Choosing Client‑Side vs Server‑Side Pagination for Angular Material MatTable

Decision: Where to Slice the Data?

When you add a MatTable to an Angular app you immediately face a design question: do you let the browser hold the entire dataset and slice it with MatPaginator, or do you let the server deliver only the rows you need for each page? The choice affects performance, memory, and user experience.

What the Decision Affects

• Initial Load – all rows are fetched or only the first page is requested.
• Subsequent Page Changes – instant in‑memory filtering or a new HTTP call.
• Memory Footprint – full array vs. a single page.
• Complexity – built‑in MatTableDataSource or a custom DataSource.
• Scalability – small static tables vs. large, frequently updated datasets.

Comparison Table

Feature	Client‑Side (MatTableDataSource)	Server‑Side (Custom DataSource)
Initial Load	All data returned in one request (may be slow for >1 000 rows)	Only first page requested (fast start)
Page Transitions	Instant – data already in memory	Network dependent – one request per page
Memory Usage	High – stores whole array	Low – stores only current page
Implementation Effort	Very low – bind MatPaginator to MatTableDataSource	Medium – create a custom DataSource and wire events
Sorting + Pagination	Built‑in – use MatSort with MatTableDataSource	Requires server support for sort parameters

When to Pick Which

• Client‑Side is suitable when:
  • The total number of rows is < 1 000 (or the payload size is < 200 KB).
  • The table is static or rarely changes.
  • Latency on the first load is acceptable.
• Server‑Side is the default for:
  • Datasets larger than a few thousand rows.
  • Highly dynamic data that can change between page loads.
  • Environments where memory or CPU usage is a concern.

Client‑Side Implementation

Use MatTableDataSource and let MatPaginator do the slicing. The code below shows the minimal wiring.

// app.module.ts
import { NgModule } from '@angular/core';
import { BrowserModule } from '@angular/platform-browser';
import { BrowserAnimationsModule } from '@angular/platform-browser/animations';
import { MatTableModule } from '@angular/material/table';
import { MatPaginatorModule } from '@angular/material/paginator';
import { MatSortModule } from '@angular/material/sort';
import { AppComponent } from './app.component';

@NgModule({
  declarations: [AppComponent],
  imports: [
    BrowserModule,
    BrowserAnimationsModule,
    MatTableModule,
    MatPaginatorModule,
    MatSortModule
  ],
  bootstrap: [AppComponent]
})
export class AppModule {}

// app.component.ts
import { Component, ViewChild, AfterViewInit } from '@angular/core';
import { MatTableDataSource } from '@angular/material/table';
import { MatPaginator } from '@angular/material/paginator';
import { MatSort } from '@angular/material/sort';

interface User {
  id: number;
  name: string;
  email: string;
}

@Component({
  selector: 'app-root',
  templateUrl: './app.component.html',
  styleUrls: ['./app.component.css']
})
export class AppComponent implements AfterViewInit {
  displayedColumns: string[] = ['id', 'name', 'email'];
  dataSource = new MatTableDataSource<User>();

  @ViewChild(MatPaginator) paginator!: MatPaginator;
  @ViewChild(MatSort) sort!: MatSort;

  ngAfterViewInit() {
    this.dataSource.paginator = this.paginator;
    this.dataSource.sort = this.sort;
  }

  // Example data – in a real app this would come from a service
  fetchData() {
    const users: User[] = [];
    for (let i = 1; i <= 200; i++) {
      users.push({ id: i, name: `User ${i}`, email: `user${i}@example.com` });
    }
    this.dataSource.data = users;
  }
}

<table mat-table [dataSource]="dataSource" class="mat-elevation-z8">
  <ng-container matColumnDef="id">
    <th mat-header-cell *matHeaderCellDef mat-sort-header> ID </th>
    <td mat-cell *matCellDef="let element"> {{element.id}} </td>
  </ng-container>

  <ng-container matColumnDef="name">
    <th mat-header-cell *matHeaderCellDef mat-sort-header> Name </th>
    <td mat-cell *matCellDef="let element"> {{element.name}} </td>
  </ng-container>

  <ng-container matColumnDef="email">
    <th mat-header-cell *matHeaderCellDef mat-sort-header> Email </th>
    <td mat-cell *matCellDef="let element"> {{element.email}} </td>
  </ng-container>

  <tr mat-header-row *matHeaderRowDef="displayedColumns">
  <tr mat-row *matRowDef="let row; columns: displayedColumns;" [trackBy]="trackById">
</table>

<mat-paginator [pageSizeOptions]="[5, 10, 25, 100]" showFirstLastButtons></mat-paginator>

Key points:

• Call this.dataSource.paginator = this.paginator after the view is initialized.
• Use trackBy on mat-row to avoid full DOM rebuilds when the page changes.
• All sorting and paging logic lives inside MatTableDataSource.

Server‑Side Implementation

When the dataset is large or highly dynamic you should fetch only the visible slice. The pattern below uses a custom DataSource that communicates with an API.

