Building Custom Input Fields in ProcessWire: Bridging Fieldtype and Inputfield

The Problem: Standard Fields Aren't Enough

ProcessWire provides a robust set of default field types, but complex data requirements—such as a specialized coordinate picker, a custom API-driven dropdown, or a formatted financial input—often require a custom UI. The challenge is that ProcessWire decouples how data is stored (the Fieldtype) from how it is interacted with in the admin panel (the Inputfield).

Prerequisites

• A running installation of ProcessWire (v3.x recommended).
• Basic knowledge of PHP and Object-Oriented Programming (OOP).
• Administrator access to the /site/modules/ directory.

Step 1: Define the Fieldtype (Storage Layer)

The Fieldtype class manages the database schema and how the value is sanitized before being saved. Create a file in /site/modules/FieldtypeMyCustomField.module.

class FieldtypeMyCustomField extends Fieldtype {
    public function __construct() {
        // Define the database column type
        $this->dbType = 'varchar';
        $this->dbSize = 255;
    }

    public function saveToDatabase($value) {
        // Ensure the value is a string before saving to prevent SQL errors
        return (string) $value;
    }
}

Step 2: Define the Inputfield (UI Layer)

The Inputfield class handles the HTML rendering in the admin interface. This class must match the naming convention of the Fieldtype to be automatically linked. Create /site/modules/InputfieldMyCustomField.module.

class InputfieldMyCustomField extends Inputfield {
    public function render() {
        // The value is accessed via $this->value
        $html = '';
        $html .= 'name . '\\" value=\\"' . $this->value . '\\" class=\\"inputtext\\" \/>';
        $html .= '
Custom helper text for this field.
';
        $html .= '';
        return $html;
    }

    public function validate() {
        // Example: Prevent empty submissions
        if (empty($this->value)) {
            $this->error = 'This field cannot be left blank.';
            return false;
        }
        return true;
    }
}

Step 3: Registration and Implementation

1. Upload both files to /site/modules/.
2. Log into the ProcessWire Admin.
3. Navigate to Setup > Fields > Add New.
4. Select your custom field type from the Type dropdown.
5. Assign the new field to a Page Template.

Comparison: Fieldtype vs. Inputfield

Responsibility	Fieldtype	Inputfield
Database	Defines column type and size	No database interaction
Admin UI	No UI logic	Renders HTML/JS
Validation	Type safety (e.g., casting to int)	User-facing error messages
Lifecycle	saveToDatabase()	render()

Verification and Diagnostics

To verify the implementation is working correctly, perform these three checks:

• UI Check: Create a page using the template. Confirm the custom HTML renders without breaking the admin layout.
• Persistence Check: Enter a value, save the page, and refresh. If the value disappears, check the saveToDatabase() method in the Fieldtype class.
• Validation Check: Trigger your validate() logic (e.g., leave the field empty) and confirm the admin displays the error message.

Diagnostic Tip: If the field does not appear in the \"Add New Field\" dropdown, check the PHP error logs. A syntax error in the module file will prevent ProcessWire from registering the class.

Limitations and Risks

• Cache Inconsistency: Never use raw SQL queries to update custom field data. Always use the ProcessWire API (e.g., $page->set('field_name', 'value')) to ensure the internal cache is cleared.
• XSS Risks: When using render(), always sanitize $this->value if it is being output directly into HTML to prevent Cross-Site Scripting.

Rollback Procedure

1. Delete the FieldtypeMyCustomField.module and InputfieldMyCustomField.module files from /site/modules/.
2. Go to Setup > Fields and delete the field instance from the system.
3. Remove the field from any associated Page Templates.
