to older toolchains. go mod graph works from Go 1.16.
• Community & Support – While Sema’s issue triage is quick, it lacks the enterprise support that golangci‑lint enjoys. For mission‑critical pipelines, this may be a consideration.

Concrete Implementation in a CI Pipeline

The following example demonstrates a GitHub Actions workflow that installs Sema, extracts the dependency graph, and verifies it against a snapshot. Replace placeholders (e.g., YOUR‑REPO‑URL) with your actual values.

name: Dependency Graph Check

on:
  push:
    branches: [ main ]
  pull_request:
    branches: [ main ]

jobs:
  extract-deps:
    runs-on: ubuntu-latest
    steps:
      - name: Checkout code
        uses: actions/checkout@v4

      - name: Set up Go 1.22
        uses: actions/setup-go@v5
        with:
          go-version: '1.22'

      - name: Install Sema
        run: |
          go install github.com/yourorg/sema@latest
        shell: bash

      - name: Run Sema and capture graph
        run: |
          sema graph --output json > deps.json
        shell: bash

      - name: Compare with snapshot
        uses: actions/cache@v4
        with:
          path: deps.json
          key: ${{ runner.os }}-deps-${{ hashFiles('deps.json') }}

      - name: Verify graph integrity
        run: |
          # Simple checksum comparison; replace with your own validation logic
          echo "Graph checksum: $(sha256sum deps.json | cut -d' ' -f1)"
        shell: bash

      - name: Upload graph artifact
        uses: actions/upload-artifact@v4
        with:
          name: dependency-graph
          path: deps.json

Key points:

• The go install step pulls the latest Sema release. If a specific tag is required, replace @latest with @v0.1.3.
• Running sema graph --output json writes a machine‑readable graph to deps.json.
• The checksum step is a lightweight verification; more robust validation could involve schema validation or a diff against a known‑good snapshot stored in the repo.
• Artifacts allow downstream jobs (e.g., visualizer services) to consume the graph.

Verification Procedures

1. Version Check – In a CI step, run sema --version and compare the output against the expected release tag. This guards against accidental upgrades that might change the output format.

   sema --version
   # Expected: sema v0.1.3


2. Snapshot Diff – Store a baseline deps.json in the repository. Use diff or a JSON diff tool to detect unexpected changes.

   diff baseline/deps.json deps.json


3. Schema Validation – If Sema provides a JSON schema (check the docs), run a schema validator to ensure the output conforms.

   jq -e '...schema validation...' deps.json


4. Checksum Hash – Compute a SHA‑256 hash of the graph and compare it against a stored hash. Any change indicates a dependency change or tool version bump.

   sha256sum deps.json


Limitations & Practical Checks

• Go 1.22 Requirement – If your CI environment cannot upgrade to Go 1.22, consider using go mod graph or a custom script. You can still use Sema locally for development.

  go mod graph | awk '{print $1,$2}' > deps.txt


• Community Support – While issues are usually resolved within days, there is no dedicated enterprise support line. For critical use cases, maintain a local copy of the tool or set up a monitoring alert for new releases.
• Large Monorepos – In very large repositories, the JSON output can become sizeable. Use streaming or compression (gzip) if storage is a concern.
• Custom Validation – If your organization has policy checks (e.g., no direct dependency on github.com/foo/bar), write a small Go or Python script that parses the JSON and enforces the rule.

Conclusion

For teams that need a clean, structured dependency graph in CI without the overhead of a full linting suite, Sema offers a compelling balance of performance, maintainability, and ease of integration. Its JSON output and Go API make it a natural fit for downstream tooling, while the requirement for Go 1.22 is a manageable constraint in most modern pipelines. By following the implementation and verification steps above, you can confidently incorporate Sema into your CI workflow and keep your dependency insights accurate and reproducible.