// user.service.ts – a minimal HTTP wrapper
import { Injectable } from '@angular/core';
import { HttpClient, HttpParams } from '@angular/common/http';
import { Observable } from 'rxjs';

export interface PaginatedResponse<T> {
  items: T[];
  total: number;
}

@Injectable({ providedIn: 'root' })
export class UserService {
  constructor(private http: HttpClient) {}

  getUsers(pageIndex: number, pageSize: number, sortActive?: string, sortDirection?: string): Observable<PaginatedResponse<User>> {
    let params = new HttpParams()
      .set('page', pageIndex.toString())
      .set('size', pageSize.toString());
    if (sortActive && sortDirection) {
      params = params.set('sort', sortActive).set('dir', sortDirection);
    }
    return this.http.get<PaginatedResponse<User>>('/api/users', { params });
  }
}

// server-side-data-source.ts
import { DataSource } from '@angular/cdk/collections';
import { Observable, BehaviorSubject, combineLatest } from 'rxjs';
import { switchMap, tap } from 'rxjs/operators';
import { UserService, PaginatedResponse } from './user.service';
import { User } from './user.model';

export class ServerSideDataSource extends DataSource<User> {
  private dataSubject = new BehaviorSubject<User[]>([]);
  private totalSubject = new BehaviorSubject<number>(0);

  constructor(private userService: UserService) {
    super();
  }

  /**
   * Called by the table when it wants the data.
   * Emits the current page of users.
   */
  connect(): Observable<User[]> {
    return this.dataSubject.asObservable();
  }

  disconnect(): void {
    this.dataSubject.complete();
    this.totalSubject.complete();
  }

  /**
   * Request a new page from the server.
   * @param pageIndex Zero‑based index of the page.
   * @param pageSize Number of rows per page.
   * @param sortActive Column used for sorting.
   * @param sortDirection 'asc' | 'desc'.
   */
  loadPage(pageIndex: number, pageSize: number, sortActive?: string, sortDirection?: string): void {
    this.userService.getUsers(pageIndex, pageSize, sortActive, sortDirection)
      .pipe(
        tap((res: PaginatedResponse<User>) => {
          this.dataSubject.next(res.items);
          this.totalSubject.next(res.total);
        })
      )
      .subscribe();
  }

  /**
   * Expose the total count for the paginator.
   */
  get total$(): Observable<number> {
    return this.totalSubject.asObservable();
  }
}

// app.component.ts (server‑side version)
import { Component, ViewChild, AfterViewInit } from '@angular/core';
import { MatPaginator, PageEvent } from '@angular/material/paginator';
import { MatSort, Sort } from '@angular/material/sort';
import { ServerSideDataSource } from './server-side-data-source';

@Component({
  selector: 'app-root',
  templateUrl: './app.component.html',
  styleUrls: ['./app.component.css']
})
export class AppComponent implements AfterViewInit {
  displayedColumns: string[] = ['id', 'name', 'email'];
  dataSource = new ServerSideDataSource();
  totalItems = 0;

  @ViewChild(MatPaginator) paginator!: MatPaginator;
  @ViewChild(MatSort) sort!: MatSort;

  ngAfterViewInit() {
    // Load the first page
    this.loadPage();

    // Update total when the data source emits a new total
    this.dataSource.total$.subscribe(total => this.totalItems = total);
  }

  loadPage(event?: PageEvent) {
    const pageIndex = event?.pageIndex ?? 0;
    const pageSize = event?.pageSize ?? 10;
    const sortActive = this.sort?.active;
    const sortDirection = this.sort?.direction;
    this.dataSource.loadPage(pageIndex, pageSize, sortActive, sortDirection);
  }

  onPageChange(event: PageEvent) {
    this.loadPage(event);
  }

  onSortChange(sort: Sort) {
    // Reset to first page when sorting changes
    this.paginator.firstPage();
    this.loadPage({ pageIndex: 0, pageSize: this.paginator.pageSize });
  }
}

<table mat-table [dataSource]="dataSource" class="mat-elevation-z8">
  <ng-container matColumnDef="id">
    <th mat-header-cell *matHeaderCellDef mat-sort-header> ID </th>
    <td mat-cell *matCellDef="let element"> {{element.id}} </td>
  </ng-container>

  <ng-container matColumnDef="name">
    <th mat-header-cell *matHeaderCellDef mat-sort-header> Name </th>
    <td mat-cell *matCellDef="let element"> {{element.name}} </td>
  </ng-container>

  <ng-container matColumnDef="email">
    <th mat-header-cell *matHeaderCellDef mat-sort-header> Email </th>
    <td mat-cell *matCellDef="let element"> {{element.email}} </td>
  </ng-container>

  <tr mat-header-row *matHeaderRowDef="displayedColumns">
  <tr mat-row *matRowDef="let row; columns: displayedColumns;" [trackBy]="trackById">
</table>

<mat-paginator
  [length]="totalItems"
  [pageSizeOptions]="[5, 10, 25, 100]"
  showFirstLastButtons
  (page)="onPageChange($event)"
  (sortChange)="onSortChange($event)"
></mat-paginator>

Key points for the server‑side flow:

• The DataSource exposes a total$ stream so the component can bind length on the paginator.
• Sorting is handled by the API – the component forwards the active column and direction to loadPage.
• When the paginator emits a PageEvent, the component calls loadPage with the new page index and size.
• Use trackBy to keep the DOM stable across page changes.

Validation & Diagnostics

1. Network Check – Open DevTools → Network. Trigger a page change. A request to /api/users?page=1&size=10 (or similar) should appear, and the response should contain only the requested slice plus a total field.
2. Console Logs – Add console.log('Page:', pageIndex, 'Size:', pageSize) inside loadPage to confirm the correct parameters are sent.
3. DOM Count – Inspect the table rows after a page change. The number of <tr mat-row> elements should equal the pageSize (or the remaining rows on the last page).
4. Change Detection – If you use ChangeDetectionStrategy.OnPush on the component, call ChangeDetectorRef.detectChanges() after subscribing to total$ or after loadPage completes to force an update.

By following the patterns above you can confidently choose the right pagination strategy for your Angular Material table and verify that each page request behaves as expected.
