Choosing Between Vaadin Flow and Vaadin Fusion: A Practical Decision Guide

Decision

When starting a new Vaadin 23+ application you must decide whether to render the UI on the server with Vaadin Flow or on the client with Vaadin Fusion. The choice is driven by team skill sets, SEO needs, and the level of client‑side interactivity required.

Constraints

• Vaadin version must be ≥23 LTS (both Flow and Fusion are fully supported).
• A Java backend (Spring Boot or plain servlet) must be available.
• Fusion requires a modern browser that supports ES2020.
• Team must have either Java (Flow) or TypeScript/JavaScript (Fusion) expertise.
• Build tooling: Flow uses Maven/Gradle; Fusion needs Node.js and npm/Yarn.

Option Comparison

Feature	Vaadin Flow (SSR)	Vaadin Fusion (CSR)
Rendering model	Server‑side Java components, initial HTML + minimal JS	Client‑side TypeScript components, full JS bundle
Initial page load	Fast HTML rendering, good for SEO and first‑paint	Longer bundle download, slower first paint
Interactivity	Java‑backed event handling, limited to server round‑trips	Rich client‑side logic, offline capabilities
Server load	Higher CPU/memory per session (UI state kept on server)	Lower server load (stateless UI)
Security integration	Direct Java access to security context	Requires API endpoints for data, security handled via REST/OData
Build tooling	Maven/Gradle, no Node required	Node + npm/Yarn, requires frontend build step
Debugging	Java stack traces, easier server‑side debugging	Browser dev tools, TypeScript debugging, requires source maps
SEO friendliness	Excellent – server renders full HTML	Good if using server-side rendering or pre-render hooks, otherwise less

Trade‑offs

• Flow is ideal when you need fast initial loads, tight security integration, or when your team is comfortable with Java only. It keeps the UI state on the server, which simplifies security but can become a bottleneck under high concurrency.
• Fusion shines for applications that require heavy client‑side logic, offline support, or a clear separation between UI and business logic. The larger JS bundle and build step add complexity, and you must expose data via REST/OData endpoints.
• Mixing Flow and Fusion in the same UI tree is discouraged; if you need both, route them separately.
• Fusion’s build time increases CI duration; consider caching node modules and using incremental builds.

Concrete Implementation Example

Below is a minimal starter that demonstrates both approaches in the same project. The project uses Spring Boot 3.2, Maven, and Node 20.

1. Project Setup

mvn archetype:generate \
  -DarchetypeGroupId=com.vaadin \
  -DarchetypeArtifactId=vaadin-archetype-application \
  -DarchetypeVersion=23.3.0 \
  -DgroupId=com.example \
  -DartifactId=vaadin-demo \
  -Dpackage=com.example.demo \
  -Dversion=0.0.1-SNAPSHOT \
  -DinteractiveMode=false
cd vaadin-demo

2. Add Fusion Support

Open pom.xml and add the Fusion starter dependency:

<dependency>
  <groupId>com.vaadin</groupId>
  <artifactId>vaadin-fusion-starter</artifactId>
  <version>23.3.0</version>
</dependency>

Install Node and npm (or Yarn) globally if not already installed.

3. Create a Flow View

File: src/main/java/com/example/demo/views/flow/HelloFlow.java

package com.example.demo.views.flow;

import com.vaadin.flow.component.html.H1;
import com.vaadin.flow.router.Route;
import com.vaadin.flow.component.orderedlayout.VerticalLayout;

@Route("flow")
public class HelloFlow extends VerticalLayout {
    public HelloFlow() {
        add(new H1("Hello from Vaadin Flow"));
    }
}

4. Create a Fusion View

File: src/main/java/com/example/demo/views/fusion/HelloFusion.java

package com.example.demo.views.fusion;

import com.vaadin.flow.component.orderedlayout.VerticalLayout;
import com.vaadin.flow.router.Route;
import com.vaadin.flow.server.auth.AnonymousAllowed;

@Route("fusion")
@AnonymousAllowed
public class HelloFusion extends VerticalLayout {
    public HelloFusion() {
        add(new com.vaadin.flow.component.html.H1("Hello from Vaadin Fusion"));
    }
}

Fusion automatically generates a fusion/HelloFusion.tsx component that renders the same UI on the client.

5. Build and Run

# Build Java and compile TypeScript
mvn clean install

# Run the Spring Boot app
mvn spring-boot:run

Navigate to /flow and /fusion to see both views.

6. Verify the Difference

• Open the browser DevTools and inspect the Network tab.
  • The Flow route should load index.html, a small vaadin.js bundle, and minimal JavaScript.
  • The Fusion route should load a larger fusion.js bundle (typically 200‑400 KB gzipped) plus the generated HelloFusion.tsx JavaScript.
• Use a simple load test (e.g., jmeter or wrk) to compare CPU usage. Under 100 concurrent users, Flow will show higher CPU per thread due to server‑side state management, whereas Fusion will have lower CPU but higher network traffic.

Validation Checklist

1. Confirm both routes load without errors in a supported browser.
2. Verify that Flow’s page source contains the full H1 markup before JavaScript executes.
3. Check that Fusion’s source includes a class HelloFusion extends Component definition in the compiled bundle.
4. Run a simple CPU profiling on the Spring Boot process to observe the expected load difference.

Summary

Choose Vaadin Flow when you need fast initial rendering, strong server‑side security, and a Java‑only stack. Opt for Vaadin Fusion if your application demands rich client‑side logic, offline capabilities, or a TypeScript‑centric development experience. Both approaches can coexist in a single project, but keep them on separate routes to avoid complexity.
