Choosing Between Quarkus Native Executable and JVM Mode

Decision and Constraints

When developing a Quarkus application you must decide whether to produce a native executable with GraalVM or to run the application on the HotSpot JVM. The choice hinges on constraints such as startup latency, memory budget, build time, library compatibility, and development workflow.

• Startup latency – critical for serverless functions or short‑lived containers.
• Memory footprint** – important when running many instances on limited hardware.
• Build time** – affects CI/CD pipelines and local iteration speed.
• Library support** – some frameworks rely on reflection or dynamic class loading that may need extra configuration for native images.
• Development mode** – hot reload and fast debugging are only available in JVM mode.

If your target environment demands sub‑100 ms start and low RSS (e.g., AWS Lambda, Knative, or dense microservice clusters), native compilation is attractive. If you prioritize rapid iteration, full library compatibility, or easier debugging, the JVM mode is preferable.

Comparison of Options

Aspect	Native Executable (GraalVM)	JVM (HotSpot)
Startup time	<100 ms (typical)	1‑2 s
Memory RSS	~30 MB	~150 MB
Build time	2‑5 min (depends on project size)	<30 s
Library support	Limited; requires reflection configuration for dynamic loading	Full; no extra configuration needed
Dev mode	Not available	Enabled via quarkus:dev
Typical use case	Serverless functions, CLI tools, low‑latency microservices	General purpose apps, APIs needing fast iteration

Trade‑offs

Choosing native execution trades build speed and library flexibility for instantaneous start and low memory consumption. The native image builder must analyze all reachable classes; any reflection‑based class loading not declared in the configuration leads to a ClassNotFoundException at runtime. Consequently, you may need to add entries to quarkus.native.additional-build-args or create a reflect-config.json file.

Running on the JVM preserves full dynamic language features, allows hot reload in dev mode, and yields faster builds, but the higher startup time and memory footprint can increase costs in autoscaling environments and affect cold‑start latency.

Implementation: Building and Verifying a Native Executable

Prerequisites

• GraalVM 22+ installed and JAVA_HOME pointing to it.
• Quarkus project with the quarkus-native-image extension added.
• Access to run Maven (./mvnw) with sufficient disk space for the native image build.

Add the Native Image Extension

If not already present, add the extension:

./mvnw quarkus:add-extension -Dextensions="quarkus-native-image"

Configure Reflection (if needed)

Suppose your application uses Jackson to deserialize polymorphic types. You must register the relevant classes for reflection. Add the following to src/main/resources/application.properties:

quarkus.native.additional-build-args=--initialize-at-run-time=com.example.model.PolymorphicType

Alternatively, create a reflect-config.json file in src/main/resources/META-INF/native-image with the appropriate name and allDeclaredConstructors, allDeclaredMethods flags.

Build the Native Executable

Run the native profile:

./mvnw package -Pnative

This command invokes GraalVM’s native-image tool. Expect the build to take several minutes. Successful completion produces a binary in target/<artifactId>-<version>-runner (or <artifactId>-<version>-runner.exe on Windows).

Verify Startup Time and Memory Usage

Execute the binary and measure startup with the time shell builtin (or /usr/bin/time for more detail). Example:

time ./target/my-app-1.0.0-runner

Check the resident set size after the process starts (in another terminal):

ps -o rss -p <pid>

You should observe a startup time well under 100 ms and an RSS around 30 MB for a typical hello‑world service. If the process fails with a ClassNotFoundException, revisit the reflection configuration and add the missing classes.

Validate JVM Mode for Comparison

To see the contrast, run the same code in JVM mode:

./mvnw quarkus:dev

or
java -jar target/*-runner.jar

Measure startup with time and RSS with ps; you will typically see 1‑2 seconds start and ~150 MB RSS.
Limitations and Practical Checks

Version compatibility – Native image builds are sensitive to the exact GraalVM and Quarkus versions. Consult the Quarkus compatibility matrix; mismatched versions can cause build errors or runtime crashes.
Reflection overhead** – Excessive reflection increases native image size and may necessitate extensive configuration. Use the --report-unsupported-elements-at-runtime flag during a trial build to detect missing metadata.
Operating system differences** – A native image built on Linux cannot run on macOS or Windows without rebuilding for that target.
Checking the result** – Beyond startup time and RSS, verify that core functionality works by exercising a representative request (e.g., HTTP endpoint) and confirming correct responses.

By following the steps above you can make an informed decision, produce a native executable when appropriate, and validate its behavior against the JVM baseline.
