Choosing Ballerina’s HTTP Streaming API vs. Full‑Buffering for Large Payloads

Decision Context

In a Ballerina 2201+ service that serves or receives large files, you can either stream the data using the stream type or buffer the entire payload in memory. The choice depends on payload size, client capabilities, and the desired balance between memory footprint and code simplicity.

Typical scenarios:

• Serving a 5 GB video file to a web browser.
• Accepting an upload from a sensor that pushes 1 GB of telemetry.
• Processing a 50 MB JSON payload that must be validated before storage.

Option Comparison

Feature	Streaming (chunked)	Full‑Buffering
Peak memory usage	O(Chunk size) – typically <10 MB	O(Payload size) – can exceed JVM heap
Code complexity	Requires handling io:ReadableByteChannel and back‑pressure	Simple read‑into‑byte[] and return
Latency	Lower start‑up latency – first chunk sent immediately	Higher latency – full payload must be read before response
Back‑pressure support	Native – producer pauses if consumer is slow	No native back‑pressure – risk of blocking thread
HTTP/2 compatibility	Experimental; may lose order guarantees	Fully supported, no special handling
Client support	Requires chunked‑transfer support (most browsers, cURL)	Works with any client
Failure handling	Can stream partial data; client may abort mid‑stream	Single failure aborts entire transaction

Trade‑Off Analysis

Choosing streaming is advantageous when:

• Payload >10 MB and you want to keep heap usage low.
• Clients can handle HTTP/1.1 chunked transfer.
• You need to start sending data before the entire file is ready (e.g., live video).

Full‑buffering is preferable when:

• Payload <10 MB – memory cost is negligible.
• You need atomicity (e.g., validate entire JSON before processing).
• Your client does not support chunked transfer.

Concrete Implementation

Streaming Service (Ballerina 2201+)

import ballerina/io;
import ballerina/http;
import ballerina/io;
import ballerina/file;

service fileService on new http:Listener(8080) {
    @http:ResourceConfig { path: "/file/{fileName}" }
    resource getFile(http:Caller caller, http:Request req, string fileName) {
        // Resolve the file path – replace with your logic
        string filePath = "/var/data/" + fileName;
        var channel = file:openReadableChannel(filePath);
        if (channel is io:ReadableByteChannel) {
            // Set Content‑Length if known; otherwise chunked is used automatically
            http:Response resp = new;
            resp.setHeader("Content-Type", "application/octet-stream");
            // Attach the stream
            resp.setEntity(channel);
            caller->respond(resp);
        } else {
            // Handle errors (file not found, permission denied, etc.)
            http:Response errorResp = new;
            errorResp.setStatusCode(404);
            caller->respond(errorResp);
        }
    }
}

Key points:

• The file:openReadableChannel call returns an io:ReadableByteChannel that Ballerina streams automatically using HTTP/1.1 chunked transfer.
• No explicit loop over chunks is needed – the runtime handles back‑pressure.
• Set Content‑Length only if you know the size ahead of time; otherwise, the server will use chunked encoding.

Full‑Buffering Service

import ballerina/io;
import ballerina/http;
import ballerina/file;

service fileService on new http:Listener(8080) {
    @http:ResourceConfig { path: "/file/buffer/{fileName}" }
    resource getFileBuffered(http:Caller caller, http:Request req, string fileName) {
        string filePath = "/var/data/" + fileName;
        var data = file:readAllBytes(filePath);
        if (data is byte[]) {
            http:Response resp = new;
            resp.setHeader("Content-Type", "application/octet-stream");
            resp.setHeader("Content-Length", data.length.toString());
            resp.setEntity(data);
            caller->respond(resp);
        } else {
            http:Response errorResp = new;
            errorResp.setStatusCode(404);
            caller->respond(errorResp);
        }
    }
}

Here the entire file is loaded into a byte array before sending. This is simple but can exhaust the JVM heap for large files.

Validation & Monitoring

1. Deploy both services. Run the Ballerina compiler with bal run for each service.
2. Measure heap usage. On Linux, find the process ID:

   pid=$(pgrep -f ballerina)


   Then monitor heap before and after a request:

   jcmd $pid GC.heap_info | grep HeapSize


3. Trigger a request. Use cURL to download a large file:

   curl -O http://localhost:8080/file/largeFile


   For the buffered version:

   curl -O http://localhost:8080/file/buffer/largeFile


4. Compare peak heap. The streaming service should keep heap near baseline; the buffered service will spike by the file size.
5. Load test. Use wrk or ab to issue concurrent requests and verify that streaming does not deadlock under back‑pressure:

   wrk -t2 -c50 -d30s http://localhost:8080/file/largeFile


   Observe that response times stay stable and no timeouts occur.

Potential pitfalls:

• Clients that do not support chunked transfer may hang or receive incomplete data. Test with a simple HTTP client that prints raw headers.
• HTTP/2 support for streaming is experimental; if you need HTTP/2, prefer buffering or use a custom implementation that forwards the channel.

Conclusion

For payloads larger than 10 MB and when the client can handle HTTP/1.1 chunked transfer, Ballerina’s native streaming API is the most memory‑efficient and scalable choice. It automatically manages back‑pressure and keeps the JVM heap usage low. For smaller payloads, or when client compatibility or atomicity is critical, the simpler buffered approach remains appropriate. Validate your choice with the outlined monitoring steps to ensure that memory usage and latency meet your SLA requirements.
