Building a Modular Fastify Plugin with Encapsulated Decorators and Schema Validation

Desired outcome

Create a reusable Fastify plugin that adds a decorated utility (e.g., an authentication helper) to the request object, registers a route with JSON‑schema validation, logs requests via Pino, and keeps the decorator scoped to the plugin so it does not leak to other plugins.

Prerequisites

• Node.js ≥18 installed
• Fastify v4.x installed via npm (or yarn/pnpm)
• Basic familiarity with async/await, JSON Schema, and optionally TypeScript
• Access to a terminal with permission to run node and install packages

Procedure

1. Initialize a Fastify instance

   // server.js
   import Fastify from 'fastify';
   const fastify = Fastify({ logger: true });


2. Define the plugin function

   The plugin uses fastify.decorate to attach a utility to the request object and registers a route that validates incoming JSON with a schema.

   // authPlugin.js
   import fp from 'fastify-plugin';

   export default fp(async function (fastify, opts) {
     // 1. Decorate the request with a simple auth helper
     fastify.decorateRequest('auth', () => {
       // placeholder: real implementation would check headers/tokens
       return { isAuthenticated: true };
     });

     // 2. Register a route inside the plugin scope
     fastify.route({
       method: 'POST',
       url: '/protected',
       schema: {
         body: {
           type: 'object',
           properties: { message: { type: 'string' } },
           required: ['message']
         }
       },
       handler: async (request, reply) => {
         // 3. Use the decorator inside the handler
         const auth = request.auth();
         if (!auth.isAuthenticated) {
           return reply.code(401).send({ error: 'Unauthorized' });
         }
         // Echo back the validated message
         return { received: request.body.message };
       }
     });
   });


3. Register the plugin with encapsulation

   // server.js (continued)
   import authPlugin from './authPlugin.js';

   fastify.register(authPlugin); // plugin is encapsulated by default

   // Start the server
   const start = async () => {
     try {
       await fastify.listen({ port: 3000, host: '0.0.0.0' });
       fastify.log.info(`Server listening on ${fastify.server.address().port}`);
     } catch (err) {
       fastify.log.error(err);
       process.exit(1);
     }
   };
   start();


4. Run the server

   From the project root, execute:

   node server.js


   No special privileges are required; the process binds to port 3000.

Expected checks

• Send a valid JSON payload ({ "message": "hello" }) to POST http://localhost:3000/protected; expect a 200 response with { "received": "hello" } and a log line from Pino.
• Send an invalid payload (e.g., missing message or wrong type); expect a 400 response with Fastify’s default validation error format.
• From a route defined the plugin (e.g., a separate plugin or the root instance), attempt to access request.auth; it should be undefined, confirming encapsulation.
• Throw an error inside the handler (e.g., throw new Error('test')); verify that Fastify’s error handler logs the error and returns a 500 response with an error object.

Recovery options (rollback)

Registering a plugin mutates the Fastify instance’s internal state. To revert:

• Call fastify.close() to shut down the server and release the port.
• If you need to replace the plugin without restarting the whole process, first close the instance, then create a new Fastify instance and register the updated plugin.
• During development, tools like fastify-cli with the --watch flag can automate this close‑and‑re‑register cycle.

Limitations and practical verification

Plugin encapsulation works only when the plugin is registered via fastify.register (or fastify-plugin). If you accidentally call fastify.decorate on the top‑level instance, the decorator becomes globally available, breaking encapsulation. To verify that encapsulation is intact:

1. Start the server as described.
2. In a separate terminal, run a Node REPL and require the Fastify instance (if exposed) or simply attempt to access request.auth in a route outside the plugin; you should receive undefined.
3. If the property is defined, review your code for any top‑level fastify.decorate calls and move them inside the plugin scope.

Remember that changing a route’s JSON schema after registration requires re‑registering the plugin (or creating a new Fastify instance); hot‑reloading without closing the instance may leave stale validation rules.

Diagram

• Fastify instance
• Plugin encapsulation boundary
• Request decorator (auth)
• Route with JSON schema
