Choosing Between Virtual Users and Arrival Rate in k6 for Throughput Control

The Throughput Dilemma: Closed-Loop vs. Open-Loop

When designing a load test in k6, the most critical decision is how to control the volume of traffic. Many engineers default to increasing the number of Virtual Users (VUs), but this creates a closed-loop system. In a closed-loop model, a VU must finish its current iteration (request and response) before starting the next. If the system under test slows down, the VU waits longer, and the total requests per second (RPS) drops automatically.

This behavior masks performance degradation. If your goal is to verify that a system can handle 500 RPS regardless of how slow the responses become, VUs alone will fail you. You need an open-loop system, provided by k6 Arrival Rate executors, which decouple the request rate from the system's response time.

Comparison: VUs vs. Constant Arrival Rate

Trade-offs and Engineering Constraints

The Risk of Coordinated Omission

Using VUs to hit a target RPS often leads to "coordinated omission." When the server stalls, the VUs stall. Because the VUs aren't sending new requests while waiting, the resulting metrics show a lower volume of requests during the slow period, which can artificially smooth out your latency percentiles. Arrival Rate executors avoid this by continuing to trigger new iterations even if previous ones are still pending.

The Cost of VU Allocation

Arrival Rate executors do not magically create requests; they dynamically scale VUs to meet the target rate. If you set a high arrival rate but a low preAllocatedVUs count, k6 will spend CPU cycles allocating new VUs on the fly, which can introduce jitter into your results. Always pre-allocate a baseline of VUs based on expected average response times.

Implementation: Maintaining a Stable RPS

To implement an open-loop test, use the constant-arrival-rate executor. This configuration ensures that k6 attempts to start a specific number of iterations per second, scaling the VU count up to a defined limit if the system slows down.

import http from 'k6/http';

export const options = {
  scenarios: {
    constant_request_rate: {
      executor: 'constant-arrival-rate',
      rate: 100,              // Target 100 iterations per second
      timeUnit: '1s',         // Rate is measured per second
      duration: '1m',         // Total test duration
      preAllocatedVUs: 50,    // Start with 50 VUs to avoid allocation overhead
      maxVUs: 200,            // Allow scaling up to 200 VUs to maintain 100 RPS
    },
  },
};

export default function () {
  http.get('https://test-api.example.com/health');
}

Execution and Validation

Run this script from your terminal with the following command (requires k6 installed locally; no special permissions needed beyond network access to the target):

k6 run script.js

Verification steps:

• Check http_reqs: In the final summary, the total requests should closely match rate * duration (e.g., 100 RPS * 60s = 6,000 requests).
• Monitor vus: Observe the VU count during the test. If the system response time increases, you will see the VU count rise toward the maxVUs limit as k6 attempts to maintain the 100 RPS target.
• Identify bottlenecks: If the VU count hits maxVUs and the http_reqs rate begins to drop, you have reached the physical limit of your load generator or the system's ability to handle the concurrency required for that throughput.

Limitations and Practical Checks

Executor behavior described here reflects k6's long-standing design (v0.27+ era through current releases), but verify against the documentation for your installed version with k6 version, since option names and defaults can change. Also note that the load generator machine itself can become the bottleneck: if CPU or memory saturates, k6 may fail to maintain the arrival rate even when the target system is healthy. Watch the dropped_iterations metric to detect this condition.

Since k6 is a stateless load generator, there is no persistent state to roll back on the client side. To stop a test that is consuming too many resources or overwhelming a target server, use Ctrl+C to terminate the process immediately.
