Choosing Between android.graphics.Rect and RectF for Custom View Hit Detection

Decision Context

When building a custom view that responds to touch events, you must choose how to represent its touchable area. Android provides android.graphics.Rect, which uses integer coordinates, and android.graphics.RectF, which uses floating-point coordinates. The choice affects hit-test accuracy, CPU cost, and behavior on screens with different densities, especially when views are scaled or transformed.

Constraints and Trade-offs

• Precision: Rect rounds coordinates to whole pixels; RectF retains sub-pixel values.
• Performance: Integer comparisons are generally faster and are often inlined by the runtime; floating-point operations cost more on older CPUs.
• Memory: Both classes store four fields, so a single instance has a similar footprint. The difference appears in temporary allocations and library helper calls that may favor one type over the other.
• Screen density: Integer rounding can shift a touch target by a pixel on high-density screens, causing misalignment with drawn content.
• Transformations: Scaling, rotation, or translation can create sub-pixel boundaries that Rect cannot represent exactly.
• Thread safety: Both classes are mutable. Reusing one instance across threads without copying can cause race conditions.

Comparison Table

Aspect	Rect (int)	RectF (float)
Coordinate type	int	float
Precision	Pixel-level, rounded	Sub-pixel
Hit-test speed	Faster integer comparisons	Slower floating-point operations
Instance size	Four int fields	Four float fields
Best for	Unscaled views, high-frequency touch on low-end hardware	Scaled or transformed views, high-density screens
Misalignment risk	Higher on high-DPI screens	Lower

When to Use Rect

Use Rect when the view is drawn at its natural size without scaling or rotation, and when the hit test runs inside a tight loop, such as a game or a gesture recognizer processing many events per second. Integer containment checks avoid floating-point rounding and work well on lower-end devices.

When to Use RectF

Use RectF when the view is scaled, rotated, or translated, or when the app targets high-density screens where a one-pixel rounding error matters. Float coordinates preserve the exact transformed boundary and reduce the chance of a touch being reported outside the visible area.

Concrete Implementation and Validation

The following custom view stores both an integer and a float rectangle and toggles between them for hit testing. It logs the result so you can compare behavior on different devices.

public class HitTestView extends View {
    private final Rect hitRectInt = new Rect();
    private final RectF hitRectFloat = new RectF();
    private boolean useFloat = false;

    public HitTestView(Context context) { super(context); init(); }
    public HitTestView(Context context, AttributeSet attrs) { super(context, attrs); init(); }
    public HitTestView(Context context, AttributeSet attrs, int defStyleAttr) {
        super(context, attrs, defStyleAttr);
        init();
    }

    private void init() {
        DisplayMetrics metrics = getResources().getDisplayMetrics();
        int widthPx = (int) (200 * metrics.density);
        int heightPx = (int) (200 * metrics.density);
        hitRectInt.set(0, 0, widthPx, heightPx);
        hitRectFloat.set(0f, 0f, widthPx * 1.5f, heightPx * 1.5f);
    }

    @Override
    public boolean onTouchEvent(MotionEvent event) {
        float x = event.getX();
        float y = event.getY();
        boolean inside;
        if (useFloat) {
            inside = hitRectFloat.contains(x, y);
        } else {
            inside = hitRectInt.contains((int) x, (int) y);
        }
        Log.d("HitTest", "Touch at (" + x + "," + y + ") inside? " + inside);
        return true;
    }

    public void setUseFloat(boolean useFloat) {
        this.useFloat = useFloat;
    }
}

To validate, attach this view to an activity, toggle useFloat, and tap near the rectangle edges. Log the containment result for each mode. On high-density screens, RectF may report touches inside that Rect misses because of integer rounding. Do not share the same rectangle instance across threads; create a copy or confine it to the UI thread.

Performance Check

Use Android Studio CPU Profiler to record a burst of touch events and compare time spent in Rect.contains versus RectF.contains. The integer path is typically cheaper, but the difference matters mainly in high-frequency loops. Allocate the rectangle once in the view constructor rather than inside onTouchEvent to avoid garbage collection pressure.

Summary

Choose Rect when:

• The view is not scaled or transformed.
• Hit-test speed is critical on low-end hardware.
• Screen density is moderate.

Choose RectF when:

• The view undergoes scaling, rotation, or translation.
• High-density screens require sub-pixel accuracy.
• Visual alignment between touch target and drawn content is important.

Keep rectangle instances thread-confined or clone them before sharing.
