Choosing a Bitmask Permission Model in Crystal: Enum Flags vs Integer vs Boolean Struct

Decision and Constraints

You need to model a set of user permissions for a Crystal 1.x web service. The decision must satisfy:

• Compile‑time safety – invalid combinations should be caught early.
• Ergonomic bitwise operations (|, &, includes?).
• JSON API compatibility – the permission value should serialize/deserialize without extra runtime cost.
• Zero allocation on hot paths (e.g., permission checks in request handlers).

Options Comparison

Option	Type Safety	Runtime Overhead	JSON Handling	Notes
Enum Flags (e.g., enum Permission : UInt32; Flags)	High – only defined constants can be used; includes? method provided.	Low – underlying integer, no allocation for bitwise ops.	Requires custom converter or mapping to Array(String); default serializes to integer.	Provides readable names and compile‑time checking.
Raw Integer Bitmask (e.g., UInt32)	None – any integer value is allowed, risk of invalid bits.	Minimal – direct CPU instructions.	Serializes as number automatically; no extra work.	Fastest and smallest but relies on documentation to avoid misuse.
Boolean Struct (e.g., struct Permissions; @read : Bool; @write : Bool; @admin : Bool)	Medium – each field is explicit, but adding a flag means editing the struct.	Higher – each Bool is a byte; struct may allocate on stack/heap depending on use.	JSON serializes naturally to object with true/false keys.	Self‑documenting but verbose and inefficient for many flags.

Trade‑offs

Enum Flags give you type‑safe constants and the includes? convenience method. The downside is that Crystal’s JSON::Serializable does not automatically turn a Flags value into an array of names; you must supply a custom converter or explicitly convert to Array(String) when you need that representation.

Raw Integer is the fastest and uses the least memory, but you lose compile‑time guarantees. A typo like 0b1010 instead of 0b0011 will compile and may cause subtle bugs.

Boolean Struct is the most explicit in JSON (each permission appears as a key) and needs no bitwise logic, yet each added flag expands the struct and increases memory traffic. For services that check permissions thousands of times per second, the extra allocation can be measurable.

Concrete Implementation

Below is a minimal, self‑contained example that shows how to define an enum‑flags permission type, combine flags, test membership, and handle JSON with a custom converter.

require "json"

# Define a flag‑based enum with an explicit underlying type.
enum Permission : UInt32
  Flags
  READ    = 1 << 0  # 0b0001
  WRITE   = 1 << 1  # 0b0010
  ADMIN   = 1 << 2  # 0b0100
end

# A simple holder that we will serialize.
struct UserContext
  @user_id : Int64
  @permissions : Permission

  def initialize(@user_id : Int64, @permissions : Permission)
  end

  # Custom JSON serializer: emit permission as an array of name strings.
  def to_json(json : JSON::Builder)
    json.object do
      json.field "user_id" do
        json @user_id
      end
      json.field "permissions" do
        # Convert the flag set to an array of enabled names.
        ary = [] of String
        Permission.each do |name, value|
          if @permissions.includes?(value)
            ary << name
          end
        end
        json ary
      end
    end
  end

  # Custom JSON deserializer: expect an array of names and rebuild the flag set.
  def self.from_json(value : JSON::PullParser)
    user_id = nil
    perms   = Permission::ZERO
    value.each do |key|
      case key
      when "user_id"
        user_id = value.pull.value.to_i64
      when "permissions"
        # Expect an array of strings.
        arr = value.pull.read_as(Array(String))
        arr.each do |name|
          if Permission.has_key?(name)
            perms |= Permission[name]
          else
            raise "Unknown permission: #{name}"
          end
        end
      else
        value.skip
      end
    end
    new(user_id, perms)
  end
end

# Usage example
ctx = UserContext.new(42, Permission::READ | Permission::WRITE)
# Check a flag – zero allocation, compile‑time safe.
if ctx.permissions.includes?(Permission::READ)
  puts "User can read"
end

# Serialize to JSON (produces {"user_id":42,"permissions":["READ","WRITE"]})
json_str = ctx.to_json
puts json_str

# Deserialize back
restored = UserContext.from_json(JSON.parse(json_str))
puts restored.permissions.includes?(Permission::ADMIN) # false

Validation Approach

To confirm that the implementation meets the constraints, perform the following checks in a local Crystal environment (no external services needed):

1. Compile and run the snippet with crystal run permissions.cr. Verify that the printed JSON contains an array of permission names and that the permission checks behave as expected.
2. Inspect the enum at runtime: crystal eval "puts Permission::READ.value" should output 1, and Permission.flags? should return true, confirming the Flags mixin is present.
3. For hot‑path allocation, write a small benchmark using Crystal’s Benchmark module that calls includes? in a tight loop (e.g., 1_000_000 iterations) and compare the allocation count against a baseline integer bitmask. You should see zero additional allocations for the flag version beyond the loop’s own variables.
4. Test JSON round‑trip: serialize a UserContext instance, deserialize it, and assert that the original and restored permission sets are equal. Any mismatch indicates a problem with the custom converter.

Limitations and Practical Checks

• The Flags mixin and the default underlying type (UInt32) are stable from Crystal 0.35 onward, but if you target a pre‑0.35 compiler you must verify the behavior manually.
• The custom JSON converter shown allocates temporary strings when building the Array(String) representation. Avoid calling this conversion inside a request‑handler loop; instead, keep the internal Permission value and only convert when preparing the response.
• If you need to send the permission as a single integer (e.g., to a legacy client), you can skip the custom converter and let the enum serialize to its numeric value directly.
• Always validate incoming permission arrays against the known enum keys to prevent injection of undefined bits.

By following the steps above you can decide which permission model fits your service’s safety, performance, and API requirements, and you have a concrete, verifiable implementation for the Enum Flags approach.
