Calling C++ Functions from Carbon and Vice Versa: A Step‑by‑Step Guide

Desired outcome

Successfully build and run a program where a Carbon source file calls a C++ function and a C++ source file calls a Carbon function, demonstrating bidirectional interoperability without wrapper code.

Prerequisites

• A recent Clang compiler (version 15 or newer) for compiling C++ and linking.
• The Carbon compiler carbonc from a pre‑1.0 release (e.g., version 0.5).
• Basic knowledge of C++ function signatures and Carbon syntax.
• A working terminal with access to clang++, carbonc, and llvm-dis for inspection.

Procedure

1. Write the C++ component. Create myfunc.cpp:

   #include <iostream>
   // Function that will be called from Carbon
   extern "C" void cpp_greet(const char* name) {
       std::cout << "Hello from C++: " << name << '\n';
   }
   // Function that calls a Carbon function
   extern "C" void carbon_caller();
   int main() {
       cpp_greet("world");   // C++ → Carbon via indirect call
       carbon_caller();        // direct call to Carbon
       return 0;
   }


2. Write the Carbon component. Create myfunc.carbon:

   package demo.api;

   // Declare the C++ function with C linkage
   extern "C" fn cpp_greet(name: *const i8);

   // Define a Carbon function that C++ can call
   export fn carbon_caller() {
       cpp_greet("Carbon\0" as *const i8);
   }

   // Optional: a Carbon function called from C++
   export fn carbon_greet(name: *const i8) {
       // Simple echo; in real code you might do more work
       // This function is not used in this example but shows the reverse direction.
   }


3. Compile each translation unit to an object file.

   # Compile C++ to object
   clang++ -c -std=c++20 -O2 myfunc.cpp -o myfunc_cpp.o
   # Compile Carbon to object
   carbonc -c -O2 myfunc.carbon -o myfunc_carbon.o


   Run these commands in the directory containing the source files. Ensure you have write permission for the current directory.

4. Link the objects into an executable.

   clang++ myfunc_cpp.o myfunc_carbon.o -o demo

   The linker uses the host C++ compiler’s ABI, which matches Carbon’s emitted LLVM IR.

5. Run the program and verify output.

   ./demo


   Expected console output (order may vary):

   Hello from C++: world
   Hello from Carbon


   If you see similar lines, the bidirectional call succeeded.

Expected checks

• Execution check. The program exits with status 0 and prints the expected greetings.
• Symbol inspection (optional). Run llvm-dis -show-anonymous-instructions -o - myfunc_carbon.o | grep cpp_greet to confirm that the Carbon object uses the same mangling as the C++ object (typically _Z11cpp_greetPKc for the extern "C" symbol). No extra thunk symbols should appear.
• Incremental build test. Touch only myfunc.carbon, re‑run the Carbon compile and link steps, and verify that the C++ object is not recompiled.

Recovery options

• Undefined reference errors. If linking reports missing symbols, verify that both objects were compiled with the same ABI settings (e.g., same -std=c++ version and -fno-rtti if used). Re‑compile with clang++ -v to see the exact command line.
• Mismatched name mangling. Ensure that any function intended to be called across the boundary is declared with extern "C" in both languages. Carbon’s extern "C" maps directly to the host compiler’s C linkage.
• Toolchain version mismatch. The Carbon compiler’s LLVM IR version must be compatible with the Clang version used for linking. Consult the Carbon release notes for the supported LLVM version; downgrade or upgrade Clang accordingly.
• Limited C++ features. If you need to use templates, multiple inheritance, or RTTI, wrap those constructs in a C++ façade that exposes only extern "C" functions, then call the façade from Carbon.

Limitations

Carbon’s bidirectional interoperability is stable only for a subset of C++: trivial types, move‑only types, and functions with C linkage. Features such as C++ templates, exception propagation across languages, and runtime type information are not yet supported and may require abstraction layers. Additionally, the Carbon toolchain is pre‑1.0, so ABI guarantees are not final; future compiler updates could break existing object files.
