Building a REST API with Ballerina's HTTP Listener and Resource Functions

Quick answer: expose a REST endpoint

To make a Ballerina program act as a REST server, you create an http:Listener bound to a port, attach a service to that listener, and write resource functions that match HTTP methods and paths. The listener handles the network I/O, the service groups related resources, and each resource function returns the response body (or a status code) for its matched request.

How the listener and service work

The following minimal example defines a listener on port 9090, a service at the base path /hello, and a GET resource that returns a plain‑text greeting.

import ballerina/http;

listener http:Listener ep = new(9090);

service /hello on ep {
    resource function get sayHello returns string {
        return "Hello, Ballerina!";
    }
}

When the program runs, Ballerina creates a listener strand that accepts TCP connections, parses incoming HTTP/1.1 requests by default, and dispatches them to the first resource whose path and method match the request. The service declaration attaches the listener to a base path; all resources inside the service are resolved relative to that base.

Enabling HTTP/2

Ballerina’s listener uses HTTP/1.1 unless you explicitly turn on HTTP/2. Add the http2 attribute with a value of true when constructing the listener.

listener http:Listener ep = new(9090, {
    http2: true
});

With HTTP/2 enabled, the same service code works unchanged; the listener will negotiate HTTP/2 with clients that support it, while still falling back to HTTP/1.1 for older clients.

Limits and common mistakes

• Missing service keyword or misplaced listener. If you declare the listener but do not wrap resources in a service block, Ballerina treats the resources as ordinary functions and never registers them with the listener, resulting in a silent service that does not respond.
• Overlapping resource paths. Resource matching follows declaration order. A resource defined earlier with a broader pattern (e.g., /users/{id}) will shadow a later resource with a more specific pattern (e.g., /users/admin) if the earlier pattern can also match the request. To avoid shadowing, order resources from most specific to most general, or use distinct base paths.
• Blocking calls inside resource functions. Ballerina runs each request on a strand from a worker pool. A long‑running blocking operation (such as a synchronous file read or a blocking database call) ties up that strand, reducing concurrency and potentially exhausting the pool. Off‑load blocking work to a separate worker (worker pool) or use non‑blocking I/O APIs.
• Incorrect return types. A resource function must return a type that Ballerina can convert to an HTTP response (e.g., string, byte[], json, or a custom http:Response). Returning an incompatible type or omitting a return statement causes a runtime error when the resource is invoked.
• Listener version compatibility. The listener http:Listener ep = new(port); syntax shown requires Ballerina 0.970.0 or later. Earlier releases used the endpoint keyword and a different configuration shape. Check your Ballerina version with bal version before copying the snippet.

Practical verification steps

1. Save the example code to a file named hello.bal.
2. Build the program: bal build hello.bal.
3. Run the executable: bal run hello.bal.
4. From another terminal, test the endpoint: curl -s http://localhost:9090/hello. You should see the text Hello, Ballerina! printed.
5. To confirm HTTP/2, rebuild with the http2: true listener attribute, restart, and use a client that speaks HTTP/2 (e.g., curl --http2 -s http://localhost:9090/hello). The response should be identical, indicating the listener accepted the HTTP/2 connection.

If the service does not respond, check the console output for error messages during startup; they often point to missing service blocks, port conflicts, or version incompatibilities.
